Upload.

Simon 4 years ago
parent
058ce2fa09
commit
09448f7cf6
32 changed files with 4616 additions and 0 deletions
Split View Show Diff Stats
  1. 47 0
      base.css
  2. 12 0
      index.html
  3. BIN
      resources/simplex-noise.png
  4. BIN
      resources/space-negx.jpg
  5. BIN
      resources/space-negy.jpg
  6. BIN
      resources/space-negz.jpg
  7. BIN
      resources/space-posx.jpg
  8. BIN
      resources/space-posy.jpg
  9. BIN
      resources/space-posz.jpg
  10. 39 0
      src/camera-track.js
  11. 448 0
      src/controls.js
  12. 82 0
      src/demo.js
  13. 70 0
      src/game.js
  14. 220 0
      src/graphics.js
  15. 81 0
      src/main.js
  16. 38 0
      src/math.js
  17. 44 0
      src/noise.js
  18. 442 0
      src/quadtree.js
  19. 468 0
      src/scattering-shader.js
  20. 479 0
      src/simplex-noise.js
  21. 115 0
      src/sky.js
  22. 76 0
      src/spline.js
  23. 644 0
      src/terrain-builder-threaded-worker.js
  24. 205 0
      src/terrain-builder-threaded.js
  25. 100 0
      src/terrain-builder.js
  26. 79 0
      src/terrain-chunk.js
  27. 12 0
      src/terrain-constants.js
  28. 288 0
      src/terrain-shader.js
  29. 338 0
      src/terrain.js
  30. 188 0
      src/texture-splatter.js
  31. 80 0
      src/textures.js
  32. 21 0
      src/utils.js

+ 47 - 0
base.css
View File

@@ -0,0 +1,47 @@

+.header {

+  font-size: 3em;

+  color: white;

+  background: #404040;

+  text-align: center;

+  height: 2.5em;

+  text-shadow: 4px 4px 4px black;

+  display: flex;

+  justify-content: center;

+  align-items: center;

+}

+

+#error {

+  font-size: 2em;

+  color: red;

+  height: 50px;

+  text-shadow: 2px 2px 2px black;

+  margin: 2em;

+  display: none;

+}

+

+.container {

+  width: 100% !important;

+  height: 100% !important;

+  display: flex;

+  justify-content: center;

+  align-items: center;

+  flex-direction: column;

+  position: absolute;

+}

+

+.visible {

+  display: block;

+}

+

+#target {

+  width: 100% !important;

+  height: 100% !important;

+  position: absolute;

+}

+

+body {

+  background: #000000;

+  margin: 0;

+  padding: 0;

+  overscroll-behavior: none;

+}

+ 12 - 0
index.html
View File

@@ -0,0 +1,12 @@

+<!DOCTYPE html>

+<html>

+<head>

+  <title>Procedural Planet</title>

+  <link rel="stylesheet" type="text/css" href="base.css">

+</head>

+<body>

+  <div id="target"></div>

+  <script src="./src/main.js" type="module">

+  </script>

+</body>

+</html>

BIN
resources/simplex-noise.png
View File


BIN
resources/space-negx.jpg
View File


BIN
resources/space-negy.jpg
View File


BIN
resources/space-negz.jpg
View File


BIN
resources/space-posx.jpg
View File


BIN
resources/space-posy.jpg
View File


BIN
resources/space-posz.jpg
View File


+ 39 - 0
src/camera-track.js
View File

@@ -0,0 +1,39 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+import {spline} from './spline.js';

+

+

+export const camera_track = (function() {

+

+  class _CameraTrack {

+    constructor(params) {

+      this._params = params;

+      this._currentTime = 0.0;

+
+      const lerp = (t, p1, p2) => {

+        const p = new THREE.Vector3().lerpVectors(p1.pos, p2.pos, t);

+        const q = p1.rot.clone().slerp(p2.rot, t);

+

+        return {pos: p, rot: q};

+      };

+      this._spline = new spline.LinearSpline(lerp);

+

+      for (let p of params.points) {

+        this._spline.AddPoint(p.time, p.data);

+      }

+    }

+

+    Update(timeInSeconds) {

+      this._currentTime += timeInSeconds;

+

+      const r = this._spline.Get(this._currentTime);

+

+      this._params.camera.position.copy(r.pos);

+      this._params.camera.quaternion.copy(r.rot);

+    }

+  };

+

+  return {

+    CameraTrack: _CameraTrack,

+  };

+})();

+ 448 - 0
src/controls.js
View File

@@ -0,0 +1,448 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+import {PointerLockControls} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/controls/PointerLockControls.js';

+import {OrbitControls} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/controls/OrbitControls.js';

+

+

+export const controls = (function() {

+

+  class _OrbitControls {

+    constructor(params) {

+      this._params = params;

+      this._Init(params);

+    }

+

+    _Init(params) {

+      this._controls = new OrbitControls(params.camera, params.domElement);

+      this._controls.target.set(0, 0, 0);

+      this._controls.update();

+    }

+

+    Update() {

+    }

+  }

+

+  // FPSControls was adapted heavily from a threejs example. Movement control

+  // and collision detection was completely rewritten, but credit to original

+  // class for the setup code.

+  class _FPSControls {

+    constructor(params) {

+      this._cells = params.cells;

+      this._Init(params);

+    }

+

+    _Init(params) {

+      this._params = params;

+      this._radius = 2;

+      this._enabled = false;

+      this._move = {

+        forward: false,

+        backward: false,

+        left: false,

+        right: false,

+        up: false,

+        down: false,

+      };

+      this._standing = true;

+      this._velocity = new THREE.Vector3(0, 0, 0);

+      this._decceleration = new THREE.Vector3(-10, -10, -10);

+      this._acceleration = new THREE.Vector3(12, 12, 12);

+

+      this._SetupPointerLock();

+

+      this._controls = new PointerLockControls(

+          params.camera, document.body);

+      params.scene.add(this._controls.getObject());

+

+      const controlObject = this._controls.getObject();

+      this._position = new THREE.Vector3();

+      this._rotation = new THREE.Quaternion();

+      this._position.copy(controlObject.position);

+      this._rotation.copy(controlObject.quaternion);

+

+      document.addEventListener('keydown', (e) => this._onKeyDown(e), false);

+      document.addEventListener('keyup', (e) => this._onKeyUp(e), false);

+

+      this._InitGUI();

+    }

+

+    _InitGUI() {

+      this._params.guiParams.camera = {

+        acceleration_x: 12,

+      };

+

+      const rollup = this._params.gui.addFolder('Camera.FPS');

+      rollup.add(this._params.guiParams.camera, "acceleration_x", 4.0, 24.0).onChange(

+        () => {

+          this._acceleration.set(

+            this._params.guiParams.camera.acceleration_x,

+            this._params.guiParams.camera.acceleration_x,

+            this._params.guiParams.camera.acceleration_x);

+        });

+    }

+

+    _onKeyDown(event) {

+      switch (event.keyCode) {

+        case 38: // up

+        case 87: // w

+          this._move.forward = true;

+          break;

+        case 37: // left

+        case 65: // a

+          this._move.left = true;

+          break;

+        case 40: // down

+        case 83: // s

+          this._move.backward = true;

+          break;

+        case 39: // right

+        case 68: // d

+          this._move.right = true;

+          break;

+        case 33: // PG_UP

+          this._move.up = true;

+          break;

+        case 34: // PG_DOWN

+          this._move.down = true;

+          break;

+      }

+    }

+

+    _onKeyUp(event) {

+      switch(event.keyCode) {

+        case 38: // up

+        case 87: // w

+          this._move.forward = false;

+          break;

+        case 37: // left

+        case 65: // a

+          this._move.left = false;

+          break;

+        case 40: // down

+        case 83: // s

+          this._move.backward = false;

+          break;

+        case 39: // right

+        case 68: // d

+          this._move.right = false;

+          break;

+        case 33: // PG_UP

+          this._move.up = false;

+          break;

+        case 34: // PG_DOWN

+          this._move.down = false;

+          break;

+      }

+    }

+

+    _SetupPointerLock() {

+      const hasPointerLock = (

+          'pointerLockElement' in document ||

+          'mozPointerLockElement' in document ||

+          'webkitPointerLockElement' in document);

+      if (hasPointerLock) {

+        const lockChange = (event) => {

+          if (document.pointerLockElement === document.body ||

+              document.mozPointerLockElement === document.body ||

+              document.webkitPointerLockElement === document.body ) {

+            this._enabled = true;

+            this._controls.enabled = true;

+          } else {

+            this._controls.enabled = false;

+          }

+        };

+        const lockError = (event) => {

+          console.log(event);

+        };

+

+        document.addEventListener('pointerlockchange', lockChange, false);

+        document.addEventListener('webkitpointerlockchange', lockChange, false);

+        document.addEventListener('mozpointerlockchange', lockChange, false);

+        document.addEventListener('pointerlockerror', lockError, false);

+        document.addEventListener('mozpointerlockerror', lockError, false);

+        document.addEventListener('webkitpointerlockerror', lockError, false);

+

+        document.getElementById('target').addEventListener('click', (event) => {

+          document.body.requestPointerLock = (

+              document.body.requestPointerLock ||

+              document.body.mozRequestPointerLock ||

+              document.body.webkitRequestPointerLock);

+

+          if (/Firefox/i.test(navigator.userAgent)) {

+            const fullScreenChange = (event) => {

+              if (document.fullscreenElement === document.body ||

+                  document.mozFullscreenElement === document.body ||

+                  document.mozFullScreenElement === document.body) {

+                document.removeEventListener('fullscreenchange', fullScreenChange);

+                document.removeEventListener('mozfullscreenchange', fullScreenChange);

+                document.body.requestPointerLock();

+              }

+            };

+            document.addEventListener(

+                'fullscreenchange', fullScreenChange, false);

+            document.addEventListener(

+                'mozfullscreenchange', fullScreenChange, false);

+            document.body.requestFullscreen = (

+                document.body.requestFullscreen ||

+                document.body.mozRequestFullscreen ||

+                document.body.mozRequestFullScreen ||

+                document.body.webkitRequestFullscreen);

+            document.body.requestFullscreen();

+          } else {

+            document.body.requestPointerLock();

+          }

+        }, false);

+      }

+    }

+

+    _FindIntersections(boxes, position) {

+      const sphere = new THREE.Sphere(position, this._radius);

+

+      const intersections = boxes.filter(b => {

+        return sphere.intersectsBox(b);

+      });

+

+      return intersections;

+    }

+

+    Update(timeInSeconds) {

+      if (!this._enabled) {

+        return;

+      }

+

+      const frameDecceleration = new THREE.Vector3(

+          this._velocity.x * this._decceleration.x,

+          this._velocity.y * this._decceleration.y,

+          this._velocity.z * this._decceleration.z

+      );

+      frameDecceleration.multiplyScalar(timeInSeconds);

+

+      this._velocity.add(frameDecceleration);

+

+      if (this._move.forward) {

+        this._velocity.z -= 2 ** this._acceleration.z * timeInSeconds;

+      }

+      if (this._move.backward) {

+        this._velocity.z += 2 ** this._acceleration.z * timeInSeconds;

+      }

+      if (this._move.left) {

+        this._velocity.x -= 2 ** this._acceleration.x * timeInSeconds;

+      }

+      if (this._move.right) {

+        this._velocity.x += 2 ** this._acceleration.x * timeInSeconds;

+      }

+      if (this._move.up) {

+        this._velocity.y += 2 ** this._acceleration.y * timeInSeconds;

+      }

+      if (this._move.down) {

+        this._velocity.y -= 2 ** this._acceleration.y * timeInSeconds;

+      }

+

+      const controlObject = this._controls.getObject();

+

+      const oldPosition = new THREE.Vector3();

+      oldPosition.copy(controlObject.position);

+

+      const forward = new THREE.Vector3(0, 0, 1);

+      forward.applyQuaternion(controlObject.quaternion);

+      forward.normalize();

+

+      const updown = new THREE.Vector3(0, 1, 0);

+

+      const sideways = new THREE.Vector3(1, 0, 0);

+      sideways.applyQuaternion(controlObject.quaternion);

+      sideways.normalize();

+

+      sideways.multiplyScalar(this._velocity.x * timeInSeconds);

+      updown.multiplyScalar(this._velocity.y * timeInSeconds);

+      forward.multiplyScalar(this._velocity.z * timeInSeconds);

+

+      controlObject.position.add(forward);

+      controlObject.position.add(sideways);

+      controlObject.position.add(updown);

+

+      // this._position.lerp(controlObject.position, 0.15);

+      this._rotation.slerp(controlObject.quaternion, 0.15);

+

+      // controlObject.position.copy(this._position);

+      controlObject.quaternion.copy(this._rotation);

+    }

+  };

+

+  class _ShipControls {

+    constructor(params) {

+      this._Init(params);

+    }

+

+    _Init(params) {

+      this._params = params;

+      this._radius = 2;

+      this._enabled = false;

+      this._move = {

+        forward: false,

+        backward: false,

+        left: false,

+        right: false,

+        up: false,

+        down: false,

+        rocket: false,

+      };

+      this._velocity = new THREE.Vector3(0, 0, 0);

+      this._decceleration = new THREE.Vector3(-0.001, -0.0001, -1);

+      this._acceleration = new THREE.Vector3(100, 0.1, 25000);

+

+      document.addEventListener('keydown', (e) => this._onKeyDown(e), false);

+      document.addEventListener('keyup', (e) => this._onKeyUp(e), false);

+

+      this._InitGUI();

+    }

+

+    _InitGUI() {

+      this._params.guiParams.camera = {

+        acceleration_x: 100,

+        acceleration_y: 0.1,

+      };

+

+      const rollup = this._params.gui.addFolder('Camera.Ship');

+      rollup.add(this._params.guiParams.camera, "acceleration_x", 50.0, 25000.0).onChange(

+        () => {

+          this._acceleration.x = this._params.guiParams.camera.acceleration_x;

+        });

+      rollup.add(this._params.guiParams.camera, "acceleration_y", 0.001, 0.1).onChange(

+        () => {

+          this._acceleration.y = this._params.guiParams.camera.acceleration_y;

+        });

+    }

+

+    _onKeyDown(event) {

+      switch (event.keyCode) {

+        case 87: // w

+          this._move.forward = true;

+          break;

+        case 65: // a

+          this._move.left = true;

+          break;

+        case 83: // s

+          this._move.backward = true;

+          break;

+        case 68: // d

+          this._move.right = true;

+          break;

+        case 33: // PG_UP

+          this._acceleration.x *= 1.1;

+          break;

+        case 34: // PG_DOWN

+          this._acceleration.x *= 0.8;

+          break;

+        case 32: // SPACE

+          this._move.rocket = true;

+          break;

+        case 38: // up

+        case 37: // left

+        case 40: // down

+        case 39: // right

+          break;

+      }

+    }

+

+    _onKeyUp(event) {

+      switch(event.keyCode) {

+        case 87: // w

+          this._move.forward = false;

+          break;

+        case 65: // a

+          this._move.left = false;

+          break;

+        case 83: // s

+          this._move.backward = false;

+          break;

+        case 68: // d

+          this._move.right = false;

+          break;

+        case 33: // PG_UP

+          break;

+        case 34: // PG_DOWN

+          break;

+        case 32: // SPACE

+          this._move.rocket = false;

+          break;

+        case 38: // up

+        case 37: // left

+        case 40: // down

+        case 39: // right

+          break;

+      }

+    }

+

+    Update(timeInSeconds) {

+      const frameDecceleration = new THREE.Vector3(

+          this._velocity.x * this._decceleration.x,

+          this._velocity.y * this._decceleration.y,

+          this._velocity.z * this._decceleration.z

+      );

+      frameDecceleration.multiplyScalar(timeInSeconds);

+

+      this._velocity.add(frameDecceleration);

+

+      const controlObject = this._params.camera;

+      const _Q = new THREE.Quaternion();

+      const _A = new THREE.Vector3();

+      const _R = controlObject.quaternion.clone();

+

+      if (this._move.forward) {

+        _A.set(1, 0, 0);

+        _Q.setFromAxisAngle(_A, -Math.PI * timeInSeconds * this._acceleration.y);

+        _R.multiply(_Q);

+      }

+      if (this._move.backward) {

+        _A.set(1, 0, 0);

+        _Q.setFromAxisAngle(_A, Math.PI * timeInSeconds * this._acceleration.y);

+        _R.multiply(_Q);

+      }

+      if (this._move.left) {

+        _A.set(0, 0, 1);

+        _Q.setFromAxisAngle(_A, Math.PI * timeInSeconds * this._acceleration.y);

+        _R.multiply(_Q);

+      }

+      if (this._move.right) {

+        _A.set(0, 0, 1);

+        _Q.setFromAxisAngle(_A, -Math.PI * timeInSeconds * this._acceleration.y);

+        _R.multiply(_Q);

+      }

+      if (this._move.rocket) {

+        this._velocity.z -= this._acceleration.x * timeInSeconds;

+      }

+

+      controlObject.quaternion.copy(_R);

+

+      const oldPosition = new THREE.Vector3();

+      oldPosition.copy(controlObject.position);

+

+      const forward = new THREE.Vector3(0, 0, 1);

+      forward.applyQuaternion(controlObject.quaternion);

+      //forward.y = 0;

+      forward.normalize();

+

+      const updown = new THREE.Vector3(0, 1, 0);

+

+      const sideways = new THREE.Vector3(1, 0, 0);

+      sideways.applyQuaternion(controlObject.quaternion);

+      sideways.normalize();

+

+      sideways.multiplyScalar(this._velocity.x * timeInSeconds);

+      updown.multiplyScalar(this._velocity.y * timeInSeconds);

+      forward.multiplyScalar(this._velocity.z * timeInSeconds);

+

+      controlObject.position.add(forward);

+      controlObject.position.add(sideways);

+      controlObject.position.add(updown);

+

+      oldPosition.copy(controlObject.position);

+    }

+  };

+

+  return {

+    ShipControls: _ShipControls,

+    FPSControls: _FPSControls,

+    OrbitControls: _OrbitControls,

+  };

+})();

+ 82 - 0
src/demo.js
View File

@@ -0,0 +1,82 @@

+import {game} from './game.js';

+import {graphics} from './graphics.js';

+import {math} from './math.js';

+import {noise} from './noise.js';

+

+

+window.onload = function() {

+  function _Perlin() {

+    const canvas = document.getElementById("canvas");
+    const context = canvas.getContext("2d");

+
+    const imgData = context.createImageData(canvas.width, canvas.height);

+
+    const params = {

+      scale: 32,

+      noiseType: 'simplex',

+      persistence: 0.5,

+      octaves: 1,

+      lacunarity: 1,

+      exponentiation: 1,

+      height: 255

+    };

+    const noiseGen = new noise.Noise(params);

+

+    for (let x = 0; x < canvas.width; x++) {

+      for (let y = 0; y < canvas.height; y++) {

+        const pixelIndex = (y * canvas.width + x) * 4;

+

+        const n = noiseGen.Get(x, y);

+

+        imgData.data[pixelIndex] = n;

+        imgData.data[pixelIndex+1] = n;

+        imgData.data[pixelIndex+2] = n;

+        imgData.data[pixelIndex+3] = 255;

+      }

+    }

+
+    context.putImageData(imgData, 0, 0);

+}

+

+

+function _Randomness() {

+  const canvas = document.getElementById("canvas");
+  const context = canvas.getContext("2d");

+

+  const imgData = context.createImageData(canvas.width, canvas.height);

+

+  const params = {

+    scale: 32,

+    noiseType: 'simplex',

+    persistence: 0.5,

+    octaves: 1,

+    lacunarity: 2,

+    exponentiation: 1,

+    height: 1

+  };

+  const noiseGen = new noise.Noise(params);

+  let foo = '';

+

+  for (let x = 0; x < canvas.width; x++) {

+    for (let y = 0; y < canvas.height; y++) {

+      const pixelIndex = (y * canvas.width + x) * 4;

+

+      const n = noiseGen.Get(x, y);

+      if (x == 0) {

+        foo += n + '\n';

+      }

+

+      imgData.data[pixelIndex] = n;

+      imgData.data[pixelIndex+1] = n;

+      imgData.data[pixelIndex+2] = n;

+      imgData.data[pixelIndex+3] = 255;

+    }

+  }

+  console.log(foo);

+

+  context.putImageData(imgData, 0, 0);

+}

+

+_Randomness();

+
+};

+ 70 - 0
src/game.js
View File

@@ -0,0 +1,70 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+import {WEBGL} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/WebGL.js';

+import {graphics} from './graphics.js';

+

+

+export const game = (function() {

+  return {

+    Game: class {

+      constructor() {

+        this._Initialize();

+      }

+

+      _Initialize() {

+        this.graphics_ = new graphics.Graphics(this);

+        if (!this.graphics_.Initialize()) {

+          this._DisplayError('WebGL2 is not available.');

+          return;

+        }

+

+        this._previousRAF = null;

+        this._minFrameTime = 1.0 / 10.0;

