+Collision shapes (3D)
|
|
|
+=====================
|
|
|
+
|
|
|
+This guide explains:
|
|
|
+
|
|
|
+- The types of collision shapes available in 3D in Godot.
|
|
|
+- Using a convex or a concave mesh as a collision shape.
|
|
|
+- Performance considerations regarding 3D collisions.
|
|
|
+
|
|
|
+Godot provides many kinds of collision shapes, with different performance and
|
|
|
+accuracy tradeoffs.
|
|
|
+
|
|
|
+You can define the shape of a :ref:`class_PhysicsBody` by adding one or more
|
|
|
+:ref:`CollisionShapes <class_CollisionShape>` as child nodes. Note that you must
|
|
|
+add a :ref:`class_Shape` *resource* to collision shape nodes in the Inspector
|
|
|
+dock.
|
|
|
+
|
|
|
+.. note::
|
|
|
+
|
|
|
+ When you add multiple collision shapes to a single PhysicsBody, you don't
|
|
|
+ have to worry about them overlapping. They won't "collide" with each other.
|
|
|
+
|
|
|
+Primitive collision shapes
|
|
|
+--------------------------
|
|
|
+
|
|
|
+Godot provides the following primitive collision shape types:
|
|
|
+
|
|
|
+- :ref:`class_BoxShape`
|
|
|
+- :ref:`class_SphereShape`
|
|
|
+- :ref:`class_CapsuleShape`
|
|
|
+- :ref:`class_CylinderShape`. It is only available when using the Bullet physics
|
|
|
+ engine.
|
|
|
+
|
|
|
+You can represent the collision of most smaller objects using one or more
|
|
|
+primitive shapes. However, for more complex objects, such as a large ship or a
|
|
|
+whole level, you may need convex or concave shapes instead. More on that below.
|
|
|
+
|
|
|
+We recommend favoring primitive shapes for dynamic objects such as RigidBodies
|
|
|
+and KinematicBodies as their behavior is the most reliable. They often provide
|
|
|
+better performance as well.
|
|
|
+
|
|
|
+Convex collision shapes
|
|
|
+-----------------------
|
|
|
+
|
|
|
+:ref:`Convex collision shapes <class_ConvexPolygonShape>` are a compromise
|
|
|
+between primitive collision shapes and concave collision shapes. They can
|
|
|
+represent shapes of any complexity, but with an important caveat. As their name
|
|
|
+implies, an individual shape can only represent a *convex* shape. For instance,
|
|
|
+a pyramid is *convex*, but a hollow box is *concave*. To define a concave object
|
|
|
+with a single collision shape, you need to use a concave collision shape.
|
|
|
+
|
|
|
+Depending on the object's complexity, you may get better performance by using
|
|
|
+multiple convex shapes instead of a concave collision shape. Godot lets you use
|
|
|
+*convex decomposition* to generate convex shapes that roughly match a hollow
|
|
|
+object. Note this performance advantage no longer applies after a certain amount
|
|
|
+of convex shapes. For large and complex objects such as a whole level, we
|
|
|
+recommend using concave shapes instead.
|
|
|
+
|
|
|
+You can generate one or several convex collision shapes from the editor by
|
|
|
+selecting a MeshInstance and using the **Mesh** menu at the top of the 3D
|
|
|
+viewport. The editor exposes two generation modes:
|
|
|
+
|
|
|
+- **Create Single Convex Collision Sibling** uses the Quickhull algorithm. It
|
|
|
+ creates one CollisionShape node with an automatically generated convex
|
|
|
+ collision shape. Since it only generates a single shape, it provides good
|
|
|
+ performance and is ideal for small objects.
|
|
|
+
|
|
|
+- **Create Multiple Convex Collision Siblings** uses the V-HACD algorithm. It
|
|
|
+ creates several CollisionShape nodes, each with a convex shape. Since it
|
|
|
+ generates multiple shapes, it is more accurate for concave objects at the cost
|
|
|
+ of performance. For objects with medium complexity, it will likely be faster
|
|
|
+ than using a single concave collision shape.
