@@ -1,618 +1,1430 @@
|
|
|
-import { glsl } from '../../code/CodeNode.js';
|
|
|
-import { glslFn } from '../../code/FunctionNode.js';
|
|
|
-
|
|
|
-// Original shader code from:
|
|
|
-// https://github.com/AcademySoftwareFoundation/MaterialX/blob/main/libraries/stdlib/genglsl/lib/mx_noise.glsl
|
|
|
-
|
|
|
-export const mx_noise = glsl( `float mx_select(bool b, float t, float f)
|
|
|
-{
|
|
|
- return b ? t : f;
|
|
|
-}
|
|
|
-
|
|
|
-float mx_negate_if(float val, bool b)
|
|
|
-{
|
|
|
- return b ? -val : val;
|
|
|
-}
|
|
|
-
|
|
|
-int mx_floor(float x)
|
|
|
-{
|
|
|
- return int(floor(x));
|
|
|
-}
|
|
|
-
|
|
|
-// return mx_floor as well as the fractional remainder
|
|
|
-float mx_floorfrac(float x, out int i)
|
|
|
-{
|
|
|
- i = mx_floor(x);
|
|
|
- return x - float(i);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_bilerp(float v0, float v1, float v2, float v3, float s, float t)
|
|
|
-{
|
|
|
- float s1 = 1.0 - s;
|
|
|
- return (1.0 - t) * (v0*s1 + v1*s) + t * (v2*s1 + v3*s);
|
|
|
-}
|
|
|
-vec3 mx_bilerp(vec3 v0, vec3 v1, vec3 v2, vec3 v3, float s, float t)
|
|
|
-{
|
|
|
- float s1 = 1.0 - s;
|
|
|
- return (1.0 - t) * (v0*s1 + v1*s) + t * (v2*s1 + v3*s);
|
|
|
-}
|
|
|
-float mx_trilerp(float v0, float v1, float v2, float v3, float v4, float v5, float v6, float v7, float s, float t, float r)
|
|
|
-{
|
|
|
- float s1 = 1.0 - s;
|
|
|
- float t1 = 1.0 - t;
|
|
|
- float r1 = 1.0 - r;
|
|
|
- return (r1*(t1*(v0*s1 + v1*s) + t*(v2*s1 + v3*s)) +
|
|
|
- r*(t1*(v4*s1 + v5*s) + t*(v6*s1 + v7*s)));
|
|
|
-}
|
|
|
-vec3 mx_trilerp(vec3 v0, vec3 v1, vec3 v2, vec3 v3, vec3 v4, vec3 v5, vec3 v6, vec3 v7, float s, float t, float r)
|
|
|
-{
|
|
|
- float s1 = 1.0 - s;
|
|
|
- float t1 = 1.0 - t;
|
|
|
- float r1 = 1.0 - r;
|
|
|
- return (r1*(t1*(v0*s1 + v1*s) + t*(v2*s1 + v3*s)) +
|
|
|
- r*(t1*(v4*s1 + v5*s) + t*(v6*s1 + v7*s)));
|
|
|
-}
|
|
|
-
|
|
|
-// 2 and 3 dimensional gradient functions - perform a dot product against a
|
|
|
-// randomly chosen vector. Note that the gradient vector is not normalized, but
|
|
|
-// this only affects the overal "scale" of the result, so we simply account for
|
|
|
-// the scale by multiplying in the corresponding "perlin" function.
|
|
|
-float mx_gradient_float(uint hash, float x, float y)
|
|
|
-{
|
|
|
- // 8 possible directions (+-1,+-2) and (+-2,+-1)
|
|
|
- uint h = hash & 7u;
|
|
|
- float u = mx_select(h<4u, x, y);
|
|
|
- float v = 2.0 * mx_select(h<4u, y, x);
|
|
|
- // compute the dot product with (x,y).
|
|
|
- return mx_negate_if(u, bool(h&1u)) + mx_negate_if(v, bool(h&2u));
|
|
|
-}
|
|
|
-float mx_gradient_float(uint hash, float x, float y, float z)
|
|
|
-{
|
|
|
- // use vectors pointing to the edges of the cube
|
|
|
- uint h = hash & 15u;
|
|
|
- float u = mx_select(h<8u, x, y);
|
|
|
- float v = mx_select(h<4u, y, mx_select((h==12u)||(h==14u), x, z));
|
|
|
- return mx_negate_if(u, bool(h&1u)) + mx_negate_if(v, bool(h&2u));
|
|
|
-}
|
|
|
-vec3 mx_gradient_vec3(uvec3 hash, float x, float y)
|
|
|
-{
|
|
|
- return vec3(mx_gradient_float(hash.x, x, y), mx_gradient_float(hash.y, x, y), mx_gradient_float(hash.z, x, y));
|
|
|
-}
|
|
|
-vec3 mx_gradient_vec3(uvec3 hash, float x, float y, float z)
|
|
|
-{
|
|
|
- return vec3(mx_gradient_float(hash.x, x, y, z), mx_gradient_float(hash.y, x, y, z), mx_gradient_float(hash.z, x, y, z));
|
|
|
-}
|
|
|
-// Scaling factors to normalize the result of gradients above.