+        this._entities = {};

+

+        this._OnInitialize();

+        this._RAF();

+      }

+

+      _DisplayError(errorText) {

+        const error = document.getElementById('error');

+        error.innerText = errorText;

+      }

+

+      _RAF() {

+        requestAnimationFrame((t) => {

+          if (this._previousRAF === null) {

+            this._previousRAF = t;

+          }

+          this._Render(t - this._previousRAF);

+          this._previousRAF = t;

+        });

+      }

+

+      _AddEntity(name, entity, priority) {

+        this._entities[name] = {entity: entity, priority: priority};

+      }

+

+      _StepEntities(timeInSeconds) {

+        const sortedEntities = Object.values(this._entities);

+

+        sortedEntities.sort((a, b) => {

+          return a.priority - b.priority;

+        })

+

+        for (let s of sortedEntities) {

+          s.entity.Update(timeInSeconds);

+        }

+      }

+

+      _Render(timeInMS) {

+        const timeInSeconds = Math.min(timeInMS * 0.001, this._minFrameTime);

+

+        this._OnStep(timeInSeconds);

+        this._StepEntities(timeInSeconds);

+        this.graphics_.Render(timeInSeconds);

+

+        this._RAF();

+      }

+    }

+  };

+})();

+ 220 - 0
src/graphics.js
View File

@@ -0,0 +1,220 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+import Stats from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/libs/stats.module.js';

+import {WEBGL} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/WebGL.js';

+

+import {RenderPass} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/postprocessing/RenderPass.js';

+import {ShaderPass} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/postprocessing/ShaderPass.js';

+import {CopyShader} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/shaders/CopyShader.js';

+import {FXAAShader} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/shaders/FXAAShader.js';

+import {EffectComposer} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/postprocessing/EffectComposer.js';

+

+import {scattering_shader} from './scattering-shader.js';

+

+

+export const graphics = (function() {

+

+  function _GetImageData(image) {

+    const canvas = document.createElement('canvas');

+    canvas.width = image.width;

+    canvas.height = image.height;

+

+    const context = canvas.getContext( '2d' );

+    context.drawImage(image, 0, 0);

+

+    return context.getImageData(0, 0, image.width, image.height);

+  }

+

+  function _GetPixel(imagedata, x, y) {

+    const position = (x + imagedata.width * y) * 4;

+    const data = imagedata.data;

+    return {

+        r: data[position],

+        g: data[position + 1],

+        b: data[position + 2],

+        a: data[position + 3]

+    };

+  }

+

+  class _Graphics {

+    constructor(game) {

+    }

+

+    Initialize() {

+      if (!WEBGL.isWebGL2Available()) {

+        return false;

+      }

+

+      const canvas = document.createElement('canvas');

+      const context = canvas.getContext('webgl2', {alpha: false});

+

+      this._threejs = new THREE.WebGLRenderer({

+        canvas: canvas,

+        context: context,

+        antialias: false,

+      });

+      this._threejs.outputEncoding = THREE.LinearEncoding;

+      this._threejs.setPixelRatio(window.devicePixelRatio);

+      this._threejs.setSize(window.innerWidth, window.innerHeight);

+      this._threejs.autoClear = false;

+

+      const target = document.getElementById('target');

+      target.appendChild(this._threejs.domElement);

+

+      this._stats = new Stats();

+      // target.appendChild(this._stats.dom);

+

+      window.addEventListener('resize', () => {

+        this._OnWindowResize();

+      }, false);

+

+      const fov = 60;

+      const aspect = 1920 / 1080;

+      const near = 0.1;

+      const far = 10000000.0;

+      this.camera_ = new THREE.PerspectiveCamera(fov, aspect, near, far);

+      this.camera_.position.set(75, 20, 0);

+

+      this.scene_ = new THREE.Scene();

+      this.scene_.background = new THREE.Color(0xaaaaaa);

+

+      const renderPass = new RenderPass(this.scene_, this.camera_);

+      const fxaaPass = new ShaderPass(FXAAShader);

+      // const depthPass = new ShaderPass(scattering_shader.Shader);

+

+      // this._depthPass = depthPass;

+

+      this.composer_ = new EffectComposer(this._threejs);

+      this.composer_.addPass(renderPass);

+      this.composer_.addPass(fxaaPass);

+      //this.composer_.addPass(depthPass);

+

+      const params = {

+        minFilter: THREE.NearestFilter,

+        magFilter: THREE.NearestFilter,

+        format: THREE.RGBAFormat,

+        type: THREE.FloatType,

+        generateMipmaps: false,

+      };

+

+      this._target = new THREE.WebGLRenderTarget(window.innerWidth, window.innerHeight, params);

+      this._target.stencilBuffer = false;

+      this._target.depthBuffer = true;

+      this._target.depthTexture = new THREE.DepthTexture();

+      this._target.depthTexture.format = THREE.DepthFormat;

+      this._target.depthTexture.type = THREE.FloatType;

+      this._target.outputEncoding = THREE.LinearEncoding;

+

+      this._threejs.setRenderTarget(this._target);

+

+      const logDepthBufFC = 2.0 / ( Math.log(this.camera_.far + 1.0) / Math.LN2);

+

+      this._postCamera = new THREE.OrthographicCamera( - 1, 1, 1, - 1, 0, 1 );

+      this._depthPass = new THREE.ShaderMaterial( {

+        vertexShader: scattering_shader.VS,

+        fragmentShader: scattering_shader.PS,

+        uniforms: {

+          cameraNear: { value: this.Camera.near },

+          cameraFar: { value: this.Camera.far },

+          cameraPosition: { value: this.Camera.position },

+          cameraForward: { value: null },

+          tDiffuse: { value: null },

+          tDepth: { value: null },

+          inverseProjection: { value: null },

+          inverseView: { value: null },

+          planetPosition: { value: null },

+          planetRadius: { value: null },

+          atmosphereRadius: { value: null },

+          logDepthBufFC: { value: logDepthBufFC },

+        }

+      } );

+      var postPlane = new THREE.PlaneBufferGeometry( 2, 2 );

+      var postQuad = new THREE.Mesh( postPlane, this._depthPass );

+      this._postScene = new THREE.Scene();

+      this._postScene.add( postQuad );

+

+      this._CreateLights();

+

+      return true;

+    }

+

+

+    _CreateLights() {

+      let light = new THREE.DirectionalLight(0xFFFFFF, 1);

+      light.position.set(100, 100, -100);

+      light.target.position.set(0, 0, 0);

+      light.castShadow = false;

+      this.scene_.add(light);

+

+      light = new THREE.DirectionalLight(0x404040, 1);

+      light.position.set(100, 100, -100);

+      light.target.position.set(0, 0, 0);

+      light.castShadow = false;

+      this.scene_.add(light);

+

+      light = new THREE.DirectionalLight(0x404040, 1);

+      light.position.set(100, 100, -100);

+      light.target.position.set(0, 0, 0);

+      light.castShadow = false;

+      this.scene_.add(light);

+

+      light = new THREE.DirectionalLight(0x202040, 1);

+      light.position.set(100, -100, 100);

+      light.target.position.set(0, 0, 0);

+      light.castShadow = false;

+      this.scene_.add(light);

+

+      light = new THREE.AmbientLight(0xFFFFFF, 1.0);

+      this.scene_.add(light);

+    }

+

+    _OnWindowResize() {

+      this.camera_.aspect = window.innerWidth / window.innerHeight;

+      this.camera_.updateProjectionMatrix();

+      this._threejs.setSize(window.innerWidth, window.innerHeight);

+      this.composer_.setSize(window.innerWidth, window.innerHeight);

+      this._target.setSize(window.innerWidth, window.innerHeight);

+    }

+

+    get Scene() {

+      return this.scene_;

+    }

+

+    get Camera() {

+      return this.camera_;

+    }

+

+    Render(timeInSeconds) {

+      this._threejs.setRenderTarget(this._target);

+

+      this._threejs.clear();

+      this._threejs.render(this.scene_, this.camera_);

+      //this.composer_.render();

+

+      this._threejs.setRenderTarget( null );

+

+      const forward = new THREE.Vector3();

+      this.camera_.getWorldDirection(forward);

+

+      this._depthPass.uniforms.inverseProjection.value = this.camera_.projectionMatrixInverse;

+      this._depthPass.uniforms.inverseView.value = this.camera_.matrixWorld;

+      this._depthPass.uniforms.tDiffuse.value = this._target.texture;

+      this._depthPass.uniforms.tDepth.value = this._target.depthTexture;

+      this._depthPass.uniforms.cameraNear.value = this.camera_.near;

+      this._depthPass.uniforms.cameraFar.value = this.camera_.far;

+      this._depthPass.uniforms.cameraPosition.value = this.camera_.position;

+      this._depthPass.uniforms.cameraForward.value = forward;

+      this._depthPass.uniforms.planetPosition.value = new THREE.Vector3(0, 0, 0);

+      this._depthPass.uniformsNeedUpdate = true;

+

+      this._threejs.render( this._postScene, this._postCamera );

+

+      this._stats.update();

+    }

+  }

+

+  return {

+    Graphics: _Graphics,

+    GetPixel: _GetPixel,

+    GetImageData: _GetImageData,

+  };

+})();

+ 81 - 0
src/main.js
View File

@@ -0,0 +1,81 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+import {GUI} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/libs/dat.gui.module.js';

+import {controls} from './controls.js';

+import {game} from './game.js';

+import {terrain} from './terrain.js';

+

+let _APP = null;

+

+

+class ProceduralTerrain_Demo extends game.Game {

+  constructor() {

+    super();

+  }

+

+  _OnInitialize() {

+    this._CreateGUI();

+

+    this.graphics_.Camera.position.set(355898.9978932907, -16169.249553939484, -181920.2108868533);

+    this.graphics_.Camera.quaternion.set(0.3525209450519473, 0.6189868049149101, -0.58773147927222, 0.38360921119467495);

+    // this.graphics_.Camera.position.set(283679.0800079606, -314104.8959314113, -71872.13040166264);

+    // this.graphics_.Camera.quaternion.set(0.4461797373759622, 0.5541566632843257, -0.523697972824766, 0.46858773751767197);

+

+    this.graphics_.Camera.position.set(357183.28155512916, -19402.113225302386, -182320.80530987142);

+    this.graphics_.Camera.quaternion.set(0.2511776691104541, 0.6998229958650649, -0.48248862753627253, 0.46299274000447177);

+

+    this._AddEntity('_terrain', new terrain.TerrainChunkManager({

+        camera: this.graphics_.Camera,

+        scene: this.graphics_.Scene,

+        scattering: this.graphics_._depthPass,

+        gui: this._gui,

+        guiParams: this._guiParams,

+        game: this}), 1.0);

+

+    this._AddEntity('_controls', new controls.FPSControls({

+        camera: this.graphics_.Camera,

+        scene: this.graphics_.Scene,

+        domElement: this.graphics_._threejs.domElement,

+        gui: this._gui,

+        guiParams: this._guiParams}), 0.0);

+

+    this._totalTime = 0;

+

+    this._LoadBackground();

+  }

+

+  _CreateGUI() {

+    this._guiParams = {

+      general: {

+      },

+    };

+    this._gui = new GUI();

+

+    const generalRollup = this._gui.addFolder('General');

+    this._gui.close();

+  }

+

+  _LoadBackground() {

+    this.graphics_.Scene.background = new THREE.Color(0x000000);

+    const loader = new THREE.CubeTextureLoader();

+    const texture = loader.load([

+        './resources/space-posx.jpg',

+        './resources/space-negx.jpg',

+        './resources/space-posy.jpg',

+        './resources/space-negy.jpg',

+        './resources/space-posz.jpg',

+        './resources/space-negz.jpg',

+    ]);

+    texture.encoding = THREE.sRGBEncoding;

+    this.graphics_.Scene.background = texture;

+  }

+

+  _OnStep(timeInSeconds) {

+  }

+}

+

+

+function _Main() {

+  _APP = new ProceduralTerrain_Demo();

+}

+

+_Main();

+ 38 - 0
src/math.js
View File

@@ -0,0 +1,38 @@

+export const math = (function() {

+  return {

+    rand_range: function(a, b) {

+      return Math.random() * (b - a) + a;

+    },

+

+    rand_normalish: function() {

+      const r = Math.random() + Math.random() + Math.random() + Math.random();

+      return (r / 4.0) * 2.0 - 1;

+    },

+

+    rand_int: function(a, b) {

+      return Math.round(Math.random() * (b - a) + a);

+    },

+

+    lerp: function(x, a, b) {

+      return x * (b - a) + a;

+    },

+

+    smoothstep: function(x, a, b) {

+      x = x * x * (3.0 - 2.0 * x);

+      return x * (b - a) + a;

+    },

+

+    smootherstep: function(x, a, b) {

+      x = x * x * x * (x * (x * 6 - 15) + 10);

+      return x * (b - a) + a;

+    },

+

+    clamp: function(x, a, b) {

+      return Math.min(Math.max(x, a), b);

+    },

+

+    sat: function(x) {

+      return Math.min(Math.max(x, 0.0), 1.0);

+    },

+  };

+})();

+ 44 - 0
src/noise.js
View File

@@ -0,0 +1,44 @@

+import {simplex} from './simplex-noise.js';

+

+export const noise = (function() {

+

+  class _NoiseGenerator {

+    constructor(params) {

+      this._params = params;

+      this._Init();

+    }

+

+    _Init() {

+      this._noise = new simplex.SimplexNoise(this._params.seed);

+    }

+

+    Get(x, y, z) {

+      const G = 2.0 ** (-this._params.persistence);

+      const xs = x / this._params.scale;

+      const ys = y / this._params.scale;

+      const zs = z / this._params.scale;

+      const noiseFunc = this._noise;

+

+      let amplitude = 1.0;

+      let frequency = 1.0;

+      let normalization = 0;

+      let total = 0;

+      for (let o = 0; o < this._params.octaves; o++) {

+        const noiseValue = noiseFunc.noise3D(

+          xs * frequency, ys * frequency, zs * frequency) * 0.5 + 0.5;

+

+        total += noiseValue * amplitude;

+        normalization += amplitude;

+        amplitude *= G;

+        frequency *= this._params.lacunarity;

+      }

+      total /= normalization;

+      return Math.pow(

+          total, this._params.exponentiation) * this._params.height;

+    }

+  }

+

+  return {

+    Noise: _NoiseGenerator

+  }

+})();

+ 442 - 0
src/quadtree.js
View File

@@ -0,0 +1,442 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+

+export const quadtree = (function() {

+

+  class CubeQuadTree {

+    constructor(params) {

+      this._params = params;

+      this.sides_ = [];

+

+      const r = params.radius;

+      let m;

+

+      const transforms = [];

+

+      // +Y 0

+      m = new THREE.Matrix4();

+      m.makeRotationX(-Math.PI / 2);

+      m.premultiply(new THREE.Matrix4().makeTranslation(0, r, 0));

+      transforms.push(m);

+

+      // -Y 1

+      m = new THREE.Matrix4();

+      m.makeRotationX(Math.PI / 2);

+      m.premultiply(new THREE.Matrix4().makeTranslation(0, -r, 0));

+      transforms.push(m);

+

+      // +X 2

+      m = new THREE.Matrix4();

+      m.makeRotationY(Math.PI / 2);

+      m.premultiply(new THREE.Matrix4().makeTranslation(r, 0, 0));

+      transforms.push(m);

+

+      // -X 3

+      m = new THREE.Matrix4();

+      m.makeRotationY(-Math.PI / 2);

+      m.premultiply(new THREE.Matrix4().makeTranslation(-r, 0, 0));

+      transforms.push(m);

+

+      // +Z 4

+      m = new THREE.Matrix4();

+      m.premultiply(new THREE.Matrix4().makeTranslation(0, 0, r));

+      transforms.push(m);

+
+      // -Z 5

+      m = new THREE.Matrix4();

+      m.makeRotationY(Math.PI);

+      m.premultiply(new THREE.Matrix4().makeTranslation(0, 0, -r));

+      transforms.push(m);

+

+      for (let i = 0; i < transforms.length; ++i) {

+        const t = transforms[i];

+        this.sides_.push({

+          transform: t.clone(),

+          quadtree: new QuadTree({

+            side: i,

+            size: r,

+            min_node_size: params.min_node_size,

+            max_node_size: params.max_node_size,

+            localToWorld: t,

+            worldToLocal: t.clone().invert()

+          }),

+        });

+      }

+

+      this.BuildRootNeighbourInfo_();

+    }

+

+    BuildRootNeighbourInfo_() {

+      const _FindClosestNeighbour = (edgeMidpoint, otherNodes) => {

+        const neighbours = [...otherNodes].sort((a, b) => {

+          return a.sphereCenter.distanceTo(edgeMidpoint) - b.sphereCenter.distanceTo(edgeMidpoint);

+        });

+        const test = [...otherNodes].map(c => {

+          return c.sphereCenter.distanceTo(edgeMidpoint);

+        }).sort((a, b) => a - b);

+        return neighbours[0];

+      };

+

+      const nodes = this.sides_.map(s => s.quadtree.root_);

+

+      for (let i = 0; i < 6; ++i) {

+        const node = nodes[i];

+        const edgeMidpoints = [

+          node.GetLeftEdgeMidpoint(),

+          node.GetTopEdgeMidpoint(),

+          node.GetRightEdgeMidpoint(),

+          node.GetBottomEdgeMidpoint(),

+        ];

+        const otherNodes = nodes.filter(n => n.side != node.side);

+

+        const neighbours = edgeMidpoints.map(p => _FindClosestNeighbour(p, otherNodes));

+        node.neighbours = neighbours.map(n => nodes[n.side]);

+      }

+    }

+

+    GetChildren() {

+      const children = [];

+

+      for (let s of this.sides_) {

+        const side = {

+          transform: s.transform,

+          children: s.quadtree.GetChildren(),

+        }

+        children.push(side);

+      }

+      return children;

+    }

+

+    Insert(pos) {

+      for (let s of this.sides_) {

+        s.quadtree.Insert(pos);

+      }

+    }

+

+    BuildNeighbours() {

+      let queue = [];

+      for (let s of this.sides_) {

+        queue.push(s.quadtree.root_);

+      }

+

+      while (queue.length > 0) {

+        const node = queue.shift();

+

+        this.sides_[node.side].quadtree.BuildNeighbours_Child_(node);

+

+        for (let c of node.children) {

+          queue.push(c);

+        }

+      }

+    }

+  }

+

+  const LEFT = 0;

+  const TOP = 1;

+  const RIGHT = 2;

+  const BOTTOM = 3;

+

+  const TOP_LEFT = 2;

+  const TOP_RIGHT = 3;

+  const BOTTOM_LEFT = 0;

+  const BOTTOM_RIGHT = 1;

+

+  class Node {

+    constructor(params) {

+    }

+

+    GetNeighbour(side) {

+      return this.neighbours[side];

+    }

+

+    GetClosestChild(node) {

+      const children = [...this.children].sort((a, b) => {

+        return a.sphereCenter.distanceTo(node.sphereCenter) - b.sphereCenter.distanceTo(node.sphereCenter);

+      });

+      const test = [...this.children].map(c => {

+        return c.sphereCenter.distanceTo(node.sphereCenter);

+      }).sort((a, b) => a - b);

+      return children[0];

+    }

+

+    GetChild(pos) {

+      return this.children[pos];

+    }

+

+    GetClosestChildrenSharingEdge(edgePoint) {

+      if (this.children.length == 0) {

+        const edgePointLocal = edgePoint.clone().applyMatrix4(this.tree.worldToLocal);

+        if (edgePointLocal.x == this.bounds.min.x || edgePointLocal.x == this.bounds.max.x ||

+            edgePointLocal.y == this.bounds.min.y || edgePointLocal.y == this.bounds.max.y) {

+          return [this];

+        }

+        return [];

+      }

+

+      const matches = [];

+      for (let i = 0; i < this.children.length; ++i) {

+        const child = this.children[i];

+

+        matches.push(...child.GetClosestChildrenSharingEdge(edgePoint));

+      }

+      return matches;

+    }

+

+    GetLeftEdgeMidpoint() {

+      const v = new THREE.Vector3(this.bounds.min.x, (this.bounds.max.y + this.bounds.min.y) * 0.5, 0);

+      v.applyMatrix4(this.localToWorld);

+      return v;

+    }

+

+    GetRightEdgeMidpoint() {

+      const v = new THREE.Vector3(this.bounds.max.x, (this.bounds.max.y + this.bounds.min.y) * 0.5, 0);

+      v.applyMatrix4(this.localToWorld);

+      return v;

+    }

+

+    GetTopEdgeMidpoint() {

+      const v = new THREE.Vector3((this.bounds.max.x + this.bounds.min.x) * 0.5, this.bounds.max.y, 0);

+      v.applyMatrix4(this.localToWorld);

+      return v;

+    }

+

+    GetBottomEdgeMidpoint() {

+      const v = new THREE.Vector3((this.bounds.max.x + this.bounds.min.x) * 0.5, this.bounds.min.y, 0);

