@@ -0,0 +1,253 @@
|
|
|
+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js webgl - Light Shafts</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
+ <style>
|
|
|
+ body {
|
|
|
+ font-family: Monospace;
|
|
|
+ background-color: #000;
|
|
|
+ color: #fff;
|
|
|
+ margin: 0px;
|
|
|
+ overflow: hidden;
|
|
|
+ }
|
|
|
+ #info {
|
|
|
+ color: #fff;
|
|
|
+ position: absolute;
|
|
|
+ top: 10px;
|
|
|
+ width: 100%;
|
|
|
+ text-align: center;
|
|
|
+ z-index: 100;
|
|
|
+ display:block;
|
|
|
+ }
|
|
|
+ #info a {
|
|
|
+ color: #ffffff;
|
|
|
+ font-weight: bold;
|
|
|
+ }
|
|
|
+ </style>
|
|
|
+ </head>
|
|
|
+
|
|
|
+ <body>
|
|
|
+ <div id="info">
|
|
|
+ <a href="http://threejs.org" target="_blank" rel="noopener">three.js</a> - Light Shafts -
|
|
|
+ Model by <a href="https://skfb.ly/6ICER" target="_blank" rel="noopener">Splodeman</a><br />
|
|
|
+ </div>
|
|
|
+
|
|
|
+ <script src="../build/three.js"></script>
|
|
|
+
|
|
|
+ <script src="js/controls/OrbitControls.js"></script>
|
|
|
+ <script src="js/loaders/GLTFLoader.js"></script>
|
|
|
+
|
|
|
+ <script src="js/WebGL.js"></script>
|
|
|
+
|
|
|
+ <script type="x-shader/x-vertex" id="vertexShader">
|
|
|
+
|
|
|
+ #include <common>
|
|
|
+
|
|
|
+ uniform float speed;
|
|
|
+ uniform float time;
|
|
|
+ uniform float timeOffset;
|
|
|
+ varying vec2 vUv;
|
|
|
+ varying float vAlpha;
|
|
|
+
|
|
|
+ void main() {
|
|
|
+
|
|
|
+ vec3 pos = position;
|
|
|
+
|
|
|
+ float l = ( time * speed * 0.01 ) + timeOffset;
|
|
|
+ float f = fract( l ); // linear time factor [0,1)
|
|
|
+ float a = f * f; // quadratic time factor [0,1)
|
|
|
+
|
|
|
+ // slightly animate the vertices of light shaft if necessary
|
|
|
+
|
|
|
+ // pos.x += cos( l * 20.0 ) * sin( l * 10.0 );
|
|
|
+
|
|
|
+ vAlpha = saturate( 0.7 + min( 1.0, a * 10.0 ) * ( sin( a * 40.0 ) * 0.25 ) );
|
|
|
+
|
|
|
+ vUv = uv;
|
|
|
+
|
|
|
+ gl_Position = projectionMatrix * modelViewMatrix * vec4( pos, 1.0 );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script type="x-shader/x-fragment" id="fragmentShader">
|
|
|
+
|
|
|
+ uniform float attenuation;
|
|
|
+ uniform vec3 color;
|
|
|
+ uniform sampler2D texture;
|
|
|
+
|
|
|
+ varying vec2 vUv;
|
|
|
+ varying float vAlpha;
|
|
|
+
|
|
|
+ void main() {
|
|
|
+
|
|
|
+ vec4 textureColor = texture2D( texture, vUv );
|
|
|
+ gl_FragColor = vec4( textureColor.rgb * color.rgb, textureColor.a * vAlpha );
|
|
|
+ gl_FragColor.a *= pow( gl_FragCoord.z, attenuation );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script>
|
|
|
+
|
|
|
+ if ( WEBGL.isWebGLAvailable() === false ) {
|
|
|
+
|
|
|
+ document.body.appendChild( WEBGL.getWebGLErrorMessage() );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ var container, controls, clock;
|
|
|
+ var camera, scene, renderer, uniforms;
|
|
|
+
|
|
|
+ init();
|
|
|
+ animate();
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ container = document.createElement( 'div' );
|
|
|
+ document.body.appendChild( container );
|
|
|
+
|
|
|
+ camera = new THREE.PerspectiveCamera( 45, window.innerWidth / window.innerHeight, 0.1, 100 );
|
|
|
+ camera.position.set( 3.2, 3, 3.7 );
|
|
|
+
|
|
|
+ controls = new THREE.OrbitControls( camera );
|
|
|
+ controls.target.set( 0.5, 1.5, 0 );
|
|
|
+ controls.minDistance = 2;
|
|
|
+ controls.maxDistance = 20;
|
|
|
+ controls.update();
|
|
|
+
|
|
|
+ clock = new THREE.Clock();
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+ scene.background = new THREE.Color( 0xcf8b74 );