|
|
|
-// These factors were experimentally calculated to be:
|
|
|
-// 2D: 0.6616
|
|
|
-// 3D: 0.9820
|
|
|
-float mx_gradient_scale2d(float v) { return 0.6616 * v; }
|
|
|
-float mx_gradient_scale3d(float v) { return 0.9820 * v; }
|
|
|
-vec3 mx_gradient_scale2d(vec3 v) { return 0.6616 * v; }
|
|
|
-vec3 mx_gradient_scale3d(vec3 v) { return 0.9820 * v; }
|
|
|
-
|
|
|
-/// Bitwise circular rotation left by k bits (for 32 bit unsigned integers)
|
|
|
-uint mx_rotl32(uint x, int k)
|
|
|
-{
|
|
|
- return (x<<k) | (x>>(32-k));
|
|
|
-}
|
|
|
-
|
|
|
-void mx_bjmix(inout uint a, inout uint b, inout uint c)
|
|
|
-{
|
|
|
- a -= c; a ^= mx_rotl32(c, 4); c += b;
|
|
|
- b -= a; b ^= mx_rotl32(a, 6); a += c;
|
|
|
- c -= b; c ^= mx_rotl32(b, 8); b += a;
|
|
|
- a -= c; a ^= mx_rotl32(c,16); c += b;
|
|
|
- b -= a; b ^= mx_rotl32(a,19); a += c;
|
|
|
- c -= b; c ^= mx_rotl32(b, 4); b += a;
|
|
|
-}
|
|
|
-
|
|
|
-// Mix up and combine the bits of a, b, and c (doesn't change them, but
|
|
|
-// returns a hash of those three original values).
|
|
|
-uint mx_bjfinal(uint a, uint b, uint c)
|
|
|
-{
|
|
|
- c ^= b; c -= mx_rotl32(b,14);
|
|
|
- a ^= c; a -= mx_rotl32(c,11);
|
|
|
- b ^= a; b -= mx_rotl32(a,25);
|
|
|
- c ^= b; c -= mx_rotl32(b,16);
|
|
|
- a ^= c; a -= mx_rotl32(c,4);
|
|
|
- b ^= a; b -= mx_rotl32(a,14);
|
|
|
- c ^= b; c -= mx_rotl32(b,24);
|
|
|
- return c;
|
|
|
-}
|
|
|
-
|
|
|
-// Convert a 32 bit integer into a floating point number in [0,1]
|
|
|
-float mx_bits_to_01(uint bits)
|
|
|
-{
|
|
|
- return float(bits) / float(uint(0xffffffff));
|
|
|
-}
|
|
|
-
|
|
|
-float mx_fade(float t)
|
|
|
-{
|
|
|
- return t * t * t * (t * (t * 6.0 - 15.0) + 10.0);
|
|
|
-}
|
|
|
-
|
|
|
-uint mx_hash_int(int x)
|
|
|
-{
|
|
|
- uint len = 1u;
|
|
|
- uint seed = uint(0xdeadbeef) + (len << 2u) + 13u;
|
|
|
- return mx_bjfinal(seed+uint(x), seed, seed);
|
|
|
-}
|
|
|
-
|
|
|
-uint mx_hash_int(int x, int y)
|
|
|
-{
|
|
|
- uint len = 2u;
|
|
|
- uint a, b, c;
|
|
|
- a = b = c = uint(0xdeadbeef) + (len << 2u) + 13u;
|
|
|
- a += uint(x);
|
|
|
- b += uint(y);
|
|
|
- return mx_bjfinal(a, b, c);
|
|
|
-}
|
|
|
-
|
|
|
-uint mx_hash_int(int x, int y, int z)
|
|
|
-{
|
|
|
- uint len = 3u;
|
|
|
- uint a, b, c;
|
|
|
- a = b = c = uint(0xdeadbeef) + (len << 2u) + 13u;
|
|
|
- a += uint(x);
|
|
|
- b += uint(y);
|
|
|
- c += uint(z);
|
|
|
- return mx_bjfinal(a, b, c);
|
|
|
-}
|
|
|
-
|
|
|
-uint mx_hash_int(int x, int y, int z, int xx)
|
|
|
-{
|
|
|
- uint len = 4u;
|
|
|
- uint a, b, c;
|
|
|
- a = b = c = uint(0xdeadbeef) + (len << 2u) + 13u;
|
|
|
- a += uint(x);
|
|
|
- b += uint(y);
|
|
|
- c += uint(z);
|
|
|
- mx_bjmix(a, b, c);
|
|
|
- a += uint(xx);
|
|
|
- return mx_bjfinal(a, b, c);
|
|
|
-}
|
|
|
-
|
|
|
-uint mx_hash_int(int x, int y, int z, int xx, int yy)
|
|
|
-{
|
|
|
- uint len = 5u;
|
|
|
- uint a, b, c;
|
|
|
- a = b = c = uint(0xdeadbeef) + (len << 2u) + 13u;
|
|
|
- a += uint(x);
|
|
|
- b += uint(y);
|
|
|
- c += uint(z);
|
|
|
- mx_bjmix(a, b, c);
|
|
|
- a += uint(xx);
|
|
|
- b += uint(yy);
|
|
|
- return mx_bjfinal(a, b, c);
|
|
|
-}
|
|
|
-
|
|
|
-uvec3 mx_hash_vec3(int x, int y)
|
|
|
-{
|
|
|
- uint h = mx_hash_int(x, y);
|
|
|
- // we only need the low-order bits to be random, so split out
|
|
|
- // the 32 bit result into 3 parts for each channel
|
|
|
- uvec3 result;
|
|
|
- result.x = (h ) & 0xFFu;
|
|
|
- result.y = (h >> 8 ) & 0xFFu;
|
|
|
- result.z = (h >> 16) & 0xFFu;
|
|
|
- return result;
|
|
|
-}
|
|
|
-
|
|
|
-uvec3 mx_hash_vec3(int x, int y, int z)
|
|
|
-{
|
|
|
- uint h = mx_hash_int(x, y, z);
|
|
|
- // we only need the low-order bits to be random, so split out
|
|
|
- // the 32 bit result into 3 parts for each channel
|
|
|
- uvec3 result;
|
|
|
- result.x = (h ) & 0xFFu;
|
|
|
- result.y = (h >> 8 ) & 0xFFu;
|
|
|
- result.z = (h >> 16) & 0xFFu;
|
|
|
- return result;
|
|
|
-}
|
|
|
-
|
|
|
-float mx_perlin_noise_float(vec2 p)
|
|
|
-{
|
|
|
- int X, Y;
|
|
|
- float fx = mx_floorfrac(p.x, X);
|
|
|
- float fy = mx_floorfrac(p.y, Y);
|
|
|
- float u = mx_fade(fx);
|
|
|