+      v.applyMatrix4(this.localToWorld);

+      return v;

+    }

+  };

+

+  class QuadTree {

+    constructor(params) {

+      const s = params.size;

+      const b = new THREE.Box3(

+        new THREE.Vector3(-s, -s, 0),

+        new THREE.Vector3(s, s, 0));

+      this.root_ = new Node();

+      this.root_.side = params.side;

+      this.root_.bounds = b;

+      this.root_.children = [];

+      this.root_.parent = null;

+      this.root_.tree = this;

+      this.root_.center = b.getCenter(new THREE.Vector3());

+      this.root_.sphereCenter = b.getCenter(new THREE.Vector3());

+      this.root_.localToWorld = params.localToWorld;

+      this.root_.size = b.getSize(new THREE.Vector3());

+      this.root_.root = true;

+      this.root_.neighbours = [null, null, null, null];

+

+      this._params = params;

+      this.worldToLocal = params.worldToLocal;

+      this.root_.sphereCenter = this.root_.center.clone();

+      this.root_.sphereCenter.applyMatrix4(this._params.localToWorld);

+      this.root_.sphereCenter.normalize();

+      this.root_.sphereCenter.multiplyScalar(this._params.size);

+    }

+

+    GetChildren() {

+      const children = [];

+      this._GetChildren(this.root_, children);

+      return children;

+    }

+

+    _GetChildren(node, target) {

+      if (node.children.length == 0) {

+        target.push(node);

+        return;

+      }

+

+      for (let c of node.children) {

+        this._GetChildren(c, target);

+      }

+    }

+

+    BuildNeighbours_Child_(node) {
+      const children = node.children;

+      if (children.length == 0) {

+        const hx = (node.bounds.max.x + node.bounds.min.x) * 0.5;

+        const hy = (node.bounds.max.y + node.bounds.min.y) * 0.5;

+        const nx = node.bounds.min.x;

+        const ny = node.bounds.min.y;

+        const px = node.bounds.max.x;

+        const py = node.bounds.max.y;

+        const b1 = new THREE.Vector3(nx, hy, 0);

+        const b2 = new THREE.Vector3(hx, py, 0);

+        const b3 = new THREE.Vector3(px, hy, 0);

+        const b4 = new THREE.Vector3(hx, ny, 0);

+

+        return;

+      }

+

+      if (node.center.x == 375000 && node.center.y == -125000 && node.side == 1 && node.size.x == 50000) {

+        let a = 0;

+      }

+      if (node.root && node.side == 1) {

+        let a = 0;

+      }

+      if (node.center.x == 200000 && node.center.y == -200000 && node.side == 1) {

+        let a =0;

+      }

+       // Bottom left

+      let leftNeighbour = node.GetNeighbour(LEFT);

+      if (leftNeighbour.children.length > 0) {

+        if (leftNeighbour.side != node.side) {

+          leftNeighbour = leftNeighbour.GetClosestChild(children[0]);

+        } else {

+          leftNeighbour = leftNeighbour.GetChild(BOTTOM_RIGHT);

+        }

+      }

+

+      let bottomNeighbour = node.GetNeighbour(BOTTOM);

+      if (bottomNeighbour.children.length > 0) {

+        if (bottomNeighbour.side != node.side) {

+          bottomNeighbour = bottomNeighbour.GetClosestChild(children[0]);

+        } else {

+          bottomNeighbour = bottomNeighbour.GetChild(TOP_LEFT);

+        }

+      }

+      children[0].neighbours = [leftNeighbour, children[TOP_LEFT], children[BOTTOM_RIGHT], bottomNeighbour];

+

+      // Bottom right

+      let rightNeighbour = node.GetNeighbour(RIGHT);

+      if (rightNeighbour.children.length > 0) {

+        if (rightNeighbour.side != node.side) {

+          rightNeighbour = rightNeighbour.GetClosestChild(children[1]);

+        } else {

+          rightNeighbour = rightNeighbour.GetChild(BOTTOM_LEFT);

+        }

+      }

+

+      bottomNeighbour = node.GetNeighbour(BOTTOM);

+      if (bottomNeighbour.children.length > 0) {

+        if (bottomNeighbour.side != node.side) {

+          bottomNeighbour = bottomNeighbour.GetClosestChild(children[1]);

+        } else {

+          bottomNeighbour = bottomNeighbour.GetChild(TOP_RIGHT);

+        }

+      }

+      children[1].neighbours = [children[BOTTOM_LEFT], children[TOP_RIGHT], rightNeighbour, bottomNeighbour];

+

+      // Top left

+      leftNeighbour = node.GetNeighbour(LEFT);

+      if (leftNeighbour.children.length > 0) {

+        if (leftNeighbour.side != node.side) {

+          leftNeighbour = leftNeighbour.GetClosestChild(children[2]);

+        } else {

+          leftNeighbour = leftNeighbour.GetChild(TOP_RIGHT);

+        }

+      }

+

+      let topNeighbour = node.GetNeighbour(TOP);

+      if (topNeighbour.children.length > 0) {

+        if (topNeighbour.side != node.side) {

+          topNeighbour = topNeighbour.GetClosestChild(children[2]);

+        } else {

+          topNeighbour = topNeighbour.GetChild(BOTTOM_LEFT);

+        }

+      }

+      children[2].neighbours = [leftNeighbour, topNeighbour, children[TOP_RIGHT], children[BOTTOM_LEFT]];

+

+      // Top right

+      topNeighbour = node.GetNeighbour(TOP);

+      if (topNeighbour.children.length > 0) {

+        if (topNeighbour.side != node.side) {

+          topNeighbour = topNeighbour.GetClosestChild(children[3]);

+        } else {

+          topNeighbour = topNeighbour.GetChild(BOTTOM_RIGHT);

+        }

+      }

+

+      rightNeighbour = node.GetNeighbour(RIGHT);

+      if (rightNeighbour.children.length > 0) {

+        if (rightNeighbour.side != node.side) {

+          rightNeighbour = rightNeighbour.GetClosestChild(children[3]);

+        } else {

+          rightNeighbour = rightNeighbour.GetChild(TOP_LEFT);

+        }

+      }

+      children[3].neighbours = [children[TOP_LEFT], topNeighbour, rightNeighbour, children[BOTTOM_RIGHT]];

+    }

+

+    Insert(pos) {

+      this._Insert(this.root_, pos);

+    }

+

+    _Insert(child, pos) {

+      // hack

+      const distToChild = this._DistanceToChild(child, pos);

+

+      if ((distToChild < child.size.x * 1.0 && child.size.x > this._params.min_node_size)) {

+        child.children = this._CreateChildren(child);

+

+        for (let c of child.children) {

+          this._Insert(c, pos);

+        }

+      }

+    }

+

+    _DistanceToChild(child, pos) {

+      return child.sphereCenter.distanceTo(pos);

+    }

+

+    _CreateChildren(child) {

+      const midpoint = child.bounds.getCenter(new THREE.Vector3());

+

+      // Bottom left

+      const b1 = new THREE.Box3(child.bounds.min, midpoint);

+

+      // Bottom right

+      const b2 = new THREE.Box3(

+        new THREE.Vector3(midpoint.x, child.bounds.min.y, 0),

+        new THREE.Vector3(child.bounds.max.x, midpoint.y, 0));

+

+      // Top left

+      const b3 = new THREE.Box3(

+        new THREE.Vector3(child.bounds.min.x, midpoint.y, 0),

+        new THREE.Vector3(midpoint.x, child.bounds.max.y, 0));

+

+      // Top right

+      const b4 = new THREE.Box3(midpoint, child.bounds.max);

+

+      const children = [b1, b2, b3, b4].map(

+          b => {

+            return {

+              side: child.side,

+              bounds: b,

+              children: [],

+              parent: child,

+              center: b.getCenter(new THREE.Vector3()),

+              size: b.getSize(new THREE.Vector3())

+            };

+          });

+

+      const nodes = [];

+      for (let c of children) {

+        c.sphereCenter = c.center.clone();

+        c.sphereCenter.applyMatrix4(this._params.localToWorld);

+        c.sphereCenter.normalize()

+        c.sphereCenter.multiplyScalar(this._params.size);

+

+        const n = new Node();

+        n.side = child.side;

+        n.bounds = c.bounds;

+        n.children = [];

+        n.parent = child;

+        n.tree = this;

+        n.center = c.center;

+        n.sphereCenter = c.sphereCenter;

+        n.size = c.size;

+        n.localToWorld = child.localToWorld;

+        n.neighbours = [null, null, null, null];

+        nodes.push(n);

+      }

+

+      return nodes;

+    }

+  }

+

+  return {

+    QuadTree: QuadTree,

+    CubeQuadTree: CubeQuadTree,

+  }

+})();

+ 468 - 0
src/scattering-shader.js
View File

@@ -0,0 +1,468 @@

+

+export const scattering_shader = (function() {

+

+  const _VS = `

+

+  #define saturate(a) clamp( a, 0.0, 1.0 )

+

+  out vec2 vUv;

+

+  void main() {

+    vUv = uv;

+    gl_Position = projectionMatrix * modelViewMatrix * vec4(position, 1.0);

+  }

+  `;

+
+

+  const _PS = `

+  #include <packing>

+

+  #define saturate(a) clamp( a, 0.0, 1.0 )

+

+  #define PI 3.141592

+  #define PRIMARY_STEP_COUNT 16

+  #define LIGHT_STEP_COUNT 8

+

+

+  in vec2 vUv;

+
+  uniform sampler2D tDiffuse;

+  uniform sampler2D tDepth;

+  uniform float cameraNear;

+  uniform float cameraFar;

+  uniform vec3 cameraForward;

+  uniform mat4 inverseProjection;

+  uniform mat4 inverseView;

+

+  uniform vec3 planetPosition;

+  uniform float planetRadius;

+  uniform float atmosphereRadius;

+
+  uniform float logDepthBufFC;

+

+  vec3 _ScreenToWorld(vec3 posS) {

+

+    float depthValue = posS.z;

+    float v_depth = pow(2.0, depthValue / (logDepthBufFC * 0.5));

+    float z_view = v_depth - 1.0;

+

+    vec4 posCLIP = vec4(posS.xy * 2.0 - 1.0, 0.0, 1.0);

+    vec4 posVS = inverseProjection * posCLIP;

+

+    posVS = vec4(posVS.xyz / posVS.w, 1.0);

+    posVS.xyz = normalize(posVS.xyz) * z_view;

+

+    vec4 posWS = inverseView * posVS;

+

+    return posWS.xyz;

+  }

+

+  vec3 _ScreenToWorld_Normal(vec3 pos) {

+    vec3 posS = pos;

+

+    vec4 posP = vec4(posS.xyz * 2.0 - 1.0, 1.0);

+    vec4 posVS = inverseProjection * posP;

+
+    posVS = vec4((posVS.xyz / posVS.w), 1.0);

+    vec4 posWS = inverseView * posVS;

+
+    return posWS.xyz;

+  }

+

+  // source: https://github.com/selfshadow/ltc_code/blob/master/webgl/shaders/ltc/ltc_blit.fs

+  vec3 RRTAndODTFit( vec3 v ) {

+    vec3 a = v * ( v + 0.0245786 ) - 0.000090537;

+    vec3 b = v * ( 0.983729 * v + 0.4329510 ) + 0.238081;

+    return a / b;

+  }

+  // this implementation of ACES is modified to accommodate a brighter viewing environment.

+  // the scale factor of 1/0.6 is subjective. see discussion in #19621.

+  vec3 ACESFilmicToneMapping( vec3 color ) {

+    // sRGB => XYZ => D65_2_D60 => AP1 => RRT_SAT

+    const mat3 ACESInputMat = mat3(

+      vec3( 0.59719, 0.07600, 0.02840 ), // transposed from source

+      vec3( 0.35458, 0.90834, 0.13383 ),

+      vec3( 0.04823, 0.01566, 0.83777 )

+    );

+    // ODT_SAT => XYZ => D60_2_D65 => sRGB

+    const mat3 ACESOutputMat = mat3(

+      vec3(  1.60475, -0.10208, -0.00327 ), // transposed from source

+      vec3( -0.53108,  1.10813, -0.07276 ),

+      vec3( -0.07367, -0.00605,  1.07602 )

+    );

+    color *= 1.0 / 0.6;

+    color = ACESInputMat * color;

+    // Apply RRT and ODT

+    color = RRTAndODTFit( color );

+    color = ACESOutputMat * color;

+    // Clamp to [0, 1]

+    return saturate( color );

+  }

+

+  float _SoftLight(float a, float b) {

+    return (b < 0.5 ?

+        (2.0 * a * b + a * a * (1.0 - 2.0 * b)) :

+        (2.0 * a * (1.0 - b) + sqrt(a) * (2.0 * b - 1.0))

+    );

+  }

+

+  vec3 _SoftLight(vec3 a, vec3 b) {

+    return vec3(

+        _SoftLight(a.x, b.x),

+        _SoftLight(a.y, b.y),

+        _SoftLight(a.z, b.z)

+    );

+  }

+

+  bool _RayIntersectsSphere(

+      vec3 rayStart, vec3 rayDir, vec3 sphereCenter, float sphereRadius, out float t0, out float t1) {

+    vec3 oc = rayStart - sphereCenter;

+    float a = dot(rayDir, rayDir);

+    float b = 2.0 * dot(oc, rayDir);

+    float c = dot(oc, oc) - sphereRadius * sphereRadius;

+    float d =  b * b - 4.0 * a * c;

+

+    // Also skip single point of contact

+    if (d <= 0.0) {

+      return false;

+    }

+

+    float r0 = (-b - sqrt(d)) / (2.0 * a);

+    float r1 = (-b + sqrt(d)) / (2.0 * a);

+

+    t0 = min(r0, r1);

+    t1 = max(r0, r1);

+

+    return (t1 >= 0.0);

+  }

+

+

+  vec3 _SampleLightRay(

+      vec3 origin, vec3 sunDir, float planetScale, float planetRadius, float totalRadius,

+      float rayleighScale, float mieScale, float absorptionHeightMax, float absorptionFalloff) {

+

+    float t0, t1;

+    _RayIntersectsSphere(origin, sunDir, planetPosition, totalRadius, t0, t1);

+

+    float actualLightStepSize = (t1 - t0) / float(LIGHT_STEP_COUNT);

+    float virtualLightStepSize = actualLightStepSize * planetScale;

+    float lightStepPosition = 0.0;

+

+    vec3 opticalDepthLight = vec3(0.0);

+

+    for (int j = 0; j < LIGHT_STEP_COUNT; j++) {

+      vec3 currentLightSamplePosition = origin + sunDir * (lightStepPosition + actualLightStepSize * 0.5);

+

+      // Calculate the optical depths and accumulate

+      float currentHeight = length(currentLightSamplePosition) - planetRadius;

+      float currentOpticalDepthRayleigh = exp(-currentHeight / rayleighScale) * virtualLightStepSize;

+      float currentOpticalDepthMie = exp(-currentHeight / mieScale) * virtualLightStepSize;

+      float currentOpticalDepthOzone = (1.0 / cosh((absorptionHeightMax - currentHeight) / absorptionFalloff));

+      currentOpticalDepthOzone *= currentOpticalDepthRayleigh * virtualLightStepSize;

+

+      opticalDepthLight += vec3(

+          currentOpticalDepthRayleigh,

+          currentOpticalDepthMie,

+          currentOpticalDepthOzone);

+

+      lightStepPosition += actualLightStepSize;

+    }

+

+    return opticalDepthLight;

+  }

+

+  void _ComputeScattering(

+      vec3 worldSpacePos, vec3 rayDirection, vec3 rayOrigin, vec3 sunDir,

+      out vec3 scatteringColour, out vec3 scatteringOpacity) {

+

+    vec3 betaRayleigh = vec3(5.5e-6, 13.0e-6, 22.4e-6);

+    float betaMie = 21e-6;

+    vec3 betaAbsorption = vec3(2.04e-5, 4.97e-5, 1.95e-6);

+    float g = 0.76;

+    float sunIntensity = 40.0;

+

+    float planetRadius = planetRadius;

+    float atmosphereRadius = atmosphereRadius - planetRadius;

+    float totalRadius = planetRadius + atmosphereRadius;

+

+    float referencePlanetRadius = 6371000.0;

+    float referenceAtmosphereRadius = 100000.0;

+    float referenceTotalRadius = referencePlanetRadius + referenceAtmosphereRadius;

+    float referenceRatio = referencePlanetRadius / referenceAtmosphereRadius;

+

+    float scaleRatio = planetRadius / atmosphereRadius;

+    float planetScale = referencePlanetRadius / planetRadius;

+    float atmosphereScale = scaleRatio / referenceRatio;

+    float maxDist = distance(worldSpacePos, rayOrigin);

+

+    float rayleighScale = 8500.0 / (planetScale * atmosphereScale);

+    float mieScale = 1200.0 / (planetScale * atmosphereScale);

+    float absorptionHeightMax = 32000.0 * (planetScale * atmosphereScale);

+    float absorptionFalloff = 3000.0 / (planetScale * atmosphereScale);;

+

+    float mu = dot(rayDirection, sunDir);

+    float mumu = mu * mu;

+    float gg = g * g;

+    float phaseRayleigh = 3.0 / (16.0 * PI) * (1.0 + mumu);

+    float phaseMie = 3.0 / (8.0 * PI) * ((1.0 - gg) * (mumu + 1.0)) / (pow(1.0 + gg - 2.0 * mu * g, 1.5) * (2.0 + gg));

+

+    // Early out if ray doesn't intersect atmosphere.

+    float t0, t1;

+    if (!_RayIntersectsSphere(rayOrigin, rayDirection, planetPosition, totalRadius, t0, t1)) {

+      scatteringOpacity = vec3(1.0);

+      return;

+    }

+

+    // Clip the ray between the camera and potentially the planet surface.

+    t0 = max(0.0, t0);

+    t1 = min(maxDist, t1);

+

+    float actualPrimaryStepSize = (t1 - t0) / float(PRIMARY_STEP_COUNT);

+    float virtualPrimaryStepSize = actualPrimaryStepSize * planetScale;

+    float primaryStepPosition = 0.0;

+

+    vec3 accumulatedRayleigh = vec3(0.0);

+    vec3 accumulatedMie = vec3(0.0);

+    vec3 opticalDepth = vec3(0.0);

+

+    // Take N steps along primary ray

+    for (int i = 0; i < PRIMARY_STEP_COUNT; i++) {

+      vec3 currentPrimarySamplePosition = rayOrigin + rayDirection * (

+          primaryStepPosition + actualPrimaryStepSize * 0.5);

+

+      float currentHeight = max(0.0, length(currentPrimarySamplePosition) - planetRadius);

+

+      float currentOpticalDepthRayleigh = exp(-currentHeight / rayleighScale) * virtualPrimaryStepSize;

+      float currentOpticalDepthMie = exp(-currentHeight / mieScale) * virtualPrimaryStepSize;

+

+      // Taken from https://www.shadertoy.com/view/wlBXWK

+      float currentOpticalDepthOzone = (1.0 / cosh((absorptionHeightMax - currentHeight) / absorptionFalloff));

+      currentOpticalDepthOzone *= currentOpticalDepthRayleigh * virtualPrimaryStepSize;

+

+      opticalDepth += vec3(currentOpticalDepthRayleigh, currentOpticalDepthMie, currentOpticalDepthOzone);

+

+      // Sample light ray and accumulate optical depth.

+      vec3 opticalDepthLight = _SampleLightRay(

+          currentPrimarySamplePosition, sunDir,

+          planetScale, planetRadius, totalRadius,

+          rayleighScale, mieScale, absorptionHeightMax, absorptionFalloff);

+

+      vec3 r = (

+          betaRayleigh * (opticalDepth.x + opticalDepthLight.x) +

+          betaMie * (opticalDepth.y + opticalDepthLight.y) +
+          betaAbsorption * (opticalDepth.z + opticalDepthLight.z));

+      vec3 attn = exp(-r);

+

+      accumulatedRayleigh += currentOpticalDepthRayleigh * attn;

+      accumulatedMie += currentOpticalDepthMie * attn;

+

+      primaryStepPosition += actualPrimaryStepSize;

+    }

+

+    scatteringColour = sunIntensity * (phaseRayleigh * betaRayleigh * accumulatedRayleigh + phaseMie * betaMie * accumulatedMie);

+    scatteringOpacity = exp(

+        -(betaMie * opticalDepth.y + betaRayleigh * opticalDepth.x + betaAbsorption * opticalDepth.z));

+  }

+

+  vec3 _ApplyGroundFog(

+      in vec3 rgb,

+      float distToPoint,

+      float height,

+      in vec3 worldSpacePos,

+      in vec3 rayOrigin,

+      in vec3 rayDir,

+      in vec3 sunDir)

+  {

+    vec3 up = normalize(rayOrigin);

+

+    float skyAmt = dot(up, rayDir) * 0.25 + 0.75;

+    skyAmt = saturate(skyAmt);

+    skyAmt *= skyAmt;

+

+    vec3 DARK_BLUE = vec3(0.1, 0.2, 0.3);

+    vec3 LIGHT_BLUE = vec3(0.5, 0.6, 0.7);

+    vec3 DARK_ORANGE = vec3(0.7, 0.4, 0.05);

+    vec3 BLUE = vec3(0.5, 0.6, 0.7);

+    vec3 YELLOW = vec3(1.0, 0.9, 0.7);

+

+    vec3 fogCol = mix(DARK_BLUE, LIGHT_BLUE, skyAmt);

+    float sunAmt = max(dot(rayDir, sunDir), 0.0);

+    fogCol = mix(fogCol, YELLOW, pow(sunAmt, 16.0));

+

+    float be = 0.0025;

+    float fogAmt = (1.0 - exp(-distToPoint * be));

+

+    // Sun

+    sunAmt = 0.5 * saturate(pow(sunAmt, 256.0));

+

+    return mix(rgb, fogCol, fogAmt) + sunAmt * YELLOW;

+  }

+

+  vec3 _ApplySpaceFog(

+      in vec3 rgb,

+      in float distToPoint,

+      in float height,

+      in vec3 worldSpacePos,

+      in vec3 rayOrigin,

+      in vec3 rayDir,

+      in vec3 sunDir)

+  {

+    float atmosphereThickness = (atmosphereRadius - planetRadius);

+

+    float t0 = -1.0;

+    float t1 = -1.0;

+

+    // This is a hack since the world mesh has seams that we haven't fixed yet.