|
|
|
+
|
|
|
+Concave or trimesh collision shapes
|
|
|
+-----------------------------------
|
|
|
+
|
|
|
+:ref:`Concave collision shapes <class_ConcavePolygonShape>`, also called trimesh
|
|
|
+collision shapes, can take any form, from a few triangles to thousands of
|
|
|
+triangles. Concave shapes are the slowest option but are also the most accurate
|
|
|
+in Godot. **You can only use concave shapes within StaticBodies.** They will not
|
|
|
+work with KinematicBodies or RigidBodies unless the RigidBody's mode is Static.
|
|
|
+
|
|
|
+.. note::
|
|
|
+
|
|
|
+ Even though concave shapes offer the most accurate *collision*, contact
|
|
|
+ reporting can be less precise than primitive shapes.
|
|
|
+
|
|
|
+When not using GridMaps for level design, concave shapes are the best approach
|
|
|
+for a level's collision. That said, if your level has small details, you may
|
|
|
+want to exclude those from collision for performance and game feel. To do so,
|
|
|
+you can build a simplified collision mesh in a 3D modeler and have Godot
|
|
|
+generate a collision shape for it automatically. More on that below
|
|
|
+
|
|
|
+Note that unlike primitive and convex shapes, a concave collision shape doesn't
|
|
|
+have an actual "volume". You can place objects both *outside* of the shape as
|
|
|
+well as *inside*.
|
|
|
+
|
|
|
+You can generate a concave collision shape from the editor by selecting a
|
|
|
+MeshInstance and using the **Mesh** menu at the top of the 3D viewport. The
|
|
|
+editor exposes two options:
|
|
|
+
|
|
|
+- **Create Trimesh Static Body** is a convenient option. It creates a StaticBody
|
|
|
+ containing a concave shape matching the mesh's geometry.
|
|
|
+
|
|
|
+- **Create Trimesh Collision Sibling** creates a CollisionShape node with a
|
|
|
+ concave shape matching the mesh's geometry.
|
|
|
+
|
|
|
+.. note::
|
|
|
+
|
|
|
+ Suppose you need to make a RigidBody *slide* on a concave collision shape.
|
|
|
+ In that case, you may notice that sometimes, the RigidBody will bump
|
|
|
+ upwards. To solve this, open **Project > Project Settings** and enable
|
|
|
+ **Physics > 3d > Smooth Trimesh Collision**.
|
|
|
+
|
|
|
+ Once you've enabled smooth trimesh collision, make sure the concave shape is
|
|
|
+ the only shape of your StaticBody and that it's located at its origin
|
|
|
+ without any rotation. This way, the RigidBody should slide perfectly on the
|
|
|
+ StaticBody.
|
|
|
+
|
|
|
+.. seealso::
|
|
|
+
|
|
|
+ Godot can generate collision shapes for your imported 3D scenes
|
|
|
+ automatically. See :ref:`doc_importing_scenes_import_hints` in the
|
|
|
+ documentation for more information.
|
|
|
+
|
|
|
+Performance caveats
|
|
|
+-------------------
|
|
|
+
|
|
|
+You aren't limited to a single collision shape per PhysicsBody. Still, we
|
|
|
+recommend keeping the number of shapes as low as possible to improve
|
|
|
+performance, especially for dynamic objects like RigidBodies and
|
|
|
+KinematicBodies. On top of that, avoid translating, rotating, or scaling
|
|
|
+CollisionShapes to benefit from the physics engine's internal optimizations.
|
|
|
+
|
|
|
+When using a single non-transformed collision shape in a StaticBody, the
|
|
|
+engine's *broad phase* algorithm can discard inactive PhysicsBodies. The *narrow
|
|
|
+phase* will then only have to take into account the active bodies' shapes. If a
|
|
|
+StaticBody has many collision shapes, the broad phase will fail. The narrow
|
|
|
+phase, which is slower, must then perform a collision check against each shape.
|
|
|
+
|
|
|
+If you run into performance issues, you may have to make tradeoffs in terms of
|
|
|
+accuracy. Most games out there don't have a 100% accurate collision. They find
|
|
|
+creative ways to hide it or otherwise make it unnoticeable during normal
|
|
|
+gameplay.
|