- float v = mx_fade(fy);
|
|
|
- float result = mx_bilerp(
|
|
|
- mx_gradient_float(mx_hash_int(X , Y ), fx , fy ),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y ), fx-1.0, fy ),
|
|
|
- mx_gradient_float(mx_hash_int(X , Y+1), fx , fy-1.0),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y+1), fx-1.0, fy-1.0),
|
|
|
- u, v);
|
|
|
- return mx_gradient_scale2d(result);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_perlin_noise_float(vec3 p)
|
|
|
-{
|
|
|
- int X, Y, Z;
|
|
|
- float fx = mx_floorfrac(p.x, X);
|
|
|
- float fy = mx_floorfrac(p.y, Y);
|
|
|
- float fz = mx_floorfrac(p.z, Z);
|
|
|
- float u = mx_fade(fx);
|
|
|
- float v = mx_fade(fy);
|
|
|
- float w = mx_fade(fz);
|
|
|
- float result = mx_trilerp(
|
|
|
- mx_gradient_float(mx_hash_int(X , Y , Z ), fx , fy , fz ),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y , Z ), fx-1.0, fy , fz ),
|
|
|
- mx_gradient_float(mx_hash_int(X , Y+1, Z ), fx , fy-1.0, fz ),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y+1, Z ), fx-1.0, fy-1.0, fz ),
|
|
|
- mx_gradient_float(mx_hash_int(X , Y , Z+1), fx , fy , fz-1.0),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y , Z+1), fx-1.0, fy , fz-1.0),
|
|
|
- mx_gradient_float(mx_hash_int(X , Y+1, Z+1), fx , fy-1.0, fz-1.0),
|
|
|
- mx_gradient_float(mx_hash_int(X+1, Y+1, Z+1), fx-1.0, fy-1.0, fz-1.0),
|
|
|
- u, v, w);
|
|
|
- return mx_gradient_scale3d(result);
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_perlin_noise_vec3(vec2 p)
|
|
|
-{
|
|
|
- int X, Y;
|
|
|
- float fx = mx_floorfrac(p.x, X);
|
|
|
- float fy = mx_floorfrac(p.y, Y);
|
|
|
- float u = mx_fade(fx);
|
|
|
- float v = mx_fade(fy);
|
|
|
- vec3 result = mx_bilerp(
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y ), fx , fy ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y ), fx-1.0, fy ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y+1), fx , fy-1.0),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y+1), fx-1.0, fy-1.0),
|
|
|
- u, v);
|
|
|
- return mx_gradient_scale2d(result);
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_perlin_noise_vec3(vec3 p)
|
|
|
-{
|
|
|
- int X, Y, Z;
|
|
|
- float fx = mx_floorfrac(p.x, X);
|
|
|
- float fy = mx_floorfrac(p.y, Y);
|
|
|
- float fz = mx_floorfrac(p.z, Z);
|
|
|
- float u = mx_fade(fx);
|
|
|
- float v = mx_fade(fy);
|
|
|
- float w = mx_fade(fz);
|
|
|
- vec3 result = mx_trilerp(
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y , Z ), fx , fy , fz ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y , Z ), fx-1.0, fy , fz ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y+1, Z ), fx , fy-1.0, fz ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y+1, Z ), fx-1.0, fy-1.0, fz ),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y , Z+1), fx , fy , fz-1.0),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y , Z+1), fx-1.0, fy , fz-1.0),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X , Y+1, Z+1), fx , fy-1.0, fz-1.0),
|
|
|
- mx_gradient_vec3(mx_hash_vec3(X+1, Y+1, Z+1), fx-1.0, fy-1.0, fz-1.0),
|
|
|
- u, v, w);
|
|
|
- return mx_gradient_scale3d(result);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_cell_noise_float(float p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p);
|
|
|
- return mx_bits_to_01(mx_hash_int(ix));
|
|
|
-}
|
|
|
-
|
|
|
-float mx_cell_noise_float(vec2 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- return mx_bits_to_01(mx_hash_int(ix, iy));
|
|
|
-}
|
|
|
-
|
|
|
-float mx_cell_noise_float(vec3 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- int iz = mx_floor(p.z);
|
|
|
- return mx_bits_to_01(mx_hash_int(ix, iy, iz));
|
|
|
-}
|
|
|
-
|
|
|
-float mx_cell_noise_float(vec4 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- int iz = mx_floor(p.z);
|
|
|
- int iw = mx_floor(p.w);
|
|
|
- return mx_bits_to_01(mx_hash_int(ix, iy, iz, iw));
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_cell_noise_vec3(float p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p);
|
|
|
- return vec3(
|
|
|