+    if (_RayIntersectsSphere(

+        rayOrigin, rayDir, planetPosition, planetRadius, t0, t1)) {

+      if (distToPoint > t0) {

+        distToPoint = t0;

+        worldSpacePos = rayOrigin + t0 * rayDir;

+      }

+    }

+

+    if (!_RayIntersectsSphere(

+        rayOrigin, rayDir, planetPosition, planetRadius + atmosphereThickness * 5.0, t0, t1)) {

+      return rgb * 0.5;

+    }

+

+    // Figure out a better way to do this

+    float silhouette = saturate((distToPoint - 10000.0) / 10000.0);

+

+    // Glow around planet

+    float scaledDistanceToSurface = 0.0;

+

+    // Calculate the closest point between ray direction and planet. Use a point in front of the

+    // camera to force differences as you get closer to planet.

+    vec3 fakeOrigin = rayOrigin + rayDir * atmosphereThickness;

+    float t = max(0.0, dot(rayDir, planetPosition - fakeOrigin) / dot(rayDir, rayDir));

+    vec3 pb = fakeOrigin + t * rayDir;

+

+    scaledDistanceToSurface = saturate((distance(pb, planetPosition) - planetRadius) / atmosphereThickness);

+    scaledDistanceToSurface = smoothstep(0.0, 1.0, 1.0 - scaledDistanceToSurface);

+    //scaledDistanceToSurface = smoothstep(0.0, 1.0, scaledDistanceToSurface);

+

+    float scatteringFactor = scaledDistanceToSurface * silhouette;

+

+    // Fog on surface

+    t0 = max(0.0, t0);

+    t1 = min(distToPoint, t1);

+

+    vec3 intersectionPoint = rayOrigin + t1 * rayDir;

+    vec3 normalAtIntersection = normalize(intersectionPoint);

+

+    float distFactor = exp(-distToPoint * 0.0005 / (atmosphereThickness));

+    float fresnel = 1.0 - saturate(dot(-rayDir, normalAtIntersection));

+    fresnel = smoothstep(0.0, 1.0, fresnel);

+

+    float extinctionFactor = saturate(fresnel * distFactor) * (1.0 - silhouette);

+

+    // Front/Back Lighting

+    vec3 BLUE = vec3(0.5, 0.6, 0.75);

+    vec3 YELLOW = vec3(1.0, 0.9, 0.7);

+    vec3 RED = vec3(0.035, 0.0, 0.0);

+

+    float NdotL = dot(normalAtIntersection, sunDir);

+    float wrap = 0.5;

+    float NdotL_wrap = max(0.0, (NdotL + wrap) / (1.0 + wrap));

+    float RdotS = max(0.0, dot(rayDir, sunDir));

+    float sunAmount = RdotS;

+

+    vec3 backLightingColour = YELLOW * 0.1;

+    vec3 frontLightingColour = mix(BLUE, YELLOW, pow(sunAmount, 32.0));

+

+    vec3 fogColour = mix(backLightingColour, frontLightingColour, NdotL_wrap);

+

+    extinctionFactor *= NdotL_wrap;

+

+    // Sun

+    float specular = pow((RdotS + 0.5) / (1.0 + 0.5), 64.0);

+

+    fresnel = 1.0 - saturate(dot(-rayDir, normalAtIntersection));

+    fresnel *= fresnel;

+

+    float sunFactor = (length(pb) - planetRadius) / (atmosphereThickness * 5.0);

+    sunFactor = (1.0 - saturate(sunFactor));

+    sunFactor *= sunFactor;

+    sunFactor *= sunFactor;

+    sunFactor *= specular * fresnel;

+

+    vec3 baseColour = mix(rgb, fogColour, extinctionFactor);

+    vec3 litColour = baseColour + _SoftLight(fogColour * scatteringFactor + YELLOW * sunFactor, baseColour);

+    vec3 blendedColour = mix(baseColour, fogColour, scatteringFactor);

+    blendedColour += blendedColour + _SoftLight(YELLOW * sunFactor, blendedColour);

+    return mix(litColour, blendedColour, scaledDistanceToSurface * 0.25);

+  }

+

+  vec3 _ApplyFog(

+    in vec3 rgb,

+    in float distToPoint,

+    in float height,

+    in vec3 worldSpacePos,

+    in vec3 rayOrigin,

+    in vec3 rayDir,

+    in vec3 sunDir)

+  {

+    float distToPlanet = max(0.0, length(rayOrigin) - planetRadius);

+    float atmosphereThickness = (atmosphereRadius - planetRadius);

+

+    vec3 groundCol = _ApplyGroundFog(

+      rgb, distToPoint, height, worldSpacePos, rayOrigin, rayDir, sunDir);

+    vec3 spaceCol = _ApplySpaceFog(

+      rgb, distToPoint, height, worldSpacePos, rayOrigin, rayDir, sunDir);

+

+    float blendFactor = saturate(distToPlanet / (atmosphereThickness * 0.5));

+

+    blendFactor = smoothstep(0.0, 1.0, blendFactor);

+    blendFactor = smoothstep(0.0, 1.0, blendFactor);

+

+    return mix(groundCol, spaceCol, blendFactor);

+  }

+

+  void main() {

+    float z = texture2D(tDepth, vUv).x;

+    vec3 posWS = _ScreenToWorld(vec3(vUv, z));

+    float dist = length(posWS - cameraPosition);

+    float height = max(0.0, length(cameraPosition) - planetRadius);

+    vec3 cameraDirection = normalize(posWS - cameraPosition);

+

+

+    vec3 diffuse = texture2D(tDiffuse, vUv).xyz;

+    vec3 lightDir = normalize(vec3(1, 1, -1));

+

+    // diffuse = _ApplyFog(diffuse, dist, height, posWS, cameraPosition, cameraDirection, lightDir);

+

+    vec3 scatteringColour = vec3(0.0);

+    vec3 scatteringOpacity = vec3(1.0, 1.0, 1.0);

+    _ComputeScattering(

+        posWS, cameraDirection, cameraPosition,

+        lightDir, scatteringColour, scatteringOpacity

+    );

+

+    // diffuse = diffuse * scatteringOpacity + scatteringColour;

+    // diffuse = ACESFilmicToneMapping(diffuse);

+    diffuse = pow(diffuse, vec3(1.0 / 2.0));

+

+    gl_FragColor.rgb = diffuse;

+    gl_FragColor.a = 1.0;

+  }

+  `;

+
+

+  const _Shader = {

+    uniforms: {

+      "tDiffuse": { value: null },

+      "tDepth": { value: null },

+      "cameraNear": { value: 0.0 },

+      "cameraFar": { value: 0.0 },

+    },

+    vertexShader: _VS,

+    fragmentShader: _PS,

+  };

+

+  return {

+    Shader: _Shader,

+    VS: _VS,

+    PS: _PS,

+  };

+})();

+ 479 - 0
src/simplex-noise.js
View File

@@ -0,0 +1,479 @@

+/*

+ * A fast javascript implementation of simplex noise by Jonas Wagner

+

+Based on a speed-improved simplex noise algorithm for 2D, 3D and 4D in Java.

+Which is based on example code by Stefan Gustavson ([email protected]).

+With Optimisations by Peter Eastman ([email protected]).

+Better rank ordering method by Stefan Gustavson in 2012.

+

+

+ Copyright (c) 2018 Jonas Wagner

+

+ Permission is hereby granted, free of charge, to any person obtaining a copy

+ of this software and associated documentation files (the "Software"), to deal

+ in the Software without restriction, including without limitation the rights

+ to use, copy, modify, merge, publish, distribute, sublicense, and/or sell

+ copies of the Software, and to permit persons to whom the Software is

+ furnished to do so, subject to the following conditions:

+

+ The above copyright notice and this permission notice shall be included in all

+ copies or substantial portions of the Software.

+

+ THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR

+ IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,

+ FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE

+ AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER

+ LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,

+ OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE

+ SOFTWARE.

+ */

+// (function() {

+

+export const simplex = (function() {

+

+  'use strict';

+

+  var F2 = 0.5 * (Math.sqrt(3.0) - 1.0);

+  var G2 = (3.0 - Math.sqrt(3.0)) / 6.0;

+  var F3 = 1.0 / 3.0;

+  var G3 = 1.0 / 6.0;

+  var F4 = (Math.sqrt(5.0) - 1.0) / 4.0;

+  var G4 = (5.0 - Math.sqrt(5.0)) / 20.0;

+

+  function SimplexNoise(randomOrSeed) {

+    var random;

+    if (typeof randomOrSeed == 'function') {

+      random = randomOrSeed;

+    }

+    else if (randomOrSeed) {

+      random = alea(randomOrSeed);

+    } else {

+      random = Math.random;

+    }

+    this.p = buildPermutationTable(random);

+    this.perm = new Uint8Array(512);

+    this.permMod12 = new Uint8Array(512);

+    for (var i = 0; i < 512; i++) {

+      this.perm[i] = this.p[i & 255];

+      this.permMod12[i] = this.perm[i] % 12;

+    }

+

+  }

+  SimplexNoise.prototype = {

+    grad3: new Float32Array([1, 1, 0,

+      -1, 1, 0,

+      1, -1, 0,

+

+      -1, -1, 0,

+      1, 0, 1,

+      -1, 0, 1,

+

+      1, 0, -1,

+      -1, 0, -1,

+      0, 1, 1,

+

+      0, -1, 1,

+      0, 1, -1,

+      0, -1, -1]),

+    grad4: new Float32Array([0, 1, 1, 1, 0, 1, 1, -1, 0, 1, -1, 1, 0, 1, -1, -1,

+      0, -1, 1, 1, 0, -1, 1, -1, 0, -1, -1, 1, 0, -1, -1, -1,

+      1, 0, 1, 1, 1, 0, 1, -1, 1, 0, -1, 1, 1, 0, -1, -1,

+      -1, 0, 1, 1, -1, 0, 1, -1, -1, 0, -1, 1, -1, 0, -1, -1,

+      1, 1, 0, 1, 1, 1, 0, -1, 1, -1, 0, 1, 1, -1, 0, -1,

+      -1, 1, 0, 1, -1, 1, 0, -1, -1, -1, 0, 1, -1, -1, 0, -1,

+      1, 1, 1, 0, 1, 1, -1, 0, 1, -1, 1, 0, 1, -1, -1, 0,

+      -1, 1, 1, 0, -1, 1, -1, 0, -1, -1, 1, 0, -1, -1, -1, 0]),

+    noise2D: function(xin, yin) {

+      var permMod12 = this.permMod12;

+      var perm = this.perm;

+      var grad3 = this.grad3;

+      var n0 = 0; // Noise contributions from the three corners

+      var n1 = 0;

+      var n2 = 0;

+      // Skew the input space to determine which simplex cell we're in

+      var s = (xin + yin) * F2; // Hairy factor for 2D

+      var i = Math.floor(xin + s);

+      var j = Math.floor(yin + s);

+      var t = (i + j) * G2;

+      var X0 = i - t; // Unskew the cell origin back to (x,y) space

+      var Y0 = j - t;

+      var x0 = xin - X0; // The x,y distances from the cell origin

+      var y0 = yin - Y0;

+      // For the 2D case, the simplex shape is an equilateral triangle.

+      // Determine which simplex we are in.

+      var i1, j1; // Offsets for second (middle) corner of simplex in (i,j) coords

+      if (x0 > y0) {

+        i1 = 1;

+        j1 = 0;

+      } // lower triangle, XY order: (0,0)->(1,0)->(1,1)

+      else {

+        i1 = 0;

+        j1 = 1;

+      } // upper triangle, YX order: (0,0)->(0,1)->(1,1)

+      // A step of (1,0) in (i,j) means a step of (1-c,-c) in (x,y), and

+      // a step of (0,1) in (i,j) means a step of (-c,1-c) in (x,y), where

+      // c = (3-sqrt(3))/6

+      var x1 = x0 - i1 + G2; // Offsets for middle corner in (x,y) unskewed coords

+      var y1 = y0 - j1 + G2;

+      var x2 = x0 - 1.0 + 2.0 * G2; // Offsets for last corner in (x,y) unskewed coords

+      var y2 = y0 - 1.0 + 2.0 * G2;

+      // Work out the hashed gradient indices of the three simplex corners

+      var ii = i & 255;

+      var jj = j & 255;

+      // Calculate the contribution from the three corners

+      var t0 = 0.5 - x0 * x0 - y0 * y0;

+      if (t0 >= 0) {

+        var gi0 = permMod12[ii + perm[jj]] * 3;

+        t0 *= t0;

+        n0 = t0 * t0 * (grad3[gi0] * x0 + grad3[gi0 + 1] * y0); // (x,y) of grad3 used for 2D gradient

+      }

+      var t1 = 0.5 - x1 * x1 - y1 * y1;

+      if (t1 >= 0) {

+        var gi1 = permMod12[ii + i1 + perm[jj + j1]] * 3;

+        t1 *= t1;

+        n1 = t1 * t1 * (grad3[gi1] * x1 + grad3[gi1 + 1] * y1);

+      }

+      var t2 = 0.5 - x2 * x2 - y2 * y2;

+      if (t2 >= 0) {

+        var gi2 = permMod12[ii + 1 + perm[jj + 1]] * 3;

+        t2 *= t2;

+        n2 = t2 * t2 * (grad3[gi2] * x2 + grad3[gi2 + 1] * y2);

+      }

+      // Add contributions from each corner to get the final noise value.

+      // The result is scaled to return values in the interval [-1,1].

+      return 70.0 * (n0 + n1 + n2);

+    },

+    // 3D simplex noise

+    noise3D: function(xin, yin, zin) {

+      var permMod12 = this.permMod12;

+      var perm = this.perm;

+      var grad3 = this.grad3;

+      var n0, n1, n2, n3; // Noise contributions from the four corners

+      // Skew the input space to determine which simplex cell we're in

+      var s = (xin + yin + zin) * F3; // Very nice and simple skew factor for 3D

+      var i = Math.floor(xin + s);

+      var j = Math.floor(yin + s);

+      var k = Math.floor(zin + s);

+      var t = (i + j + k) * G3;

+      var X0 = i - t; // Unskew the cell origin back to (x,y,z) space

+      var Y0 = j - t;

+      var Z0 = k - t;

+      var x0 = xin - X0; // The x,y,z distances from the cell origin

+      var y0 = yin - Y0;

+      var z0 = zin - Z0;

+      // For the 3D case, the simplex shape is a slightly irregular tetrahedron.

+      // Determine which simplex we are in.

+      var i1, j1, k1; // Offsets for second corner of simplex in (i,j,k) coords

+      var i2, j2, k2; // Offsets for third corner of simplex in (i,j,k) coords

+      if (x0 >= y0) {

+        if (y0 >= z0) {

+          i1 = 1;

+          j1 = 0;

+          k1 = 0;

+          i2 = 1;

+          j2 = 1;

+          k2 = 0;

+        } // X Y Z order

+        else if (x0 >= z0) {

+          i1 = 1;

+          j1 = 0;

+          k1 = 0;

+          i2 = 1;

+          j2 = 0;

+          k2 = 1;

+        } // X Z Y order

+        else {

+          i1 = 0;

+          j1 = 0;

+          k1 = 1;

+          i2 = 1;

+          j2 = 0;

+          k2 = 1;

+        } // Z X Y order

+      }

+      else { // x0<y0

+        if (y0 < z0) {

+          i1 = 0;

+          j1 = 0;

+          k1 = 1;

+          i2 = 0;

+          j2 = 1;

+          k2 = 1;

+        } // Z Y X order

+        else if (x0 < z0) {

+          i1 = 0;

+          j1 = 1;

+          k1 = 0;

+          i2 = 0;

+          j2 = 1;

+          k2 = 1;

+        } // Y Z X order

+        else {

+          i1 = 0;

+          j1 = 1;

+          k1 = 0;

+          i2 = 1;

+          j2 = 1;

+          k2 = 0;

+        } // Y X Z order

+      }

+      // A step of (1,0,0) in (i,j,k) means a step of (1-c,-c,-c) in (x,y,z),

+      // a step of (0,1,0) in (i,j,k) means a step of (-c,1-c,-c) in (x,y,z), and

+      // a step of (0,0,1) in (i,j,k) means a step of (-c,-c,1-c) in (x,y,z), where

+      // c = 1/6.

+      var x1 = x0 - i1 + G3; // Offsets for second corner in (x,y,z) coords

+      var y1 = y0 - j1 + G3;

+      var z1 = z0 - k1 + G3;

+      var x2 = x0 - i2 + 2.0 * G3; // Offsets for third corner in (x,y,z) coords

+      var y2 = y0 - j2 + 2.0 * G3;

+      var z2 = z0 - k2 + 2.0 * G3;

+      var x3 = x0 - 1.0 + 3.0 * G3; // Offsets for last corner in (x,y,z) coords

+      var y3 = y0 - 1.0 + 3.0 * G3;

+      var z3 = z0 - 1.0 + 3.0 * G3;

+      // Work out the hashed gradient indices of the four simplex corners

+      var ii = i & 255;

+      var jj = j & 255;

+      var kk = k & 255;

+      // Calculate the contribution from the four corners

+      var t0 = 0.6 - x0 * x0 - y0 * y0 - z0 * z0;

+      if (t0 < 0) n0 = 0.0;

+      else {

+        var gi0 = permMod12[ii + perm[jj + perm[kk]]] * 3;

+        t0 *= t0;

+        n0 = t0 * t0 * (grad3[gi0] * x0 + grad3[gi0 + 1] * y0 + grad3[gi0 + 2] * z0);

+      }

+      var t1 = 0.6 - x1 * x1 - y1 * y1 - z1 * z1;

+      if (t1 < 0) n1 = 0.0;

+      else {

+        var gi1 = permMod12[ii + i1 + perm[jj + j1 + perm[kk + k1]]] * 3;

+        t1 *= t1;

+        n1 = t1 * t1 * (grad3[gi1] * x1 + grad3[gi1 + 1] * y1 + grad3[gi1 + 2] * z1);

+      }

+      var t2 = 0.6 - x2 * x2 - y2 * y2 - z2 * z2;

+      if (t2 < 0) n2 = 0.0;

+      else {

+        var gi2 = permMod12[ii + i2 + perm[jj + j2 + perm[kk + k2]]] * 3;

+        t2 *= t2;

+        n2 = t2 * t2 * (grad3[gi2] * x2 + grad3[gi2 + 1] * y2 + grad3[gi2 + 2] * z2);

+      }

+      var t3 = 0.6 - x3 * x3 - y3 * y3 - z3 * z3;

+      if (t3 < 0) n3 = 0.0;

+      else {

+        var gi3 = permMod12[ii + 1 + perm[jj + 1 + perm[kk + 1]]] * 3;

+        t3 *= t3;

+        n3 = t3 * t3 * (grad3[gi3] * x3 + grad3[gi3 + 1] * y3 + grad3[gi3 + 2] * z3);

+      }

+      // Add contributions from each corner to get the final noise value.