|
|
|
+
|
|
|
+ var light = new THREE.HemisphereLight( 0xffffff, 0x444444 );
|
|
|
+ light.position.set( 0, 20, 0 );
|
|
|
+ scene.add( light );
|
|
|
+
|
|
|
+ light = new THREE.DirectionalLight( 0xffffff );
|
|
|
+ light.position.set( 0, 20, 10 );
|
|
|
+ scene.add( light );
|
|
|
+
|
|
|
+ // light shafts definition
|
|
|
+
|
|
|
+ var textureLoader = new THREE.TextureLoader();
|
|
|
+ var texture = textureLoader.load( 'textures/lightShaft.png' );
|
|
|
+
|
|
|
+ uniforms = {
|
|
|
+ // controls how fast the ray attenuates when the camera comes closer
|
|
|
+ attenuation: {
|
|
|
+ value: 10
|
|
|
+ },
|
|
|
+ // controls the speed of the animation
|
|
|
+ speed: {
|
|
|
+ value: 2
|
|
|
+ },
|
|
|
+ // the color of the ray
|
|
|
+ color: {
|
|
|
+ value: new THREE.Color( 0xdadc9f )
|
|
|
+ },
|
|
|
+ // the visual representation of the ray highly depends on the used texture
|
|
|
+ texture: {
|
|
|
+ value: texture
|
|
|
+ },
|
|
|
+ // global time value for animation
|
|
|
+ time: {
|
|
|
+ value: 0
|
|
|
+ },
|
|
|
+ // individual time offset so rays are animated differently if necessary
|
|
|
+ timeOffset: {
|
|
|
+ value: 0
|
|
|
+ }
|
|
|
+ };
|
|
|
+
|
|
|
+ var lightShaftMaterial = new THREE.ShaderMaterial( {
|
|
|
+ uniforms: uniforms,
|
|
|
+ vertexShader: document.getElementById( 'vertexShader' ).textContent,
|
|
|
+ fragmentShader: document.getElementById( 'fragmentShader' ).textContent,
|
|
|
+ blending: THREE.AdditiveBlending,
|
|
|
+ depthWrite: false,
|
|
|
+ transparent: true,
|
|
|
+ side: THREE.DoubleSide
|
|
|
+ } );
|
|
|
+
|
|
|
+ var lightShaftGeometry = new THREE.PlaneBufferGeometry( 0.5, 5 );
|
|
|
+
|
|
|
+ // model
|
|
|
+
|
|
|
+ var loader = new THREE.GLTFLoader().setPath( 'models/gltf/Tree/' );
|
|
|
+ loader.load( 'tree.glb', function ( gltf ) {
|
|
|
+
|
|
|
+ gltf.scene.traverse( function ( child ) {
|
|
|
+
|
|
|
+ if ( child.isMesh ) {
|
|
|
+
|
|
|
+ child.material.transparent = false;
|
|
|
+ child.material.alphaTest = 0.5;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ scene.add( gltf.scene );
|
|
|
+
|
|
|
+ // when the model is loaded, add light shafts
|
|
|
+
|
|
|
+ for ( var i = 0; i < 5; i ++ ) {
|
|
|
+
|
|
|
+ var lightShaft = new THREE.Mesh( lightShaftGeometry, lightShaftMaterial );
|
|
|
+ lightShaft.position.x = - 1 + 1.5 * Math.sign( ( i % 2 ) );
|
|
|
+ lightShaft.position.y = 2;
|
|
|
+ lightShaft.position.z = - 1.5 + ( i * 0.5 );
|
|
|
+ lightShaft.rotation.y = Math.PI * 0.2;
|
|
|
+ lightShaft.rotation.z = Math.PI * - ( 0.15 + 0.1 * Math.random() );
|
|
|
+ scene.add( lightShaft );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ renderer = new THREE.WebGLRenderer( { antialias: true } );
|
|
|
+ renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ renderer.gammaOutput = true;
|
|
|
+ renderer.gammaFactor = 2.2;
|
|
|
+ container.appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', onWindowResize, false );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onWindowResize() {
|
|
|
+
|
|
|
+ camera.aspect = window.innerWidth / window.innerHeight;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ function animate() {
|
|
|
+
|
|
|
+ requestAnimationFrame( animate );
|
|
|
+
|
|
|
+ const delta = clock.getDelta();
|
|
|
+
|
|
|
+ uniforms.time.value += delta;
|
|
|
+
|
|
|
+ renderer.render( scene, camera );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ </body>
|
|
|
+</html>
|