- mx_bits_to_01(mx_hash_int(ix, 0)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, 1)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, 2))
|
|
|
- );
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_cell_noise_vec3(vec2 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- return vec3(
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, 0)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, 1)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, 2))
|
|
|
- );
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_cell_noise_vec3(vec3 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- int iz = mx_floor(p.z);
|
|
|
- return vec3(
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, 0)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, 1)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, 2))
|
|
|
- );
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_cell_noise_vec3(vec4 p)
|
|
|
-{
|
|
|
- int ix = mx_floor(p.x);
|
|
|
- int iy = mx_floor(p.y);
|
|
|
- int iz = mx_floor(p.z);
|
|
|
- int iw = mx_floor(p.w);
|
|
|
- return vec3(
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, iw, 0)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, iw, 1)),
|
|
|
- mx_bits_to_01(mx_hash_int(ix, iy, iz, iw, 2))
|
|
|
- );
|
|
|
-}
|
|
|
-
|
|
|
-float mx_fractal_noise_float(vec3 p, int octaves, float lacunarity, float diminish)
|
|
|
-{
|
|
|
- float result = 0.0;
|
|
|
- float amplitude = 1.0;
|
|
|
- for (int i = 0; i < octaves; ++i)
|
|
|
- {
|
|
|
- result += amplitude * mx_perlin_noise_float(p);
|
|
|
- amplitude *= diminish;
|
|
|
- p *= lacunarity;
|
|
|
- }
|
|
|
- return result;
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_fractal_noise_vec3(vec3 p, int octaves, float lacunarity, float diminish)
|
|
|
-{
|
|
|
- vec3 result = vec3(0.0);
|
|
|
- float amplitude = 1.0;
|
|
|
- for (int i = 0; i < octaves; ++i)
|
|
|
- {
|
|
|
- result += amplitude * mx_perlin_noise_vec3(p);
|
|
|
- amplitude *= diminish;
|
|
|
- p *= lacunarity;
|
|
|
- }
|
|
|
- return result;
|
|
|
-}
|
|
|
-
|
|
|
-vec2 mx_fractal_noise_vec2(vec3 p, int octaves, float lacunarity, float diminish)
|
|
|
-{
|
|
|
- return vec2(mx_fractal_noise_float(p, octaves, lacunarity, diminish),
|
|
|
- mx_fractal_noise_float(p+vec3(19, 193, 17), octaves, lacunarity, diminish));
|
|
|
-}
|
|
|
-
|
|
|
-vec4 mx_fractal_noise_vec4(vec3 p, int octaves, float lacunarity, float diminish)
|
|
|
-{
|
|
|
- vec3 c = mx_fractal_noise_vec3(p, octaves, lacunarity, diminish);
|
|
|
- float f = mx_fractal_noise_float(p+vec3(19, 193, 17), octaves, lacunarity, diminish);
|
|
|
- return vec4(c, f);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_worley_distance(vec2 p, int x, int y, int xoff, int yoff, float jitter, int metric)
|
|
|
-{
|
|
|
- vec3 tmp = mx_cell_noise_vec3(vec2(x+xoff, y+yoff));
|
|
|
- vec2 off = vec2(tmp.x, tmp.y);
|
|
|
-
|
|
|
- off -= 0.5f;
|
|
|
- off *= jitter;
|
|
|
- off += 0.5f;
|
|
|
-
|
|
|
- vec2 cellpos = vec2(float(x), float(y)) + off;
|
|
|
- vec2 diff = cellpos - p;
|
|
|
- if (metric == 2)
|
|
|
- return abs(diff.x) + abs(diff.y); // Manhattan distance
|
|
|
- if (metric == 3)
|
|
|
- return max(abs(diff.x), abs(diff.y)); // Chebyshev distance
|
|
|
- // Either Euclidian or Distance^2
|
|
|
- return dot(diff, diff);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_worley_distance(vec3 p, int x, int y, int z, int xoff, int yoff, int zoff, float jitter, int metric)
|
|
|
-{
|
|
|
- vec3 off = mx_cell_noise_vec3(vec3(x+xoff, y+yoff, z+zoff));
|
|
|
-
|
|
|
- off -= 0.5f;
|
|
|
- off *= jitter;
|
|
|
- off += 0.5f;
|
|
|
-
|
|
|
- vec3 cellpos = vec3(float(x), float(y), float(z)) + off;
|
|
|
- vec3 diff = cellpos - p;
|
|
|
- if (metric == 2)
|
|
|
- return abs(diff.x) + abs(diff.y) + abs(diff.z); // Manhattan distance
|
|
|
- if (metric == 3)
|
|
|
- return max(max(abs(diff.x), abs(diff.y)), abs(diff.z)); // Chebyshev distance
|
|
|
- // Either Euclidian or Distance^2
|
|
|
- return dot(diff, diff);
|
|
|
-}
|
|
|
-
|
|
|
-float mx_worley_noise_float(vec2 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y;
|
|
|
- vec2 localpos = vec2(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y));