+      // The result is scaled to stay just inside [-1,1]

+      return 32.0 * (n0 + n1 + n2 + n3);

+    },

+    // 4D simplex noise, better simplex rank ordering method 2012-03-09

+    noise4D: function(x, y, z, w) {

+      var perm = this.perm;

+      var grad4 = this.grad4;

+

+      var n0, n1, n2, n3, n4; // Noise contributions from the five corners

+      // Skew the (x,y,z,w) space to determine which cell of 24 simplices we're in

+      var s = (x + y + z + w) * F4; // Factor for 4D skewing

+      var i = Math.floor(x + s);

+      var j = Math.floor(y + s);

+      var k = Math.floor(z + s);

+      var l = Math.floor(w + s);

+      var t = (i + j + k + l) * G4; // Factor for 4D unskewing

+      var X0 = i - t; // Unskew the cell origin back to (x,y,z,w) space

+      var Y0 = j - t;

+      var Z0 = k - t;

+      var W0 = l - t;

+      var x0 = x - X0; // The x,y,z,w distances from the cell origin

+      var y0 = y - Y0;

+      var z0 = z - Z0;

+      var w0 = w - W0;

+      // For the 4D case, the simplex is a 4D shape I won't even try to describe.

+      // To find out which of the 24 possible simplices we're in, we need to

+      // determine the magnitude ordering of x0, y0, z0 and w0.

+      // Six pair-wise comparisons are performed between each possible pair

+      // of the four coordinates, and the results are used to rank the numbers.

+      var rankx = 0;

+      var ranky = 0;

+      var rankz = 0;

+      var rankw = 0;

+      if (x0 > y0) rankx++;

+      else ranky++;

+      if (x0 > z0) rankx++;

+      else rankz++;

+      if (x0 > w0) rankx++;

+      else rankw++;

+      if (y0 > z0) ranky++;

+      else rankz++;

+      if (y0 > w0) ranky++;

+      else rankw++;

+      if (z0 > w0) rankz++;

+      else rankw++;

+      var i1, j1, k1, l1; // The integer offsets for the second simplex corner

+      var i2, j2, k2, l2; // The integer offsets for the third simplex corner

+      var i3, j3, k3, l3; // The integer offsets for the fourth simplex corner

+      // simplex[c] is a 4-vector with the numbers 0, 1, 2 and 3 in some order.

+      // Many values of c will never occur, since e.g. x>y>z>w makes x<z, y<w and x<w

+      // impossible. Only the 24 indices which have non-zero entries make any sense.

+      // We use a thresholding to set the coordinates in turn from the largest magnitude.

+      // Rank 3 denotes the largest coordinate.

+      i1 = rankx >= 3 ? 1 : 0;

+      j1 = ranky >= 3 ? 1 : 0;

+      k1 = rankz >= 3 ? 1 : 0;

+      l1 = rankw >= 3 ? 1 : 0;

+      // Rank 2 denotes the second largest coordinate.

+      i2 = rankx >= 2 ? 1 : 0;

+      j2 = ranky >= 2 ? 1 : 0;

+      k2 = rankz >= 2 ? 1 : 0;

+      l2 = rankw >= 2 ? 1 : 0;

+      // Rank 1 denotes the second smallest coordinate.

+      i3 = rankx >= 1 ? 1 : 0;

+      j3 = ranky >= 1 ? 1 : 0;

+      k3 = rankz >= 1 ? 1 : 0;

+      l3 = rankw >= 1 ? 1 : 0;

+      // The fifth corner has all coordinate offsets = 1, so no need to compute that.

+      var x1 = x0 - i1 + G4; // Offsets for second corner in (x,y,z,w) coords

+      var y1 = y0 - j1 + G4;

+      var z1 = z0 - k1 + G4;

+      var w1 = w0 - l1 + G4;

+      var x2 = x0 - i2 + 2.0 * G4; // Offsets for third corner in (x,y,z,w) coords

+      var y2 = y0 - j2 + 2.0 * G4;

+      var z2 = z0 - k2 + 2.0 * G4;

+      var w2 = w0 - l2 + 2.0 * G4;

+      var x3 = x0 - i3 + 3.0 * G4; // Offsets for fourth corner in (x,y,z,w) coords

+      var y3 = y0 - j3 + 3.0 * G4;

+      var z3 = z0 - k3 + 3.0 * G4;

+      var w3 = w0 - l3 + 3.0 * G4;

+      var x4 = x0 - 1.0 + 4.0 * G4; // Offsets for last corner in (x,y,z,w) coords

+      var y4 = y0 - 1.0 + 4.0 * G4;

+      var z4 = z0 - 1.0 + 4.0 * G4;

+      var w4 = w0 - 1.0 + 4.0 * G4;

+      // Work out the hashed gradient indices of the five simplex corners

+      var ii = i & 255;

+      var jj = j & 255;

+      var kk = k & 255;

+      var ll = l & 255;

+      // Calculate the contribution from the five corners

+      var t0 = 0.6 - x0 * x0 - y0 * y0 - z0 * z0 - w0 * w0;

+      if (t0 < 0) n0 = 0.0;

+      else {

+        var gi0 = (perm[ii + perm[jj + perm[kk + perm[ll]]]] % 32) * 4;

+        t0 *= t0;

+        n0 = t0 * t0 * (grad4[gi0] * x0 + grad4[gi0 + 1] * y0 + grad4[gi0 + 2] * z0 + grad4[gi0 + 3] * w0);

+      }

+      var t1 = 0.6 - x1 * x1 - y1 * y1 - z1 * z1 - w1 * w1;

+      if (t1 < 0) n1 = 0.0;

+      else {

+        var gi1 = (perm[ii + i1 + perm[jj + j1 + perm[kk + k1 + perm[ll + l1]]]] % 32) * 4;

+        t1 *= t1;

+        n1 = t1 * t1 * (grad4[gi1] * x1 + grad4[gi1 + 1] * y1 + grad4[gi1 + 2] * z1 + grad4[gi1 + 3] * w1);

+      }

+      var t2 = 0.6 - x2 * x2 - y2 * y2 - z2 * z2 - w2 * w2;

+      if (t2 < 0) n2 = 0.0;

+      else {

+        var gi2 = (perm[ii + i2 + perm[jj + j2 + perm[kk + k2 + perm[ll + l2]]]] % 32) * 4;

+        t2 *= t2;

+        n2 = t2 * t2 * (grad4[gi2] * x2 + grad4[gi2 + 1] * y2 + grad4[gi2 + 2] * z2 + grad4[gi2 + 3] * w2);

+      }

+      var t3 = 0.6 - x3 * x3 - y3 * y3 - z3 * z3 - w3 * w3;

+      if (t3 < 0) n3 = 0.0;

+      else {

+        var gi3 = (perm[ii + i3 + perm[jj + j3 + perm[kk + k3 + perm[ll + l3]]]] % 32) * 4;

+        t3 *= t3;

+        n3 = t3 * t3 * (grad4[gi3] * x3 + grad4[gi3 + 1] * y3 + grad4[gi3 + 2] * z3 + grad4[gi3 + 3] * w3);

+      }

+      var t4 = 0.6 - x4 * x4 - y4 * y4 - z4 * z4 - w4 * w4;

+      if (t4 < 0) n4 = 0.0;

+      else {

+        var gi4 = (perm[ii + 1 + perm[jj + 1 + perm[kk + 1 + perm[ll + 1]]]] % 32) * 4;

+        t4 *= t4;

+        n4 = t4 * t4 * (grad4[gi4] * x4 + grad4[gi4 + 1] * y4 + grad4[gi4 + 2] * z4 + grad4[gi4 + 3] * w4);

+      }

+      // Sum up and scale the result to cover the range [-1,1]

+      return 27.0 * (n0 + n1 + n2 + n3 + n4);

+    }

+  };

+

+  function buildPermutationTable(random) {

+    var i;

+    var p = new Uint8Array(256);

+    for (i = 0; i < 256; i++) {

+      p[i] = i;

+    }

+    for (i = 0; i < 255; i++) {

+      var r = i + ~~(random() * (256 - i));

+      var aux = p[i];

+      p[i] = p[r];

+      p[r] = aux;

+    }

+    return p;

+  }

+  SimplexNoise._buildPermutationTable = buildPermutationTable;

+

+  function alea() {

+    // Johannes Baagøe <[email protected]>, 2010

+    var s0 = 0;

+    var s1 = 0;

+    var s2 = 0;

+    var c = 1;

+

+    var mash = masher();

+    s0 = mash(' ');

+    s1 = mash(' ');

+    s2 = mash(' ');

+

+    for (var i = 0; i < arguments.length; i++) {

+      s0 -= mash(arguments[i]);

+      if (s0 < 0) {

+        s0 += 1;

+      }

+      s1 -= mash(arguments[i]);

+      if (s1 < 0) {

+        s1 += 1;

+      }

+      s2 -= mash(arguments[i]);

+      if (s2 < 0) {

+        s2 += 1;

+      }

+    }

+    mash = null;

+    return function() {

+      var t = 2091639 * s0 + c * 2.3283064365386963e-10; // 2^-32

+      s0 = s1;

+      s1 = s2;

+      return s2 = t - (c = t | 0);

+    };

+  }

+  function masher() {

+    var n = 0xefc8249d;

+    return function(data) {

+      data = data.toString();

+      for (var i = 0; i < data.length; i++) {

+        n += data.charCodeAt(i);

+        var h = 0.02519603282416938 * n;

+        n = h >>> 0;

+        h -= n;

+        h *= n;

+        n = h >>> 0;

+        h -= n;

+        n += h * 0x100000000; // 2^32

+      }

+      return (n >>> 0) * 2.3283064365386963e-10; // 2^-32

+    };

+  }

+

+  // // amd

+  // if (typeof define !== 'undefined' && define.amd) define(function() {return SimplexNoise;});

+  // // common js

+  // if (typeof exports !== 'undefined') exports.SimplexNoise = SimplexNoise;

+  // // browser

+  // else if (typeof window !== 'undefined') window.SimplexNoise = SimplexNoise;

+  // // nodejs

+  // if (typeof module !== 'undefined') {

+  //   module.exports = SimplexNoise;

+  // }

+  return {

+    SimplexNoise: SimplexNoise

+  };

+

+})();

+ 115 - 0
src/sky.js
View File

@@ -0,0 +1,115 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+import {Sky} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/objects/Sky.js';

+import {Water} from 'https://cdn.jsdelivr.net/npm/[email protected]/examples/jsm/objects/Water.js';

+

+

+export const sky = (function() {

+

+  class TerrainSky {

+    constructor(params) {

+      this._params = params;

+      this._Init(params);

+    }

+

+    _Init(params) {

+      const waterGeometry = new THREE.PlaneBufferGeometry(10000, 10000, 100, 100);

+

+      this._water = new Water(

+        waterGeometry,

+        {

+          textureWidth: 2048,

+          textureHeight: 2048,

+          waterNormals: new THREE.TextureLoader().load( 'resources/waternormals.jpg', function ( texture ) {

+            texture.wrapS = texture.wrapT = THREE.RepeatWrapping;

+          } ),

+          alpha: 0.5,

+          sunDirection: new THREE.Vector3(1, 0, 0),

+          sunColor: 0xffffff,

+          waterColor: 0x001e0f,

+          distortionScale: 0.0,

+          fog: undefined

+        }

+      );

+      // this._water.rotation.x = - Math.PI / 2;

+      // this._water.position.y = 4;

+

+      this._sky = new Sky();

+      this._sky.scale.setScalar(10000);

+

+      this._group = new THREE.Group();

+      //this._group.add(this._water);

+      this._group.add(this._sky);

+

+      params.scene.add(this._group);

+

+      params.guiParams.sky = {

+        turbidity: 10.0,

+        rayleigh: 2,

+        mieCoefficient: 0.005,

+        mieDirectionalG: 0.8,

+        luminance: 1,

+      };

+

+      params.guiParams.sun = {

+        inclination: 0.31,

+        azimuth: 0.25,

+      };

+

+      const onShaderChange = () => {

+        for (let k in params.guiParams.sky) {

+          this._sky.material.uniforms[k].value = params.guiParams.sky[k];

+        }

+        for (let k in params.guiParams.general) {

+          this._sky.material.uniforms[k].value = params.guiParams.general[k];

+        }

+      };

+

+      const onSunChange = () => {

+        var theta = Math.PI * (params.guiParams.sun.inclination - 0.5);

+        var phi = 2 * Math.PI * (params.guiParams.sun.azimuth - 0.5);

+

+        const sunPosition = new THREE.Vector3();

+        sunPosition.x = Math.cos(phi);

+        sunPosition.y = Math.sin(phi) * Math.sin(theta);

+        sunPosition.z = Math.sin(phi) * Math.cos(theta);

+

+        this._sky.material.uniforms['sunPosition'].value.copy(sunPosition);

+        this._water.material.uniforms['sunDirection'].value.copy(sunPosition.normalize());

+      };

+

+      const skyRollup = params.gui.addFolder('Sky');

+      skyRollup.add(params.guiParams.sky, "turbidity", 0.1, 30.0).onChange(

+          onShaderChange);

+      skyRollup.add(params.guiParams.sky, "rayleigh", 0.1, 4.0).onChange(

+          onShaderChange);

+      skyRollup.add(params.guiParams.sky, "mieCoefficient", 0.0001, 0.1).onChange(

+          onShaderChange);

+      skyRollup.add(params.guiParams.sky, "mieDirectionalG", 0.0, 1.0).onChange(

+          onShaderChange);

+      skyRollup.add(params.guiParams.sky, "luminance", 0.0, 2.0).onChange(

+          onShaderChange);

+

+      const sunRollup = params.gui.addFolder('Sun');

+      sunRollup.add(params.guiParams.sun, "inclination", 0.0, 1.0).onChange(

+          onSunChange);

+      sunRollup.add(params.guiParams.sun, "azimuth", 0.0, 1.0).onChange(

+          onSunChange);

+

+      onShaderChange();

+      onSunChange();

+    }

+

+    Update(timeInSeconds) {

+      this._water.material.uniforms['time'].value += timeInSeconds;

+

+      this._group.position.x = this._params.camera.position.x;

+      this._group.position.z = this._params.camera.position.z;

+    }

+  }

+

+

+  return {

+    TerrainSky: TerrainSky

+  }

+})();

+ 76 - 0
src/spline.js
View File

@@ -0,0 +1,76 @@

+export const spline = (function() {

+

+  class _CubicHermiteSpline {

+    constructor(lerp) {

+      this._points = [];

+      this._lerp = lerp;

+    }

+

+    AddPoint(t, d) {

+      this._points.push([t, d]);

+    }

+

+    Get(t) {

+      let p1 = 0;

+

+      for (let i = 0; i < this._points.length; i++) {

+        if (this._points[i][0] >= t) {

+          break;

+        }

+        p1 = i;

+      }

+

+      const p0 = Math.max(0, p1 - 1);

+      const p2 = Math.min(this._points.length - 1, p1 + 1);

+      const p3 = Math.min(this._points.length - 1, p1 + 2);

+

+      if (p1 == p2) {

+        return this._points[p1][1];

+      }

+

+      return this._lerp(

+          (t - this._points[p1][0]) / (

+              this._points[p2][0] - this._points[p1][0]),

+          this._points[p0][1], this._points[p1][1],

+          this._points[p2][1], this._points[p3][1]);

+    }

+  };

+

+  class _LinearSpline {

+    constructor(lerp) {

+      this._points = [];

+      this._lerp = lerp;

+    }

+

+    AddPoint(t, d) {

+      this._points.push([t, d]);

+    }

+

+    Get(t) {

+      let p1 = 0;

+

+      for (let i = 0; i < this._points.length; i++) {

+        if (this._points[i][0] >= t) {

+          break;

+        }

+        p1 = i;

+      }

+

+      const p2 = Math.min(this._points.length - 1, p1 + 1);

+

+      if (p1 == p2) {

+        return this._points[p1][1];

+      }

+

+      return this._lerp(

+          (t - this._points[p1][0]) / (

+              this._points[p2][0] - this._points[p1][0]),

+          this._points[p1][1], this._points[p2][1]);

+    }

+  }

+

+  return {

+    CubicHermiteSpline: _CubicHermiteSpline,

+    LinearSpline: _LinearSpline,

+  };

+})();

+ 644 - 0
src/terrain-builder-threaded-worker.js
View File

@@ -0,0 +1,644 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+import {noise} from './noise.js';

+import {texture_splatter} from './texture-splatter.js' ;

+import {math} from './math.js';

+

+

+const _D = new THREE.Vector3();

+const _D1 = new THREE.Vector3();

+const _D2 = new THREE.Vector3();

+const _P = new THREE.Vector3();

+const _P1 = new THREE.Vector3();

+const _P2 = new THREE.Vector3();

+const _P3 = new THREE.Vector3();

+const _H = new THREE.Vector3();

+const _W = new THREE.Vector3();

+const _S = new THREE.Vector3();

+const _C = new THREE.Vector3();

+

+const _N = new THREE.Vector3();

+const _N1 = new THREE.Vector3();

+const _N2 = new THREE.Vector3();

+const _N3 = new THREE.Vector3();

+

+

+class _TerrainBuilderThreadedWorker {

+  constructor() {

+  }

+

+  Init(params) {

+    this.cachedParams_ = {...params};

+    this.params_ = params;

+    this.params_.offset = new THREE.Vector3(...params.offset);

+    this.params_.origin = new THREE.Vector3(...params.origin);

+    this.params_.noise = new noise.Noise(params.noiseParams);

+    this.params_.heightGenerators = [

+        new texture_splatter.HeightGenerator(

+            this.params_.noise, params.offset,

+            params.heightGeneratorsParams.min, params.heightGeneratorsParams.max)

+    ];

+

+    this.params_.biomeGenerator = new noise.Noise(params.biomesParams);

+    this.params_.colourNoise = new noise.Noise(params.colourNoiseParams);

+    this.params_.colourGenerator = new texture_splatter.TextureSplatter(

+        {

+          biomeGenerator: this.params_.biomeGenerator,

+          colourNoise: this.params_.colourNoise

+        });

+  }

+

+  _GenerateHeight(v) {

+    return this.params_.heightGenerators[0].Get(v.x, v.y, v.z)[0];

+  }

+

+  GenerateNormals_(positions, indices) {

+    const normals = new Array(positions.length).fill(0.0);

+    for (let i = 0, n = indices.length; i < n; i+= 3) {

+      const i1 = indices[i] * 3;

+      const i2 = indices[i+1] * 3;

+      const i3 = indices[i+2] * 3;

+

+      _N1.fromArray(positions, i1);

+      _N2.fromArray(positions, i2);

+      _N3.fromArray(positions, i3);

+

+      _D1.subVectors(_N3, _N2);

+      _D2.subVectors(_N1, _N2);

+      _D1.cross(_D2);

+

+      normals[i1] += _D1.x;

+      normals[i2] += _D1.x;

+      normals[i3] += _D1.x;

+

+      normals[i1+1] += _D1.y;

+      normals[i2+1] += _D1.y;

+      normals[i3+1] += _D1.y;

+

+      normals[i1+2] += _D1.z;

+      normals[i2+2] += _D1.z;

+      normals[i3+2] += _D1.z;

+    }

+    return normals;

+  }

+

+  GenerateIndices_() {

+    const resolution = this.params_.resolution + 2;

+    const indices = [];

+    for (let i = 0; i < resolution; i++) {

+      for (let j = 0; j < resolution; j++) {

+        indices.push(

+            i * (resolution + 1) + j,

+            (i + 1) * (resolution + 1) + j + 1,

+            i * (resolution + 1) + j + 1);

+        indices.push(

+            (i + 1) * (resolution + 1) + j,

+            (i + 1) * (resolution + 1) + j + 1,

+            i * (resolution + 1) + j);

+      }

+    }

+    return indices;

+  }

+

+  _ComputeNormal_CentralDifference(xp, yp, stepSize) {

+    const localToWorld = this.params_.worldMatrix;

+    const radius = this.params_.radius;

+    const offset = this.params_.offset;

+    const width = this.params_.width;

+    const half = width / 2;

+    const resolution = this.params_.resolution + 2;

+    const effectiveResolution = resolution - 2;

+

+    // Compute position

+    const _ComputeWSPosition = (xpos, ypos) => {

+      const xp = width * xpos;

+      const yp = width * ypos;

+      _P.set(xp - half, yp - half, radius);

+      _P.add(offset);

+      _P.normalize();

+      _D.copy(_P);

+      _D.transformDirection(localToWorld);

+

+      _P.multiplyScalar(radius);

+      _P.z -= radius;

+      _P.applyMatrix4(localToWorld);

+

+      // Purturb height along z-vector

+      const height = this._GenerateHeight(_P);

+      _H.copy(_D);

+      _H.multiplyScalar(height);

+      _P.add(_H);

+

+      return _P;

+    };

+

+    const _ComputeWSPositionFromWS = (pos) => {

+      _P.copy(pos);

+      _P.normalize();

+      _D.copy(_P);

+      _P.multiplyScalar(radius);

+

+      // Purturb height along z-vector

+      const height = this._GenerateHeight(_P);

+      _H.copy(_D);

+      _H.multiplyScalar(height);

+      _P.add(_H);

+

+      return _P;

+    };

+

+    const _SphericalToCartesian = (theta, phi) => {

+      const x = (Math.sin(theta) * Math.cos(phi));

+      const y = (Math.sin(theta) * Math.sin(phi));

+      const z = (Math.cos(theta));