|
|
|
- float sqdist = 1e6f; // Some big number for jitter > 1 (not all GPUs may be IEEE)
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, X, Y, jitter, metric);
|
|
|
- sqdist = min(sqdist, dist);
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}
|
|
|
-
|
|
|
-vec2 mx_worley_noise_vec2(vec2 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y;
|
|
|
- vec2 localpos = vec2(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y));
|
|
|
- vec2 sqdist = vec2(1e6f, 1e6f);
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, X, Y, jitter, metric);
|
|
|
- if (dist < sqdist.x)
|
|
|
- {
|
|
|
- sqdist.y = sqdist.x;
|
|
|
- sqdist.x = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.y)
|
|
|
- {
|
|
|
- sqdist.y = dist;
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_worley_noise_vec3(vec2 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y;
|
|
|
- vec2 localpos = vec2(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y));
|
|
|
- vec3 sqdist = vec3(1e6f, 1e6f, 1e6f);
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, X, Y, jitter, metric);
|
|
|
- if (dist < sqdist.x)
|
|
|
- {
|
|
|
- sqdist.z = sqdist.y;
|
|
|
- sqdist.y = sqdist.x;
|
|
|
- sqdist.x = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.y)
|
|
|
- {
|
|
|
- sqdist.z = sqdist.y;
|
|
|
- sqdist.y = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.z)
|
|
|
- {
|
|
|
- sqdist.z = dist;
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}
|
|
|
-
|
|
|
-float mx_worley_noise_float(vec3 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y, Z;
|
|
|
- vec3 localpos = vec3(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y), mx_floorfrac(p.z, Z));
|
|
|
- float sqdist = 1e6f;
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- for (int z = -1; z <= 1; ++z)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, z, X, Y, Z, jitter, metric);
|
|
|
- sqdist = min(sqdist, dist);
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}
|
|
|
-
|
|
|
-vec2 mx_worley_noise_vec2(vec3 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y, Z;
|
|
|
- vec3 localpos = vec3(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y), mx_floorfrac(p.z, Z));
|
|
|
- vec2 sqdist = vec2(1e6f, 1e6f);
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- for (int z = -1; z <= 1; ++z)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, z, X, Y, Z, jitter, metric);
|
|
|
- if (dist < sqdist.x)
|
|
|
- {
|
|
|
- sqdist.y = sqdist.x;
|
|
|
- sqdist.x = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.y)
|
|
|
- {
|
|
|
- sqdist.y = dist;
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}
|
|
|
-
|
|
|
-vec3 mx_worley_noise_vec3(vec3 p, float jitter, int metric)
|
|
|
-{
|
|
|
- int X, Y, Z;
|
|
|
- vec3 localpos = vec3(mx_floorfrac(p.x, X), mx_floorfrac(p.y, Y), mx_floorfrac(p.z, Z));
|
|
|
- vec3 sqdist = vec3(1e6f, 1e6f, 1e6f);
|
|
|
- for (int x = -1; x <= 1; ++x)
|
|
|
- {
|
|
|
- for (int y = -1; y <= 1; ++y)
|
|
|
- {
|
|
|
- for (int z = -1; z <= 1; ++z)
|
|
|
- {
|
|
|
- float dist = mx_worley_distance(localpos, x, y, z, X, Y, Z, jitter, metric);
|
|
|
- if (dist < sqdist.x)
|
|
|
- {
|
|
|
- sqdist.z = sqdist.y;
|
|
|
- sqdist.y = sqdist.x;
|
|
|
- sqdist.x = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.y)
|
|
|
- {
|
|
|
- sqdist.z = sqdist.y;
|
|
|
- sqdist.y = dist;
|
|
|
- }
|
|
|
- else if (dist < sqdist.z)
|
|
|
- {
|
|
|
- sqdist.z = dist;
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- }
|
|
|
- if (metric == 0)
|
|
|
- sqdist = sqrt(sqdist);
|
|
|
- return sqdist;
|
|
|
-}` );
|
|
|
-
|
|
|
-const includes = [ mx_noise ];
|
|
|
-
|
|
|
-export const mx_perlin_noise_float = glslFn( 'float mx_perlin_noise_float( any p )', includes );
|
|
|
-export const mx_perlin_noise_vec2 = glslFn( 'vec2 mx_perlin_noise_vec2( any p )', includes );
|
|
|
-export const mx_perlin_noise_vec3 = glslFn( 'vec3 mx_perlin_noise_vec3( any p )', includes );
|
|
|
-
|
|
|
-export const mx_cell_noise_float = glslFn( 'float mx_cell_noise_float( vec3 p )', includes );
|
|
|
-
|
|
|
-export const mx_worley_noise_float = glslFn( 'float mx_worley_noise_float( any p, float jitter, int metric )', includes );
|
|
|
-export const mx_worley_noise_vec2 = glslFn( 'vec2 mx_worley_noise_vec2( any p, float jitter, int metric )', includes );
|
|
|
-export const mx_worley_noise_vec3 = glslFn( 'vec3 mx_worley_noise_vec3( any p, float jitter, int metric )', includes );
|
|
|
-
|
|
|
-export const mx_fractal_noise_float = glslFn( 'float mx_fractal_noise_float( vec3 p, int octaves, float lacunarity, float diminish )', includes );
|
|
|
-export const mx_fractal_noise_vec2 = glslFn( 'vec2 mx_fractal_noise_vec2( vec3 p, int octaves, float lacunarity, float diminish )', includes );
|
|
|
-export const mx_fractal_noise_vec3 = glslFn( 'vec3 mx_fractal_noise_vec3( vec3 p, int octaves, float lacunarity, float diminish )', includes );
|
|
|
-export const mx_fractal_noise_vec4 = glslFn( 'vec4 mx_fractal_noise_vec4( vec3 p, int octaves, float lacunarity, float diminish )', includes );
|
|
|
+// Three.js Transpiler
|
|
|
+// https://raw.githubusercontent.com/AcademySoftwareFoundation/MaterialX/main/libraries/stdlib/genglsl/lib/mx_noise.glsl
|
|
|
+
|
|
|
+import { int, uint, float, vec3, bool, uvec3, vec2, vec4, If, tslFn } from '../../shadernode/ShaderNode.js';
|
|
|
+import { cond } from '../../math/CondNode.js';
|
|
|
+import { sub, mul } from '../../math/OperatorNode.js';
|
|
|
+import { floor, abs, max, dot, min, sqrt } from '../../math/MathNode.js';
|
|
|
+import { overloadingFn } from '../../utils/FunctionOverloadingNode.js';
|
|
|
+import { loop } from '../../utils/LoopNode.js';
|
|
|
+
|
|
|
+const mx_select = tslFn( ( [ b_immutable, t_immutable, f_immutable ] ) => {
|
|
|
+
|
|
|
+ const f = float( f_immutable ).toVar();
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+ const b = bool( b_immutable ).toVar();
|
|
|
+
|
|
|
+ return cond( b, t, f );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_negate_if = tslFn( ( [ val_immutable, b_immutable ] ) => {
|
|
|
+
|
|
|
+ const b = bool( b_immutable ).toVar();
|
|
|
+ const val = float( val_immutable ).toVar();
|
|
|
+
|
|
|
+ return cond( b, val.negate(), val );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_floor = tslFn( ( [ x_immutable ] ) => {
|
|
|
+
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+
|
|
|
+ return int( floor( x ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_floorfrac = tslFn( ( [ x_immutable, i ] ) => {
|
|
|
+
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+ i.assign( mx_floor( x ) );
|
|
|
+
|
|
|
+ return x.sub( float( i ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bilerp_0 = tslFn( ( [ v0_immutable, v1_immutable, v2_immutable, v3_immutable, s_immutable, t_immutable ] ) => {
|
|
|
+
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+ const s = float( s_immutable ).toVar();
|
|
|
+ const v3 = float( v3_immutable ).toVar();
|
|
|
+ const v2 = float( v2_immutable ).toVar();
|
|
|
+ const v1 = float( v1_immutable ).toVar();
|
|
|
+ const v0 = float( v0_immutable ).toVar();
|
|
|
+ const s1 = float( sub( 1.0, s ) ).toVar();
|
|
|
+
|
|
|
+ return sub( 1.0, t ).mul( v0.mul( s1 ).add( v1.mul( s ) ) ).add( t.mul( v2.mul( s1 ).add( v3.mul( s ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bilerp_1 = tslFn( ( [ v0_immutable, v1_immutable, v2_immutable, v3_immutable, s_immutable, t_immutable ] ) => {
|
|
|
+
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+ const s = float( s_immutable ).toVar();
|
|
|
+ const v3 = vec3( v3_immutable ).toVar();
|
|
|
+ const v2 = vec3( v2_immutable ).toVar();
|
|
|
+ const v1 = vec3( v1_immutable ).toVar();
|
|
|
+ const v0 = vec3( v0_immutable ).toVar();
|
|
|
+ const s1 = float( sub( 1.0, s ) ).toVar();
|
|
|
+
|
|
|
+ return sub( 1.0, t ).mul( v0.mul( s1 ).add( v1.mul( s ) ) ).add( t.mul( v2.mul( s1 ).add( v3.mul( s ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bilerp = overloadingFn( [ mx_bilerp_0, mx_bilerp_1 ] );
|
|
|
+
|
|
|
+const mx_trilerp_0 = tslFn( ( [ v0_immutable, v1_immutable, v2_immutable, v3_immutable, v4_immutable, v5_immutable, v6_immutable, v7_immutable, s_immutable, t_immutable, r_immutable ] ) => {