+      _P.set(x, y, z);

+      _P.multiplyScalar(radius);

+      const height = this._GenerateHeight(_P);

+      _P.set(x, y, z);

+      _P.multiplyScalar(height + radius);

+      return _P;

+    };

+

+    //

+    _P3.copy(_ComputeWSPosition(xp, yp));

+    _D.copy(_P3);

+    _D.normalize();

+

+    const phi = Math.atan2(_D.y, _D.x);

+    const theta = Math.atan2((_D.x * _D.x + _D.y * _D.y) ** 0.5, _D.z);

+

+    _P1.copy(_ComputeWSPosition(xp, yp));

+    _P2.copy(_SphericalToCartesian(theta, phi));

+

+    // Fixme - Fixed size right now, calculate an appropriate delta

+    const delta = 0.001;

+

+    _P1.copy(_SphericalToCartesian(theta - delta, phi));

+    _P2.copy(_SphericalToCartesian(theta + delta, phi));

+    _D1.subVectors(_P1, _P2);

+    _D1.normalize();

+

+    _P1.copy(_SphericalToCartesian(theta, phi - delta));

+    _P2.copy(_SphericalToCartesian(theta, phi + delta));

+    _D2.subVectors(_P1, _P2);

+    _D2.normalize();

+

+
+    _P1.copy(_D1);

+    _P1.multiplyScalar(-0.5*width*stepSize/effectiveResolution);

+    _P2.copy(_P1);

+    _P2.multiplyScalar(-1)

+    _P1.add(_P3);

+    _P2.add(_P3);

+    _P1.copy(_ComputeWSPositionFromWS(_P1));

+    _P2.copy(_ComputeWSPositionFromWS(_P2));

+    _D1.subVectors(_P1, _P2);

+    _D1.normalize();

+

+    _P1.copy(_D2);

+    _P1.multiplyScalar(-0.5*width*stepSize/effectiveResolution);

+    _P2.copy(_P1);

+    _P2.multiplyScalar(-1)

+    _P1.add(_P3);

+    _P2.add(_P3);

+    _P1.copy(_ComputeWSPositionFromWS(_P1));

+    _P2.copy(_ComputeWSPositionFromWS(_P2));

+    _D2.subVectors(_P1, _P2);

+    _D2.normalize();

+

+    _D1.cross(_D2);

+

+    return _D1;

+  }

+

+  RebuildEdgeNormals_(normals) {

+    const resolution = this.params_.resolution + 2;

+    const effectiveResolution = resolution - 2;

+

+    let x = 1;

+    for (let z = 1; z <= resolution-1; z+=1) {

+      const i = x * (resolution + 1) + z;

+      _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, 1))

+      normals[i * 3 + 0] = _N.x;

+      normals[i * 3 + 1] = _N.y;

+      normals[i * 3 + 2] = _N.z;

+    }

+

+    let z = resolution - 1;

+    for (let x = 1; x <= resolution-1; x+=1) {

+      const i = (x) * (resolution + 1) + z;

+      _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, 1))

+      normals[i * 3 + 0] = _N.x;

+      normals[i * 3 + 1] = _N.y;

+      normals[i * 3 + 2] = _N.z;

+    }

+

+    x = resolution - 1;

+    for (let z = 1; z <= resolution-1; z+=1) {

+      const i = x * (resolution + 1) + z;

+      _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, 1))

+      normals[i * 3 + 0] = _N.x;

+      normals[i * 3 + 1] = _N.y;

+      normals[i * 3 + 2] = _N.z;

+    }

+

+    z = 1;

+    for (let x = 1; x <= resolution-1; x+=1) {

+      const i = (x) * (resolution + 1) + z;

+      _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, 1))

+      normals[i * 3 + 0] = _N.x;

+      normals[i * 3 + 1] = _N.y;

+      normals[i * 3 + 2] = _N.z;

+    }

+  }

+

+  FixEdgesToMatchNeighbours_(positions, normals, colours) {

+    const resolution = this.params_.resolution + 2;

+    const effectiveResolution = resolution - 2;

+

+    if (this.params_.neighbours[0] > 1) {

+      const x = 1;

+      const stride = this.params_.neighbours[0];

+      for (let z = 1; z <= resolution-1; z+=1) {

+        const i = x * (resolution + 1) + z;

+        // colours[i * 3 + 0] = 0;

+        // colours[i * 3 + 1] = 0;

+        // colours[i * 3 + 2] = 1;

+

+        _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, stride))

+        normals[i * 3 + 0] = _N.x;

+        normals[i * 3 + 1] = _N.y;

+        normals[i * 3 + 2] = _N.z;

+      }

+      for (let z = 1; z <= resolution-1-stride; z+=stride) {

+        const i1 = x * (resolution + 1) + z;

+        const i2 = x * (resolution + 1) + (z + stride);

+

+        for (let s = 1; s < stride; ++s) {

+          const i = x * (resolution + 1) + z + s;

+          const p = s / stride;

+          for (let j = 0; j < 3; ++j) {

+            positions[i * 3 + j] = math.lerp(p, positions[i1 * 3 + j], positions[i2 * 3 + j]);

+            normals[i * 3 + j] = math.lerp(p, normals[i1 * 3 + j], normals[i2 * 3 + j]);

+          }

+          // colours[i * 3 + 0] = 0;

+          // colours[i * 3 + 1] = 1;

+          // colours[i * 3 + 2] = 0;

+        }

+      }

+    }

+

+    if (this.params_.neighbours[1] > 1) {

+      const z = resolution - 1;

+      const stride = this.params_.neighbours[1];

+      for (let x = 1; x <= resolution-1; x+=1) {

+        const i = (x) * (resolution + 1) + z;

+        // colours[i * 3 + 0] = 0;

+        // colours[i * 3 + 1] = 0;

+        // colours[i * 3 + 2] = 1;

+

+        _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, stride))

+        normals[i * 3 + 0] = _N.x;

+        normals[i * 3 + 1] = _N.y;

+        normals[i * 3 + 2] = _N.z;

+      }

+      for (let x = 1; x <= resolution-1-stride; x+=stride) {

+        const i1 = (x) * (resolution + 1) + z;

+        const i2 = (x + stride) * (resolution + 1) + z;

+

+        for (let s = 1; s < stride; ++s) {

+          const i = (x + s) * (resolution + 1) + z;

+          const p = s / stride;

+          for (let j = 0; j < 3; ++j) {

+            positions[i * 3 + j] = math.lerp(p, positions[i1 * 3 + j], positions[i2 * 3 + j]);

+            normals[i * 3 + j] = math.lerp(p, normals[i1 * 3 + j], normals[i2 * 3 + j]);

+          }

+          // colours[i * 3 + 0] = 1;

+          // colours[i * 3 + 1] = 1;

+          // colours[i * 3 + 2] = 0;

+        }

+      }

+    }

+

+    if (this.params_.neighbours[2] > 1) {

+      const x = resolution - 1;

+      const stride = this.params_.neighbours[2];

+      for (let z = 1; z <= resolution-1; z+=1) {

+        const i = x * (resolution + 1) + z;

+        // colours[i * 3 + 0] = 0;

+        // colours[i * 3 + 1] = 0;

+        // colours[i * 3 + 2] = 1;

+

+        _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, stride))

+        normals[i * 3 + 0] = _N.x;

+        normals[i * 3 + 1] = _N.y;

+        normals[i * 3 + 2] = _N.z;

+      }

+      for (let z = 1; z <= resolution-1-stride; z+=stride) {

+        const i1 = x * (resolution + 1) + z;

+        const i2 = x * (resolution + 1) + (z + stride);

+

+        for (let s = 1; s < stride; ++s) {

+          const i = x * (resolution + 1) + z + s;

+          const p = s / stride;

+          for (let j = 0; j < 3; ++j) {

+            positions[i * 3 + j] = math.lerp(p, positions[i1 * 3 + j], positions[i2 * 3 + j]);

+            normals[i * 3 + j] = math.lerp(p, normals[i1 * 3 + j], normals[i2 * 3 + j]);

+          }

+          // colours[i * 3 + 0] = 0;

+          // colours[i * 3 + 1] = 1;

+          // colours[i * 3 + 2] = 1;

+        }

+      }

+    }

+

+    if (this.params_.neighbours[3] > 1) {

+      const z = 1;

+      const stride = this.params_.neighbours[3];

+      for (let x = 1; x <= resolution-1; x+=1) {

+        const i = (x) * (resolution + 1) + z;

+        // colours[i * 3 + 0] = 0;

+        // colours[i * 3 + 1] = 0;

+        // colours[i * 3 + 2] = 1;

+

+        _N.copy(this._ComputeNormal_CentralDifference((x-1) / effectiveResolution, (z-1) / effectiveResolution, stride))

+        normals[i * 3 + 0] = _N.x;

+        normals[i * 3 + 1] = _N.y;

+        normals[i * 3 + 2] = _N.z;

+      }

+      for (let x = 1; x <= resolution-1-stride; x+=stride) {

+        const i1 = (x) * (resolution + 1) + z;

+        const i2 = (x + stride) * (resolution + 1) + z;

+

+        for (let s = 1; s < stride; ++s) {

+          const i = (x + s) * (resolution + 1) + z;

+          const p = s / stride;

+          for (let j = 0; j < 3; ++j) {

+            positions[i * 3 + j] = math.lerp(p, positions[i1 * 3 + j], positions[i2 * 3 + j]);

+            normals[i * 3 + j] = math.lerp(p, normals[i1 * 3 + j], normals[i2 * 3 + j]);

+          }

+          // colours[i * 3 + 0] = 1;

+          // colours[i * 3 + 1] = 0;

+          // colours[i * 3 + 2] = 0;

+        }

+      }

+    }

+  }

+

+  FixEdgeSkirt_(positions, up, normals) {

+    const resolution = this.params_.resolution + 2;

+

+    const _ApplyFix = (x, y, xp, yp) => {

+      const skirtIndex = x * (resolution + 1) + y;

+      const proxyIndex = xp * (resolution + 1) + yp;

+

+      _P.fromArray(positions, proxyIndex * 3);

+      _D.fromArray(up, proxyIndex * 3);

+      _D.multiplyScalar(0);

+      _P.add(_D);

+      positions[skirtIndex * 3 + 0] = _P.x;

+      positions[skirtIndex * 3 + 1] = _P.y;

+      positions[skirtIndex * 3 + 2] = _P.z;

+

+      // Normal will be fucked, copy it from proxy point

+      normals[skirtIndex * 3 + 0] = normals[proxyIndex * 3 + 0];

+      normals[skirtIndex * 3 + 1] = normals[proxyIndex * 3 + 1];

+      normals[skirtIndex * 3 + 2] = normals[proxyIndex * 3 + 2];

+    };

+

+    for (let y = 0; y <= resolution; ++y) {

+      _ApplyFix(0, y, 1, y);

+    }

+    for (let y = 0; y <= resolution; ++y) {

+      _ApplyFix(resolution, y, resolution - 1, y);

+    }

+    for (let x = 0; x <= resolution; ++x) {

+      _ApplyFix(x, 0, x, 1);

+    }

+    for (let x = 0; x <= resolution; ++x) {

+      _ApplyFix(x, resolution, x, resolution - 1);

+    }

+  }

+

+  NormalizeNormals_(normals) {

+    for (let i = 0, n = normals.length; i < n; i+=3) {

+      _N.fromArray(normals, i);

+      _N.normalize();

+      normals[i] = _N.x;

+      normals[i+1] = _N.y;

+      normals[i+2] = _N.z;

+    }

+  }

+

+  RebuildEdgePositions_(positions) {

+    const localToWorld = this.params_.worldMatrix;

+    const resolution = this.params_.resolution + 2;

+    const radius = this.params_.radius;

+    const offset = this.params_.offset;

+    const origin = this.params_.origin;

+    const width = this.params_.width;

+    const half = width / 2;

+    const effectiveResolution = resolution - 2;

+

+    const _ComputeOriginOffsetPosition = (xpos, ypos) => {

+      const xp = width * xpos;

+      const yp = width * ypos;

+      _P.set(xp - half, yp - half, radius);

+      _P.add(offset);

+      _P.normalize();

+      _D.copy(_P);

+      _D.transformDirection(localToWorld);

+

+      _P.multiplyScalar(radius);

+      _P.z -= radius;

+      _P.applyMatrix4(localToWorld);

+

+      // Keep the absolute world space position to sample noise

+      _W.copy(_P);

+

+      // Move the position relative to the origin

+      _P.sub(origin);

+

+      // Purturb height along z-vector

+      const height = this._GenerateHeight(_W);

+      _H.copy(_D);

+      _H.multiplyScalar(height);

+      _P.add(_H);

+

+      return _P;

+    }

+

+    let x = 1;

+    for (let z = 1; z <= resolution-1; z++) {

+      const i = x * (resolution + 1) + z;

+      const p = _ComputeOriginOffsetPosition((x-1) / effectiveResolution, (z-1) / effectiveResolution);

+      positions[i * 3 + 0] = p.x;

+      positions[i * 3 + 1] = p.y;

+      positions[i * 3 + 2] = p.z;

+    }

+

+    let z = resolution - 1;

+    for (let x = 1; x <= resolution-1; x++) {

+      const i = (x) * (resolution + 1) + z;

+      const p = _ComputeOriginOffsetPosition((x-1) / effectiveResolution, (z-1) / effectiveResolution);

+      positions[i * 3 + 0] = p.x;

+      positions[i * 3 + 1] = p.y;

+      positions[i * 3 + 2] = p.z;

+    }

+

+    x = resolution - 1;

+    for (let z = 1; z <= resolution-1; z++) {

+      const i = x * (resolution + 1) + z;

+      const p = _ComputeOriginOffsetPosition((x-1) / effectiveResolution, (z-1) / effectiveResolution);

+      positions[i * 3 + 0] = p.x;

+      positions[i * 3 + 1] = p.y;

+      positions[i * 3 + 2] = p.z;

+    }

+

+    z = 1;

+    for (let x = 1; x <= resolution-1; x++) {

+      const i = (x) * (resolution + 1) + z;

+      const p = _ComputeOriginOffsetPosition((x-1) / effectiveResolution, (z-1) / effectiveResolution);

+      positions[i * 3 + 0] = p.x;

+      positions[i * 3 + 1] = p.y;

+      positions[i * 3 + 2] = p.z;

+    }

+  }

+

+  Rebuild() {

+    const positions = [];

+    const up = [];

+    const coords = [];

+

+    const localToWorld = this.params_.worldMatrix;

+    const resolution = this.params_.resolution + 2;

+    const radius = this.params_.radius;

+    const offset = this.params_.offset;

+    const origin = this.params_.origin;

+    const width = this.params_.width;

+    const half = width / 2;

+    const effectiveResolution = resolution - 2;

+

+    for (let x = -1; x <= effectiveResolution + 1; x++) {

+      const xp = width * x / effectiveResolution;

+      for (let y = -1; y <= effectiveResolution + 1; y++) {

+        const yp = width * y / effectiveResolution;

+

+        // Compute position

+        _P.set(xp - half, yp - half, radius);

+        _P.add(offset);

+        _P.normalize();

+        _D.copy(_P);

+        _D.transformDirection(localToWorld);

+

+        _P.multiplyScalar(radius);

+        _P.z -= radius;

+        _P.applyMatrix4(localToWorld);

+

+        // Keep the absolute world space position to sample noise

+        _W.copy(_P);

+

+        // Move the position relative to the origin

+        _P.sub(origin);

+

+        // Purturb height along z-vector

+        const height = this._GenerateHeight(_W);

+        _H.copy(_D);

+        _H.multiplyScalar(height);

+        _P.add(_H);

+

+        positions.push(_P.x, _P.y, _P.z);

+

+        _C.copy(_W);

+        _C.add(_H);

+        coords.push(_C.x, _C.y, _C.z);

+

+        _S.set(_W.x, _W.y, height);

+

+        up.push(_D.x, _D.y, _D.z);

+      }

+    }

+

+    const colours = new Array(positions.length).fill(1.0);

+

+    // Generate indices

+    const indices = this.GenerateIndices_();

+    const normals = this.GenerateNormals_(positions, indices);

+

+    this.RebuildEdgePositions_(positions);

+    this.RebuildEdgeNormals_(normals);

+    this.FixEdgesToMatchNeighbours_(positions, normals, colours);

+    this.FixEdgeSkirt_(positions, up, normals);

+    this.NormalizeNormals_(normals);

+

+    const bytesInFloat32 = 4;

+    const bytesInInt32 = 4;

+    const positionsArray = new Float32Array(

+        new SharedArrayBuffer(bytesInFloat32 * positions.length));

+    const coloursArray = new Float32Array(

+        new SharedArrayBuffer(bytesInFloat32 * colours.length));

+    const normalsArray = new Float32Array(

+        new SharedArrayBuffer(bytesInFloat32 * normals.length));

+    const coordsArray = new Float32Array(

+        new SharedArrayBuffer(bytesInFloat32 * coords.length));

+    const indicesArray = new Uint32Array(

+        new SharedArrayBuffer(bytesInInt32 * indices.length));

+

+    positionsArray.set(positions, 0);

+    coloursArray.set(colours, 0);

+    normalsArray.set(normals, 0);

+    coordsArray.set(coords, 0);

+    indicesArray.set(indices, 0);

+

+    return {

+      positions: positionsArray,

+      colours: coloursArray,

+      normals: normalsArray,

+      coords: coordsArray,

+      indices: indicesArray,

+    };

+  }

+

+  QuickRebuild(mesh) {

+    const positions = mesh.positions;

+    const normals = mesh.normals;

+    const colours = mesh.colours;

+    const up = [];

+    const indices = mesh.indices;

+

+    const localToWorld = this.params_.worldMatrix;

+    const resolution = this.params_.resolution + 2;

+    const radius = this.params_.radius;

+    const offset = this.params_.offset;

+    const origin = this.params_.origin;

+    const width = this.params_.width;

+    const half = width / 2;

+    const effectiveResolution = resolution - 2;

+

+    colours.fill(1.0);

+

+    this.RebuildEdgePositions_(positions);

+    this.RebuildEdgeNormals_(normals);

+    this.FixEdgesToMatchNeighbours_(positions, normals, colours);

+    this.FixEdgeSkirt_(positions, up, normals);

+    this.NormalizeNormals_(normals);

+

+    return mesh;

+  }

+}

+

+const _CHUNK = new _TerrainBuilderThreadedWorker();

+

+self.onmessage = (msg) => {

+  if (msg.data.subject == 'build_chunk') {

+    _CHUNK.Init(msg.data.params);

+

+    const rebuiltData = _CHUNK.Rebuild();

+    self.postMessage({subject: 'build_chunk_result', data: rebuiltData});

+  } else if (msg.data.subject == 'rebuild_chunk') {

+    _CHUNK.Init(msg.data.params);

+

+    const rebuiltData = _CHUNK.QuickRebuild(msg.data.mesh);

+    self.postMessage({subject: 'quick_rebuild_chunk_result', data: rebuiltData});

+  }

+};

+ 205 - 0
src/terrain-builder-threaded.js
View File

@@ -0,0 +1,205 @@

+

+import {terrain_chunk} from './terrain-chunk.js';

+

+

+export const terrain_builder_threaded = (function() {

+

+  const _NUM_WORKERS = 7;

+

+  let _IDs = 0;

+

+  class WorkerThread {

+    constructor(s) {

+      this.worker_ = new Worker(s, {type: 'module'});

+      this.worker_.onmessage = (e) => {

+        this._OnMessage(e);

+      };

+      this._resolve = null;

+      this._id = _IDs++;

+    }

+

+    _OnMessage(e) {

+      const resolve = this._resolve;

+      this._resolve = null;

+      resolve(e.data);

+    }

+

+    get id() {

+      return this._id;

+    }

+

+    postMessage(s, resolve) {

+      this._resolve = resolve;

+      this.worker_.postMessage(s);

+    }

+  }

+

+  class WorkerThreadPool {

+    constructor(sz, entry) {

+      this.workers_ = [...Array(sz)].map(_ => new WorkerThread(entry));

+      this.free_ = [...this.workers_];

+      this.busy_ = {};

+      this.queue_ = [];

+    }

+

+    get length() {

+      return this.workers_.length;

+    }

+

+    get Busy() {

+      return this.queue_.length > 0 || Object.keys(this.busy_).length > 0;

+    }

+

+    Enqueue(workItem, resolve) {

+      this.queue_.push([workItem, resolve]);

+      this._PumpQueue();

+    }

+

+    _PumpQueue() {

+      while (this.free_.length > 0 && this.queue_.length > 0) {

+        const w = this.free_.pop();

+        this.busy_[w.id] = w;

+

+        const [workItem, workResolve] = this.queue_.shift();

+

+        w.postMessage(workItem, (v) => {

+          delete this.busy_[w.id];

+          this.free_.push(w);

+          workResolve(v);

+          this._PumpQueue();

+        });

+      }

+    }

+  }

+

+  class _TerrainChunkRebuilder_Threaded {

+    constructor(params) {

+      this.pool_ = {};