|
|
|
+
|
|
|
+ const r = float( r_immutable ).toVar();
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+ const s = float( s_immutable ).toVar();
|
|
|
+ const v7 = float( v7_immutable ).toVar();
|
|
|
+ const v6 = float( v6_immutable ).toVar();
|
|
|
+ const v5 = float( v5_immutable ).toVar();
|
|
|
+ const v4 = float( v4_immutable ).toVar();
|
|
|
+ const v3 = float( v3_immutable ).toVar();
|
|
|
+ const v2 = float( v2_immutable ).toVar();
|
|
|
+ const v1 = float( v1_immutable ).toVar();
|
|
|
+ const v0 = float( v0_immutable ).toVar();
|
|
|
+ const s1 = float( sub( 1.0, s ) ).toVar();
|
|
|
+ const t1 = float( sub( 1.0, t ) ).toVar();
|
|
|
+ const r1 = float( sub( 1.0, r ) ).toVar();
|
|
|
+
|
|
|
+ return r1.mul( t1.mul( v0.mul( s1 ).add( v1.mul( s ) ) ).add( t.mul( v2.mul( s1 ).add( v3.mul( s ) ) ) ) ).add( r.mul( t1.mul( v4.mul( s1 ).add( v5.mul( s ) ) ).add( t.mul( v6.mul( s1 ).add( v7.mul( s ) ) ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_trilerp_1 = tslFn( ( [ v0_immutable, v1_immutable, v2_immutable, v3_immutable, v4_immutable, v5_immutable, v6_immutable, v7_immutable, s_immutable, t_immutable, r_immutable ] ) => {
|
|
|
+
|
|
|
+ const r = float( r_immutable ).toVar();
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+ const s = float( s_immutable ).toVar();
|
|
|
+ const v7 = vec3( v7_immutable ).toVar();
|
|
|
+ const v6 = vec3( v6_immutable ).toVar();
|
|
|
+ const v5 = vec3( v5_immutable ).toVar();
|
|
|
+ const v4 = vec3( v4_immutable ).toVar();
|
|
|
+ const v3 = vec3( v3_immutable ).toVar();
|
|
|
+ const v2 = vec3( v2_immutable ).toVar();
|
|
|
+ const v1 = vec3( v1_immutable ).toVar();
|
|
|
+ const v0 = vec3( v0_immutable ).toVar();
|
|
|
+ const s1 = float( sub( 1.0, s ) ).toVar();
|
|
|
+ const t1 = float( sub( 1.0, t ) ).toVar();
|
|
|
+ const r1 = float( sub( 1.0, r ) ).toVar();
|
|
|
+
|
|
|
+ return r1.mul( t1.mul( v0.mul( s1 ).add( v1.mul( s ) ) ).add( t.mul( v2.mul( s1 ).add( v3.mul( s ) ) ) ) ).add( r.mul( t1.mul( v4.mul( s1 ).add( v5.mul( s ) ) ).add( t.mul( v6.mul( s1 ).add( v7.mul( s ) ) ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_trilerp = overloadingFn( [ mx_trilerp_0, mx_trilerp_1 ] );
|
|
|
+
|
|
|
+const mx_gradient_float_0 = tslFn( ( [ hash_immutable, x_immutable, y_immutable ] ) => {
|
|
|
+
|
|
|
+ const y = float( y_immutable ).toVar();
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+ const hash = uint( hash_immutable ).toVar();
|
|
|
+ const h = uint( hash.bitAnd( uint( 7 ) ) ).toVar();
|
|
|
+ const u = float( mx_select( h.lessThan( uint( 4 ) ), x, y ) ).toVar();
|
|
|
+ const v = float( mul( 2.0, mx_select( h.lessThan( uint( 4 ) ), y, x ) ) ).toVar();
|
|
|
+
|
|
|
+ return mx_negate_if( u, bool( h.bitAnd( uint( 1 ) ) ) ).add( mx_negate_if( v, bool( h.bitAnd( uint( 2 ) ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_float_1 = tslFn( ( [ hash_immutable, x_immutable, y_immutable, z_immutable ] ) => {
|
|
|
+
|
|
|
+ const z = float( z_immutable ).toVar();
|
|
|
+ const y = float( y_immutable ).toVar();
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+ const hash = uint( hash_immutable ).toVar();
|
|
|
+ const h = uint( hash.bitAnd( uint( 15 ) ) ).toVar();
|
|
|
+ const u = float( mx_select( h.lessThan( uint( 8 ) ), x, y ) ).toVar();
|
|
|
+ const v = float( mx_select( h.lessThan( uint( 4 ) ), y, mx_select( h.equal( uint( 12 ) ).or( h.equal( uint( 14 ) ) ), x, z ) ) ).toVar();
|
|
|
+
|
|
|
+ return mx_negate_if( u, bool( h.bitAnd( uint( 1 ) ) ) ).add( mx_negate_if( v, bool( h.bitAnd( uint( 2 ) ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_float = overloadingFn( [ mx_gradient_float_0, mx_gradient_float_1 ] );
|
|
|
+
|
|
|
+const mx_gradient_vec3_0 = tslFn( ( [ hash_immutable, x_immutable, y_immutable ] ) => {
|
|
|
+
|
|
|
+ const y = float( y_immutable ).toVar();
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+ const hash = uvec3( hash_immutable ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_gradient_float( hash.x, x, y ), mx_gradient_float( hash.y, x, y ), mx_gradient_float( hash.z, x, y ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_vec3_1 = tslFn( ( [ hash_immutable, x_immutable, y_immutable, z_immutable ] ) => {