+      this.old_ = [];

+

+      this.workerPool_ = new WorkerThreadPool(

+        _NUM_WORKERS, 'src/terrain-builder-threaded-worker.js');

+
+      this.params_ = params;

+    }

+

+    _OnResult(chunk, msg) {

+      if (msg.subject == 'build_chunk_result') {

+        chunk.RebuildMeshFromData(msg.data);

+      } else if (msg.subject == 'quick_rebuild_chunk_result') {

+        chunk.QuickRebuildMeshFromData(msg.data);

+      }

+    }

+

+    AllocateChunk(params) {

+      const w = params.width;

+

+      if (!(w in this.pool_)) {

+        this.pool_[w] = [];

+      }

+

+      let c = null;

+      if (this.pool_[w].length > 0) {

+        c = this.pool_[w].pop();

+        c.params_ = params;

+      } else {

+        c = new terrain_chunk.TerrainChunk(params);

+      }

+

+      c.Hide();

+

+      const threadedParams = {

+        noiseParams: params.noiseParams,

+        colourNoiseParams: params.colourNoiseParams,

+        biomesParams: params.biomesParams,

+        colourGeneratorParams: params.colourGeneratorParams,

+        heightGeneratorsParams: params.heightGeneratorsParams,

+        width: params.width,

+        neighbours: params.neighbours,

+        offset: params.offset.toArray(),

+        origin: params.origin.toArray(),

+        radius: params.radius,

+        resolution: params.resolution,

+        worldMatrix: params.transform,

+      };

+

+      const msg = {

+        subject: 'build_chunk',

+        params: threadedParams,

+      };

+

+      this.workerPool_.Enqueue(msg, (m) => {

+        this._OnResult(c, m);

+      });

+

+      return c;
+    }

+

+    RetireChunks(chunks) {

+      this.old_.push(...chunks);

+    }

+

+    _RecycleChunks(chunks) {

+      for (let c of chunks) {

+        if (!(c.chunk.params_.width in this.pool_)) {

+          this.pool_[c.chunk.params_.width] = [];

+        }

+

+        c.chunk.Destroy();

+      }

+    }

+

+    get Busy() {

+      return this.workerPool_.Busy;

+    }

+

+    Rebuild(chunks) {

+      for (let k in chunks) {

+        this.workerPool_.Enqueue(chunks[k].chunk.params_);

+      }

+    }

+

+    QuickRebuild(chunks) {

+      for (let k in chunks) {

+        const chunk = chunks[k];

+        const params = chunk.chunk.params_;

+

+        const threadedParams = {

+          noiseParams: params.noiseParams,

+          colourNoiseParams: params.colourNoiseParams,

+          biomesParams: params.biomesParams,

+          colourGeneratorParams: params.colourGeneratorParams,

+          heightGeneratorsParams: params.heightGeneratorsParams,

+          width: params.width,

+          neighbours: params.neighbours,

+          offset: params.offset.toArray(),

+          origin: params.origin.toArray(),

+          radius: params.radius,

+          resolution: params.resolution,

+          worldMatrix: params.transform,

+        };

+

+        const msg = {

+          subject: 'rebuild_chunk',

+          params: threadedParams,

+          mesh: chunk.chunk.rebuildData_,

+        };

+
+        this.workerPool_.Enqueue(msg, (m) => {

+          this._OnResult(chunk.chunk, m);

+        });

+      }

+    }

+

+    Update() {

+      if (!this.Busy) {

+        this._RecycleChunks(this.old_);

+        this.old_ = [];

+      }

+    }

+  }

+

+  return {

+    TerrainChunkRebuilder_Threaded: _TerrainChunkRebuilder_Threaded

+  }

+})();

+ 100 - 0
src/terrain-builder.js
View File

@@ -0,0 +1,100 @@

+import {terrain_chunk} from './terrain-chunk.js';

+

+

+export const terrain_builder = (function() {

+

+  class _TerrainChunkRebuilder {

+    constructor(params) {

+      this._pool = {};

+      this._params = params;

+      this._Reset();

+    }

+

+    AllocateChunk(params) {

+      const w = params.width;

+

+      if (!(w in this._pool)) {

+        this._pool[w] = [];

+      }

+

+      let c = null;

+      if (this._pool[w].length > 0) {

+        c = this._pool[w].pop();

+        c._params = params;

+      } else {

+        c = new terrain_chunk.TerrainChunk(params);

+      }

+

+      c.Hide();

+

+      this._queued.push(c);

+

+      return c;
+    }

+

+    RetireChunks(chunks) {

+      this._old.push(...chunks);

+    }

+

+    _RecycleChunks(chunks) {

+      for (let c of chunks) {

+        if (!(c.chunk._params.width in this._pool)) {

+          this._pool[c.chunk._params.width] = [];

+        }

+

+        c.chunk.Destroy();

+      }

+    }

+

+    _Reset() {

+      this._active = null;

+      this._queued = [];

+      this._old = [];

+      this._new = [];

+    }

+

+    get Busy() {

+      return this._active || this._queued.length > 0;

+    }

+

+    Rebuild(chunks) {

+      if (this.Busy) {

+        return;

+      }

+      for (let k in chunks) {

+        this._queued.push(chunks[k].chunk);

+      }

+    }

+

+    Update() {

+      if (this._active) {

+        const r = this._active.next();

+        if (r.done) {

+          this._active = null;

+        }

+      } else {

+        const b = this._queued.pop();

+        if (b) {

+          this._active = b._Rebuild();

+          this._new.push(b);

+        }

+      }

+

+      if (this._active) {

+        return;

+      }

+

+      if (!this._queued.length) {

+        this._RecycleChunks(this._old);

+        for (let b of this._new) {

+          b.Show();

+        }

+        this._Reset();

+      }

+    }

+  }

+

+  return {

+    TerrainChunkRebuilder: _TerrainChunkRebuilder

+  }

+})();

+ 79 - 0
src/terrain-chunk.js
View File

@@ -0,0 +1,79 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+

+export const terrain_chunk = (function() {

+

+  class TerrainChunk {

+    constructor(params) {

+      this.params_ = params;

+      this._Init(params);

+    }

+
+    Destroy() {

+      this.params_.group.remove(this.mesh_);

+    }

+

+    Hide() {

+      this.mesh_.visible = false;

+    }

+

+    Show() {

+      this.mesh_.visible = true;

+    }

+

+    _Init(params) {

+      this.geometry_ = new THREE.BufferGeometry();

+      this.mesh_ = new THREE.Mesh(this.geometry_, params.material);

+      this.mesh_.castShadow = false;

+      this.mesh_.receiveShadow = true;

+      this.mesh_.frustumCulled = false;

+      this.params_.group.add(this.mesh_);

+      this.Reinit(params);

+    }

+

+    Update(cameraPosition) {

+      this.mesh_.position.copy(this.params_.origin);

+      this.mesh_.position.sub(cameraPosition);

+    }

+

+    Reinit(params) {

+      this.params_ = params;

+      this.mesh_.position.set(0, 0, 0);

+    }

+

+    SetWireframe(b) {

+      this.mesh_.material.wireframe = b;

+    }

+

+    RebuildMeshFromData(data) {

+      this.geometry_.setAttribute(

+          'position', new THREE.Float32BufferAttribute(data.positions, 3));

+      this.geometry_.setAttribute(

+          'color', new THREE.Float32BufferAttribute(data.colours, 3));

+      this.geometry_.setAttribute(

+          'normal', new THREE.Float32BufferAttribute(data.normals, 3));

+      this.geometry_.setAttribute(

+          'coords', new THREE.Float32BufferAttribute(data.coords, 3));

+      this.geometry_.setIndex(

+          new THREE.BufferAttribute(data.indices, 1));

+      this.rebuildData_ = data;

+      this.geometry_.attributes.position.needsUpdate = true;

+      this.geometry_.attributes.normal.needsUpdate = true;

+      this.geometry_.attributes.color.needsUpdate = true;

+      this.geometry_.attributes.coords.needsUpdate = true;

+    }

+

+    QuickRebuildMeshFromData(data) {

+      this.geometry_.attributes.position.array.set(data.positions, 0)

+      this.geometry_.attributes.normal.array.set(data.normals, 0)

+      this.geometry_.attributes.color.array.set(data.colours, 0)

+      this.geometry_.attributes.position.needsUpdate = true;

+      this.geometry_.attributes.normal.needsUpdate = true;

+      this.geometry_.attributes.color.needsUpdate = true;

+    }

+  }

+

+  return {

+    TerrainChunk: TerrainChunk

+  }

+})();

+ 12 - 0
src/terrain-constants.js
View File

@@ -0,0 +1,12 @@

+

+

+export const terrain_constants = (function() {

+  return {

+    QT_MIN_CELL_SIZE: 25,

+    QT_MIN_CELL_RESOLUTION: 48,

+    PLANET_RADIUS: 400000.0,

+

+    NOISE_HEIGHT: 20000.0,

+    NOISE_SCALE: 18000.0,

+  }

+})();

+ 288 - 0
src/terrain-shader.js
View File

@@ -0,0 +1,288 @@

+export const terrain_shader = (function() {

+

+  const _VS = `#version 300 es

+

+precision highp float;

+

+uniform mat4 modelMatrix;

+uniform mat4 modelViewMatrix;

+uniform mat4 viewMatrix;

+uniform mat4 projectionMatrix;

+uniform vec3 cameraPosition;

+uniform float fogDensity;

+uniform vec3 cloudScale;

+

+// Attributes

+in vec3 position;

+in vec3 normal;

+in vec3 coords;

+in vec3 color;

+

+// Outputs

+out vec4 vColor;

+out vec3 vNormal;

+out vec3 vCoords;

+out vec3 vVSPos;

+out vec3 vRepeatingCoords;

+out float vFragDepth;

+

+#define saturate(a) clamp( a, 0.0, 1.0 )

+

+void main(){

+  mat4 terrainMatrix = mat4(

+      viewMatrix[0],

+      viewMatrix[1],

+      viewMatrix[2],

+      vec4(0.0, 0.0, 0.0, 1.0));

+

+  gl_Position = projectionMatrix * terrainMatrix * modelMatrix * vec4(position, 1.0);

+

+  vNormal = normal;

+

+  vColor = vec4(color, 1);

+  vCoords = (modelMatrix * vec4(position, 1.0)).xyz + cameraPosition;

+  vVSPos = (terrainMatrix * modelMatrix * vec4(position, 1.0)).xyz;

+

+  vec3 pos = coords;

+  float p = 32768.0;

+  float a = 1024.0;

+  vRepeatingCoords = (4.0 * a / p) * abs(mod(pos, p) - p * 0.5);

+

+  vFragDepth = 1.0 + gl_Position.w;

+}

+  `;

+
+

+  const _PS = `#version 300 es

+

+precision highp float;

+precision highp int;

+precision highp sampler2DArray;

+

+uniform sampler2DArray normalMap;

+uniform sampler2DArray diffuseMap;

+uniform sampler2D noiseMap;

+

+uniform mat4 modelMatrix;

+uniform mat4 modelViewMatrix;

+uniform vec3 cameraPosition;

+uniform float logDepthBufFC;

+

+in vec4 vColor;

+in vec3 vNormal;

+in vec3 vCoords;

+in vec3 vRepeatingCoords;

+in vec3 vVSPos;

+in float vFragDepth;

+

+out vec4 out_FragColor;

+

+#define saturate(a) clamp( a, 0.0, 1.0 )

+

+const float _TRI_SCALE = 10.0;

+

+float sum( vec3 v ) { return v.x+v.y+v.z; }

+

+vec4 hash4( vec2 p ) {

+  return fract(

+    sin(vec4(1.0+dot(p,vec2(37.0,17.0)),
+              2.0+dot(p,vec2(11.0,47.0)),

+              3.0+dot(p,vec2(41.0,29.0)),

+              4.0+dot(p,vec2(23.0,31.0))))*103.0);

+}

+

+vec4 _CalculateLighting(

+    vec3 lightDirection, vec3 lightColour, vec3 worldSpaceNormal, vec3 viewDirection) {

+  float NdotL = saturate(dot(worldSpaceNormal, lightDirection));

+  // return vec4(lightColour * diffuse, 0.0);

+

+  vec3 H = normalize(lightDirection + viewDirection);

+  float NdotH = dot(worldSpaceNormal, H);

+  float specular = saturate(pow(NdotH, 8.0));

+

+  return vec4(lightColour * NdotL, specular * NdotL);

+}

+

+vec4 _ComputeLighting(vec3 worldSpaceNormal, vec3 sunDir, vec3 viewDirection) {

+  // Hardcoded, whee!

+  vec4 lighting;

+
+  lighting += _CalculateLighting(

+      sunDir, vec3(1.0, 1.0, 1.0), worldSpaceNormal, viewDirection);

+  // lighting += _CalculateLighting(

+  //     vec3(0, 1, 0), vec3(0.25, 0.25, 0.25), worldSpaceNormal, viewDirection);

+

+  // lighting += vec4(0.15, 0.15, 0.15, 0.0);

+
+  return lighting;

+}

+

+vec4 _TerrainBlend_4(vec4 samples[4]) {

+  float depth = 0.2;

+  float ma = max(

+      samples[0].w,

+      max(

+          samples[1].w,

+          max(samples[2].w, samples[3].w))) - depth;

+

+  float b1 = max(samples[0].w - ma, 0.0);

+  float b2 = max(samples[1].w - ma, 0.0);

+  float b3 = max(samples[2].w - ma, 0.0);

+  float b4 = max(samples[3].w - ma, 0.0);

+

+  vec4 numer = (

+      samples[0] * b1 + samples[1] * b2 +

+      samples[2] * b3 + samples[3] * b4);

+  float denom = (b1 + b2 + b3 + b4);

+  return numer / denom;

+}

+

+vec4 _TerrainBlend_4_lerp(vec4 samples[4]) {

+  return (

+      samples[0] * samples[0].w + samples[1] * samples[1].w +

+      samples[2] * samples[2].w + samples[3] * samples[3].w);

+}

+

+// Lifted from https://www.shadertoy.com/view/Xtl3zf

+vec4 texture_UV(in sampler2DArray srcTexture, in vec3 x) {

+  float k = texture(noiseMap, 0.0025*x.xy).x; // cheap (cache friendly) lookup

+  float l = k*8.0;

+  float f = fract(l);

+
+  float ia = floor(l+0.5); // suslik's method (see comments)

+  float ib = floor(l);

+  f = min(f, 1.0-f)*2.0;

+

+  vec2 offa = sin(vec2(3.0,7.0)*ia); // can replace with any other hash

+  vec2 offb = sin(vec2(3.0,7.0)*ib); // can replace with any other hash

+

+  vec4 cola = texture(srcTexture, vec3(x.xy + offa, x.z));

+  vec4 colb = texture(srcTexture, vec3(x.xy + offb, x.z));

+

+  return mix(cola, colb, smoothstep(0.2,0.8,f-0.1*sum(cola.xyz-colb.xyz)));

+}

+

+vec4 _Triplanar_UV(vec3 pos, vec3 normal, float texSlice, sampler2DArray tex) {

+  vec4 dx = texture_UV(tex, vec3(pos.zy / _TRI_SCALE, texSlice));

+  vec4 dy = texture_UV(tex, vec3(pos.xz / _TRI_SCALE, texSlice));

+  vec4 dz = texture_UV(tex, vec3(pos.xy / _TRI_SCALE, texSlice));

+

+  vec3 weights = abs(normal.xyz);

+  weights = weights / (weights.x + weights.y + weights.z);

+

+  return dx * weights.x + dy * weights.y + dz * weights.z;

+}

+

+vec4 _TriplanarN_UV(vec3 pos, vec3 normal, float texSlice, sampler2DArray tex) {

+  // Tangent Reconstruction

+  // Triplanar uvs

+  vec2 uvX = pos.zy; // x facing plane

+  vec2 uvY = pos.xz; // y facing plane

+  vec2 uvZ = pos.xy; // z facing plane

+  // Tangent space normal maps

+  vec3 tx = texture_UV(tex, vec3(uvX / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+  vec3 ty = texture_UV(tex, vec3(uvY / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+  vec3 tz = texture_UV(tex, vec3(uvZ / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+

+  vec3 weights = abs(normal.xyz);

+  weights = weights / (weights.x + weights.y + weights.z);

+

+  // Get the sign (-1 or 1) of the surface normal

+  vec3 axis = sign(normal);

+  // Construct tangent to world matrices for each axis

+  vec3 tangentX = normalize(cross(normal, vec3(0.0, axis.x, 0.0)));

+  vec3 bitangentX = normalize(cross(tangentX, normal)) * axis.x;

+  mat3 tbnX = mat3(tangentX, bitangentX, normal);

+

+  vec3 tangentY = normalize(cross(normal, vec3(0.0, 0.0, axis.y)));

+  vec3 bitangentY = normalize(cross(tangentY, normal)) * axis.y;

+  mat3 tbnY = mat3(tangentY, bitangentY, normal);

+

+  vec3 tangentZ = normalize(cross(normal, vec3(0.0, -axis.z, 0.0)));

+  vec3 bitangentZ = normalize(-cross(tangentZ, normal)) * axis.z;

+  mat3 tbnZ = mat3(tangentZ, bitangentZ, normal);

+

+  // Apply tangent to world matrix and triblend

+  // Using clamp() because the cross products may be NANs

+  vec3 worldNormal = normalize(

+      clamp(tbnX * tx, -1.0, 1.0) * weights.x +

+      clamp(tbnY * ty, -1.0, 1.0) * weights.y +

+      clamp(tbnZ * tz, -1.0, 1.0) * weights.z

+      );

+  return vec4(worldNormal, 0.0);

+}

+

+vec4 _Triplanar(vec3 pos, vec3 normal, float texSlice, sampler2DArray tex) {

+  vec4 dx = texture(tex, vec3(pos.zy / _TRI_SCALE, texSlice));

+  vec4 dy = texture(tex, vec3(pos.xz / _TRI_SCALE, texSlice));

+  vec4 dz = texture(tex, vec3(pos.xy / _TRI_SCALE, texSlice));

+

+  vec3 weights = abs(normal.xyz);

+  weights = weights / (weights.x + weights.y + weights.z);

+

+  return dx * weights.x + dy * weights.y + dz * weights.z;

+}

+

+vec4 _TriplanarN(vec3 pos, vec3 normal, float texSlice, sampler2DArray tex) {

+  vec2 uvx = pos.zy;

+  vec2 uvy = pos.xz;

+  vec2 uvz = pos.xy;

+  vec3 tx = texture(tex, vec3(uvx / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+  vec3 ty = texture(tex, vec3(uvy / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+  vec3 tz = texture(tex, vec3(uvz / _TRI_SCALE, texSlice)).xyz * vec3(2,2,2) - vec3(1,1,1);

+

+  vec3 weights = abs(normal.xyz);

+  weights *= weights;

+  weights = weights / (weights.x + weights.y + weights.z);

+

+  vec3 axis = sign(normal);

+  vec3 tangentX = normalize(cross(normal, vec3(0.0, axis.x, 0.0)));

+  vec3 bitangentX = normalize(cross(tangentX, normal)) * axis.x;

+  mat3 tbnX = mat3(tangentX, bitangentX, normal);

+

+  vec3 tangentY = normalize(cross(normal, vec3(0.0, 0.0, axis.y)));

+  vec3 bitangentY = normalize(cross(tangentY, normal)) * axis.y;

+  mat3 tbnY = mat3(tangentY, bitangentY, normal);

+

+  vec3 tangentZ = normalize(cross(normal, vec3(0.0, -axis.z, 0.0)));

+  vec3 bitangentZ = normalize(-cross(tangentZ, normal)) * axis.z;

+  mat3 tbnZ = mat3(tangentZ, bitangentZ, normal);

+

+  vec3 worldNormal = normalize(

+      clamp(tbnX * tx, -1.0, 1.0) * weights.x +

+      clamp(tbnY * ty, -1.0, 1.0) * weights.y +

+      clamp(tbnZ * tz, -1.0, 1.0) * weights.z);

+  return vec4(worldNormal, 0.0);

+}

+

+void main() {

+  vec3 worldPosition = vCoords;

+  vec3 eyeDirection = normalize(worldPosition - cameraPosition);

+  vec3 sunDir = normalize(vec3(1, 1, -1));

+  vec3 worldSpaceNormal = normalize(vNormal);

+

+  // Bit of a hack to remove lighting on dark side of planet

+  vec3 diffuse = vec3(0.75);

+  vec3 planetNormal = normalize(worldPosition);

+  float planetLighting = saturate(dot(planetNormal, sunDir));

+

+  vec4 lighting = _ComputeLighting(worldSpaceNormal, sunDir, -eyeDirection);

+  vec3 finalColour = mix(vec3(1.0, 1.0, 1.0), vColor.xyz, 0.25) * diffuse + lighting.w * 0.1;

+  // vec3 finalColour = mix(vec3(1.0, 1.0, 1.0), vColor.xyz, 0.25);

+

+  finalColour *= lighting.xyz;

+  finalColour = lighting.xyz;

+  // finalColour = vColor.xyz;

+

+  out_FragColor = vec4(finalColour, 1);

+  gl_FragDepth = log2(vFragDepth) * logDepthBufFC * 0.5;

+}

+

+  `;

+
+  return {

+    VS: _VS,

+    PS: _PS,

+  };

+})();

+

+ 338 - 0
src/terrain.js
View File

@@ -0,0 +1,338 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+import {noise} from './noise.js';

+import {quadtree} from './quadtree.js';

+import {terrain_shader} from './terrain-shader.js';

+import {terrain_builder_threaded} from './terrain-builder-threaded.js';

+import {terrain_constants} from './terrain-constants.js';

+import {texture_splatter} from './texture-splatter.js';

+import {textures} from './textures.js';

+import {utils} from './utils.js';

+

+export const terrain = (function() {

+

+  class TerrainChunkManager {

+    constructor(params) {

+      this._Init(params);

+    }

+

+    _Init(params) {

+      this.params_ = params;

+

+      this.builder_ = new terrain_builder_threaded.TerrainChunkRebuilder_Threaded();

+      // this.builder_ = new terrainbuilder_.TerrainChunkRebuilder();

+

+      this.LoadTextures_();

+

+      this.InitNoise_(params);

+      this.InitBiomes_(params);

+      this.InitTerrain_(params);

+    }

+

+    LoadTextures_() {

+      const loader = new THREE.TextureLoader();

+

+      const noiseTexture = loader.load('./resources/simplex-noise.png');

+      noiseTexture.wrapS = THREE.RepeatWrapping;

+      noiseTexture.wrapT = THREE.RepeatWrapping;

+

+      this.material_ = new THREE.RawShaderMaterial({

+        uniforms: {

+          diffuseMap: {

+          },

+          normalMap: {

+          },

+          noiseMap: {

+            value: noiseTexture

+          },

+          logDepthBufFC: {

+            value: 2.0 / (Math.log(this.params_.camera.far + 1.0) / Math.LN2),

+          }

+        },

+        vertexShader: terrain_shader.VS,

+        fragmentShader: terrain_shader.PS,

+        side: THREE.FrontSide

+      });

+    }

+

+    InitNoise_(params) {

+      params.guiParams.noise = {

+        octaves: 13,

+        persistence: 0.5,

+        lacunarity: 1.6,

+        exponentiation: 7.5,

+        height: terrain_constants.NOISE_HEIGHT,

+        scale: terrain_constants.NOISE_SCALE,

+        seed: 1

+      };

+

+      const onNoiseChanged = () => {

+        this.builder_.Rebuild(this.chunks_);

+      };

+

+      const noiseRollup = params.gui.addFolder('Terrain.Noise');

+      noiseRollup.add(params.guiParams.noise, "scale", 32.0, 4096.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.noise, "octaves", 1, 20, 1).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.noise, "persistence", 0.25, 1.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.noise, "lacunarity", 0.01, 4.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.noise, "exponentiation", 0.1, 10.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.noise, "height", 0, 20000).onChange(

+          onNoiseChanged);

+

+      this.noise_ = new noise.Noise(params.guiParams.noise);

+      this.noiseParams_ = params.guiParams.noise;

+

+      params.guiParams.heightmap = {

+        height: 16,

+      };

+

+      const heightmapRollup = params.gui.addFolder('Terrain.Heightmap');

+      heightmapRollup.add(params.guiParams.heightmap, "height", 0, 128).onChange(

+          onNoiseChanged);

+    }

+

+    InitBiomes_(params) {

+      params.guiParams.biomes = {

+        octaves: 2,

+        persistence: 0.5,

+        lacunarity: 2.0,

+        scale: 2048.0,

+        noiseType: 'simplex',

+        seed: 2,

+        exponentiation: 1,

+        height: 1.0

+      };

+

+      const onNoiseChanged = () => {

+        this.builder_.Rebuild(this.chunks_);

+      };

+

+      const noiseRollup = params.gui.addFolder('Terrain.Biomes');

+      noiseRollup.add(params.guiParams.biomes, "scale", 64.0, 4096.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.biomes, "octaves", 1, 20, 1).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.biomes, "persistence", 0.01, 1.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.biomes, "lacunarity", 0.01, 4.0).onChange(

+          onNoiseChanged);

+      noiseRollup.add(params.guiParams.biomes, "exponentiation", 0.1, 10.0).onChange(

+          onNoiseChanged);

+

+      this.biomes_ = new noise.Noise(params.guiParams.biomes);

+      this.biomesParams_ = params.guiParams.biomes;

+

+      const colourParams = {

+        octaves: 1,

+        persistence: 0.5,

+        lacunarity: 2.0,

+        exponentiation: 1.0,

+        scale: 256.0,

+        noiseType: 'simplex',

+        seed: 2,

+        height: 1.0,

+      };

+      this.colourNoise_ = new noise.Noise(colourParams);

+      this.colourNoiseParams_ = colourParams;

+    }

+

+    InitTerrain_(params) {

+      params.guiParams.terrain = {

+        wireframe: false,

+        fixedCamera: false,

+      };

+

+      this.groups_ = [...new Array(6)].map(_ => new THREE.Group());

+      params.scene.add(...this.groups_);

+

+      const terrainRollup = params.gui.addFolder('Terrain');

+      terrainRollup.add(params.guiParams.terrain, "wireframe").onChange(() => {

+        for (let k in this.chunks_) {

+          this.chunks_[k].chunk.SetWireframe(params.guiParams.terrain.wireframe);

+        }

+      });

+

+      terrainRollup.add(params.guiParams.terrain, "fixedCamera");

+

+      this.chunks_ = {};

+      this.params_ = params;

+    }

+

+    _CreateTerrainChunk(group, groupTransform, offset, cameraPosition, width, neighbours, resolution) {

+      const params = {

+        group: group,

+        transform: groupTransform,

+        material: this.material_,

+        width: width,

+        offset: offset,

+        origin: cameraPosition.clone(),

+        radius: terrain_constants.PLANET_RADIUS,

+        resolution: resolution,

+        neighbours: neighbours,

+        biomeGenerator: this.biomes_,

+        colourGenerator: new texture_splatter.TextureSplatter(

+            {biomeGenerator: this.biomes_, colourNoise: this.colourNoise_}),

+        heightGenerators: [new texture_splatter.HeightGenerator(

+            this.noise_, offset, 100000, 100000 + 1)],

+        noiseParams: this.noiseParams_,

+        colourNoiseParams: this.colourNoiseParams_,

+        biomesParams: this.biomesParams_,

+        colourGeneratorParams: {

+          biomeGeneratorParams: this.biomesParams_,

+          colourNoiseParams: this.colourNoiseParams_,

+        },

+        heightGeneratorsParams: {

+          min: 100000,

+          max: 100000 + 1,

+        }

+      };

+

+      return this.builder_.AllocateChunk(params);

+    }

+

+    Update(_) {

+      const cameraPosition = this.params_.camera.position.clone();

+      if (this.params_.guiParams.terrain.fixedCamera) {

+        cameraPosition.copy(this.cachedCamera_);

+      } else {

+        this.cachedCamera_ = cameraPosition.clone();

+      }

+

+      this.builder_.Update();

+      if (!this.builder_.Busy) {

+        for (let k in this.chunks_) {

+          this.chunks_[k].chunk.Show();

+        }

+        this.UpdateVisibleChunks_Quadtree_(cameraPosition);

+      }

+

+      for (let k in this.chunks_) {

+        this.chunks_[k].chunk.Update(this.params_.camera.position);

+      }

+      for (let c of this.builder_.old_) {

+        c.chunk.Update(this.params_.camera.position);

+      }

+

+      this.params_.scattering.uniforms.planetRadius.value = terrain_constants.PLANET_RADIUS;

+      this.params_.scattering.uniforms.atmosphereRadius.value = terrain_constants.PLANET_RADIUS * 1.01;

+    }

+

+    UpdateVisibleChunks_Quadtree_(cameraPosition) {

+      function _Key(c) {

+        return c.position[0] + '/' + c.position[1] + ' [' + c.size + ']' + ' [' + c.index + ']';

+      }

+

+      const q = new quadtree.CubeQuadTree({

+        radius: terrain_constants.PLANET_RADIUS,

+        min_node_size: terrain_constants.QT_MIN_CELL_SIZE,

+        max_node_size: terrain_constants.QT_MAX_CELL_SIZE,

+      });

+      q.Insert(cameraPosition);

+      q.BuildNeighbours();

+

+      const sides = q.GetChildren();

+

+      let newTerrainChunks = {};

+      const center = new THREE.Vector3();

+      const dimensions = new THREE.Vector3();

+

+      const _Child = (c) => {

+        c.bounds.getCenter(center);

+        c.bounds.getSize(dimensions);

+

+        const child = {

+          index: c.side,

+          group: this.groups_[c.side],

+          transform: sides[c.side].transform,

+          position: [center.x, center.y, center.z],

+          bounds: c.bounds,

+          size: dimensions.x,

+          neighbours: c.neighbours.map(n => n.size.x / c.size.x),

+          neighboursOriginal: c.neighbours,

+        };

+        return child;

+      };

+

+      for (let i = 0; i < sides.length; i++) {

+        for (let c of sides[i].children) {

+          const child = _Child(c);

+          const k = _Key(child);

+

+          const left = c.neighbours[0].GetClosestChildrenSharingEdge(c.GetLeftEdgeMidpoint());

+          const top = c.neighbours[1].GetClosestChildrenSharingEdge(c.GetTopEdgeMidpoint());

+          const right = c.neighbours[2].GetClosestChildrenSharingEdge(c.GetRightEdgeMidpoint());

+          const bottom = c.neighbours[3].GetClosestChildrenSharingEdge(c.GetBottomEdgeMidpoint());

+

+          child.neighbourKeys = [...left, ...top, ...right, ...bottom].map(n => _Key(_Child(n)));

+          child.debug = [left, top, right, bottom];

+
+          newTerrainChunks[k] = child;

+        }

+      }

+

+

+      const allChunks = newTerrainChunks;

+      const intersection = utils.DictIntersection(this.chunks_, newTerrainChunks);

+      const difference = utils.DictDifference(newTerrainChunks, this.chunks_);

+      const recycle = Object.values(utils.DictDifference(this.chunks_, newTerrainChunks));

+

+      if (0) {

+        const partialRebuilds = {};

+

+        for (let k in difference) {

+          for (let n of difference[k].neighbourKeys) {

+            if (n in this.chunks_) {

+              partialRebuilds[n] = newTerrainChunks[n];

+            }

+          }

+        }

+        for (let k in partialRebuilds) {

+          if (k in intersection) {

+            recycle.push(this.chunks_[k]);

+            delete intersection[k];

+            difference[k] = allChunks[k];

+          }

+        }

+      }

+

+      this.builder_.RetireChunks(recycle);

+

+      newTerrainChunks = intersection;

+

+      const partialRebuilds = {};

+

+      for (let k in difference) {

+        const [xp, yp, zp] = difference[k].position;

+

+        const offset = new THREE.Vector3(xp, yp, zp);

+        newTerrainChunks[k] = {

+          position: [xp, zp],

+          chunk: this._CreateTerrainChunk(

+              difference[k].group, difference[k].transform,

+              offset, cameraPosition, difference[k].size, difference[k].neighbours,

+              terrain_constants.QT_MIN_CELL_RESOLUTION),

+        };

+

+        for (let n of difference[k].neighbourKeys) {

+          if (n in this.chunks_) {

+            partialRebuilds[n] = intersection[n];

+            partialRebuilds[n].chunk.params_.neighbours = allChunks[n].neighbours;

+          }

+        }

+      }

+

+      this.builder_.QuickRebuild(partialRebuilds);

+

+      this.chunks_ = newTerrainChunks;

+    }

+  }

+

+  return {

+    TerrainChunkManager: TerrainChunkManager

+  }

+})();

+ 188 - 0
src/texture-splatter.js
View File

@@ -0,0 +1,188 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+import {math} from './math.js';

+import {spline} from './spline.js';

+import {terrain_constants} from './terrain-constants.js';

+

+

+export const texture_splatter = (function() {

+

+  const _HEIGHT_NORMALIZATION = terrain_constants.NOISE_HEIGHT / 10.0;

+

+  const _WHITE = new THREE.Color(0x808080);

+

+  const _DEEP_OCEAN = new THREE.Color(0x20020FF);

+  const _SHALLOW_OCEAN = new THREE.Color(0x8080FF);

+  const _BEACH = new THREE.Color(0xd9d592);

+  const _SNOW = new THREE.Color(0xFFFFFF);

+  const _FOREST_BOREAL = new THREE.Color(0x29c100);

+
+  const _GREEN = new THREE.Color(0x80FF80);

+  const _RED = new THREE.Color(0xFF8080);

+  const _BLACK = new THREE.Color(0x000000);

+

+

+  class FixedHeightGenerator {

+    constructor() {}

+
+    Get() {

+      return [50, 1];

+    }

+  }

+
+

+  class FixedColourGenerator {

+    constructor(params) {

+      this._params = params;

+    }

+
+    Get() {

+      return this._params.colour;

+    }

+  }

+

+

+  class HeightGenerator {

+    constructor(generator, position, minRadius, maxRadius) {

+      this._position = position.clone();

+      this._radius = [minRadius, maxRadius];

+      this._generator = generator;

+    }

+

+    Get(x, y, z) {

+      return [this._generator.Get(x, y, z), 1];

+    }

+  }

+

+

+  class TextureSplatter {

+    constructor(params) {

+      const _colourLerp = (t, p0, p1) => {

+        const c = p0.clone();

+

+        return c.lerp(p1, t);

+      };

+      this._colourSpline = [

+        new spline.LinearSpline(_colourLerp),

+        new spline.LinearSpline(_colourLerp)

+      ];

+

+      // Arid

+      this._colourSpline[0].AddPoint(0.0, new THREE.Color(0xb7a67d));

+      this._colourSpline[0].AddPoint(0.5, new THREE.Color(0xf1e1bc));

+      this._colourSpline[0].AddPoint(1.0, _SNOW);

+

+      // Humid

+      this._colourSpline[1].AddPoint(0.0, _FOREST_BOREAL);

+      this._colourSpline[1].AddPoint(0.5, new THREE.Color(0xcee59c));

+      this._colourSpline[1].AddPoint(1.0, _SNOW);

+

+      this._oceanSpline = new spline.LinearSpline(_colourLerp);

+      this._oceanSpline.AddPoint(0, _DEEP_OCEAN);

+      this._oceanSpline.AddPoint(0.03, _SHALLOW_OCEAN);

+      this._oceanSpline.AddPoint(0.05, _SHALLOW_OCEAN);

+

+      this._params = params;

+    }

+

+    _BaseColour(x, y, z) {

+      const m = this._params.biomeGenerator.Get(x, y, z);

+      const h = math.sat(z / 100.0);

+

+      const c1 = this._colourSpline[0].Get(h);

+      const c2 = this._colourSpline[1].Get(h);

+

+      let c = c1.lerp(c2, m);

+

+      if (h < 0.1) {

+        c = c.lerp(new THREE.Color(0x54380e), 1.0 - math.sat(h / 0.05));

+      }

+      return c;
+    }

+

+    _Colour(x, y, z) {

+      const c = this._BaseColour(x, y, z);

+      const r = this._params.colourNoise.Get(x, y, z) * 2.0 - 1.0;

+

+      c.offsetHSL(0.0, 0.0, r * 0.01);

+      return c;

+    }

+

+    _GetTextureWeights(p, n, up) {

+      const m = this._params.biomeGenerator.Get(p.x, p.y, p.z);

+      const h = p.z / _HEIGHT_NORMALIZATION;

+

+      const types = {

+        dirt: {index: 0, strength: 0.0},

+        grass: {index: 1, strength: 0.0},

+        gravel: {index: 2, strength: 0.0},

+        rock: {index: 3, strength: 0.0},

+        snow: {index: 4, strength: 0.0},

+        snowrock: {index: 5, strength: 0.0},

+        cobble: {index: 6, strength: 0.0},

+        sandyrock: {index: 7, strength: 0.0},

+      };

+

+      function _ApplyWeights(dst, v, m) {

+        for (let k in types) {

+          types[k].strength *= m;

+        }

+        types[dst].strength = v;

+      };

+

+      types.grass.strength = 1.0;

+      _ApplyWeights('gravel', 1.0 - m, m);

+

+      if (h < 0.2) {

+        const s = 1.0 - math.sat((h - 0.1) / 0.05);

+        _ApplyWeights('cobble', s, 1.0 - s);

+

+        if (h < 0.1) {

+          const s = 1.0 - math.sat((h - 0.05) / 0.05);

+          _ApplyWeights('sandyrock', s, 1.0 - s);

+        }

+      } else {

+        if (h > 0.125) {

+          const s = (math.sat((h - 0.125) / 1.25));

+          _ApplyWeights('rock', s, 1.0 - s);

+        }

+

+        if (h > 1.5) {

+          const s = math.sat((h - 0.75) / 2.0);

+          _ApplyWeights('snow', s, 1.0 - s);

+        }

+      }

+

+      // In case nothing gets set.

+      types.dirt.strength = 0.01;

+

+      let total = 0.0;

+      for (let k in types) {

+        total += types[k].strength;

+      }

+      if (total < 0.01) {

+        const a = 0;

+      }

+      const normalization = 1.0 / total;

+

+      for (let k in types) {

+        types[k].strength / normalization;

+      }

+

+      return types;

+    }

+

+    GetColour(position) {

+      return this._Colour(position.x, position.y, position.z);

+    }

+

+    GetSplat(position, normal, up) {

+      return this._GetTextureWeights(position, normal, up);

+    }

+  }

+

+  return {

+    HeightGenerator: HeightGenerator,

+    TextureSplatter: TextureSplatter,

+  }

+})();

+ 80 - 0
src/textures.js
View File

@@ -0,0 +1,80 @@

+import * as THREE from 'https://cdn.jsdelivr.net/npm/[email protected]/build/three.module.js';

+

+

+export const textures = (function() {

+

+  // Taken from https://github.com/mrdoob/three.js/issues/758

+  function _GetImageData( image ) {

+    var canvas = document.createElement('canvas');

+    canvas.width = image.width;

+    canvas.height = image.height;

+

+    var context = canvas.getContext('2d');

+    context.drawImage( image, 0, 0 );

+

+    return context.getImageData( 0, 0, image.width, image.height );

+  }

+

+  return {

+    TextureAtlas: class {

+      constructor(params) {

+        this.game_ = params.game;

+        this.Create_();

+        this.onLoad = () => {};

+      }

+

+      Load(atlas, names) {

+        this.LoadAtlas_(atlas, names);

+      }

+

+      Create_() {

+        this.manager_ = new THREE.LoadingManager();

+        this.loader_ = new THREE.TextureLoader(this.manager_);

+        this.textures_ = {};

+

+        this.manager_.onLoad = () => {

+          this.OnLoad_();

+        };

+      }

+

+      get Info() {

+        return this.textures_;

+      }

+

+      OnLoad_() {

+        for (let k in this.textures_) {

+          const atlas = this.textures_[k];

+          const data = new Uint8Array(atlas.textures.length * 4 * 1024 * 1024);

+

+          for (let t = 0; t < atlas.textures.length; t++) {

+            const curTexture = atlas.textures[t];

+            const curData = _GetImageData(curTexture.image);

+            const offset = t * (4 * 1024 * 1024);

+

+            data.set(curData.data, offset);

+          }

+
+          const diffuse = new THREE.DataTexture2DArray(data, 1024, 1024, atlas.textures.length);

+          diffuse.format = THREE.RGBAFormat;

+          diffuse.type = THREE.UnsignedByteType;

+          diffuse.minFilter = THREE.LinearMipMapLinearFilter;

+          diffuse.magFilter = THREE.LinearFilter;

+          diffuse.wrapS = THREE.RepeatWrapping;

+          diffuse.wrapT = THREE.RepeatWrapping;

+          diffuse.generateMipmaps = true;

+          diffuse.encoding = THREE.sRGBEncoding;

+

+          atlas.atlas = diffuse;

+        }

+

+        this.onLoad();

+      }

+

+      LoadAtlas_(atlas, names) {

+        this.textures_[atlas] = {

+          textures: names.map(n => this.loader_.load(n))

+        };

+      }

+    }

+  };

+})();

+ 21 - 0
src/utils.js
View File

@@ -0,0 +1,21 @@

+export const utils = (function() {

+  return {

+    DictIntersection: function(dictA, dictB) {

+      const intersection = {};

+      for (let k in dictB) {

+        if (k in dictA) {

+          intersection[k] = dictA[k];

+        }

+      }

+      return intersection

+    },

+

+    DictDifference: function(dictA, dictB) {

+      const diff = {...dictA};

+      for (let k in dictB) {

+        delete diff[k];

+      }

+      return diff;

+    }

+  };

+})();