|
|
|
+
|
|
|
+ const z = float( z_immutable ).toVar();
|
|
|
+ const y = float( y_immutable ).toVar();
|
|
|
+ const x = float( x_immutable ).toVar();
|
|
|
+ const hash = uvec3( hash_immutable ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_gradient_float( hash.x, x, y, z ), mx_gradient_float( hash.y, x, y, z ), mx_gradient_float( hash.z, x, y, z ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_vec3 = overloadingFn( [ mx_gradient_vec3_0, mx_gradient_vec3_1 ] );
|
|
|
+
|
|
|
+const mx_gradient_scale2d_0 = tslFn( ( [ v_immutable ] ) => {
|
|
|
+
|
|
|
+ const v = float( v_immutable ).toVar();
|
|
|
+
|
|
|
+ return mul( 0.6616, v );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_scale3d_0 = tslFn( ( [ v_immutable ] ) => {
|
|
|
+
|
|
|
+ const v = float( v_immutable ).toVar();
|
|
|
+
|
|
|
+ return mul( 0.9820, v );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_scale2d_1 = tslFn( ( [ v_immutable ] ) => {
|
|
|
+
|
|
|
+ const v = vec3( v_immutable ).toVar();
|
|
|
+
|
|
|
+ return mul( 0.6616, v );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_scale2d = overloadingFn( [ mx_gradient_scale2d_0, mx_gradient_scale2d_1 ] );
|
|
|
+
|
|
|
+const mx_gradient_scale3d_1 = tslFn( ( [ v_immutable ] ) => {
|
|
|
+
|
|
|
+ const v = vec3( v_immutable ).toVar();
|
|
|
+
|
|
|
+ return mul( 0.9820, v );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_gradient_scale3d = overloadingFn( [ mx_gradient_scale3d_0, mx_gradient_scale3d_1 ] );
|
|
|
+
|
|
|
+const mx_rotl32 = tslFn( ( [ x_immutable, k_immutable ] ) => {
|
|
|
+
|
|
|
+ const k = int( k_immutable ).toVar();
|
|
|
+ const x = uint( x_immutable ).toVar();
|
|
|
+
|
|
|
+ return x.shiftLeft( k ).bitOr( x.shiftRight( int( 32 ).sub( k ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bjmix = tslFn( ( [ a, b, c ] ) => {
|
|
|
+
|
|
|
+ a.subAssign( c );
|
|
|
+ a.bitXorAssign( mx_rotl32( c, int( 4 ) ) );
|
|
|
+ c.addAssign( b );
|
|
|
+ b.subAssign( a );
|
|
|
+ b.bitXorAssign( mx_rotl32( a, int( 6 ) ) );
|
|
|
+ a.addAssign( c );
|
|
|
+ c.subAssign( b );
|
|
|
+ c.bitXorAssign( mx_rotl32( b, int( 8 ) ) );
|
|
|
+ b.addAssign( a );
|
|
|
+ a.subAssign( c );
|
|
|
+ a.bitXorAssign( mx_rotl32( c, int( 16 ) ) );
|
|
|
+ c.addAssign( b );
|
|
|
+ b.subAssign( a );
|
|
|
+ b.bitXorAssign( mx_rotl32( a, int( 19 ) ) );
|
|
|
+ a.addAssign( c );
|
|
|
+ c.subAssign( b );
|
|
|
+ c.bitXorAssign( mx_rotl32( b, int( 4 ) ) );
|
|
|
+ b.addAssign( a );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bjfinal = tslFn( ( [ a_immutable, b_immutable, c_immutable ] ) => {
|
|
|
+
|
|
|
+ const c = uint( c_immutable ).toVar();
|
|
|
+ const b = uint( b_immutable ).toVar();
|
|
|
+ const a = uint( a_immutable ).toVar();
|
|
|
+ c.bitXorAssign( b );
|
|
|
+ c.subAssign( mx_rotl32( b, int( 14 ) ) );
|
|
|
+ a.bitXorAssign( c );
|
|
|
+ a.subAssign( mx_rotl32( c, int( 11 ) ) );
|
|
|
+ b.bitXorAssign( a );
|
|
|
+ b.subAssign( mx_rotl32( a, int( 25 ) ) );
|
|
|
+ c.bitXorAssign( b );
|
|
|
+ c.subAssign( mx_rotl32( b, int( 16 ) ) );
|
|
|
+ a.bitXorAssign( c );
|
|
|
+ a.subAssign( mx_rotl32( c, int( 4 ) ) );
|
|
|
+ b.bitXorAssign( a );
|
|
|
+ b.subAssign( mx_rotl32( a, int( 14 ) ) );
|
|
|
+ c.bitXorAssign( b );
|
|
|
+ c.subAssign( mx_rotl32( b, int( 24 ) ) );
|
|
|
+
|
|
|
+ return c;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_bits_to_01 = tslFn( ( [ bits_immutable ] ) => {
|
|
|
+
|
|
|
+ const bits = uint( bits_immutable ).toVar();
|
|
|
+
|
|
|
+ return float( bits ).div( float( uint( int( 0xffffffff ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_fade = tslFn( ( [ t_immutable ] ) => {
|
|
|
+
|
|
|
+ const t = float( t_immutable ).toVar();
|
|
|
+
|
|
|
+ return t.mul( t.mul( t.mul( t.mul( t.mul( 6.0 ).sub( 15.0 ) ).add( 10.0 ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int_0 = tslFn( ( [ x_immutable ] ) => {
|
|
|
+
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const len = uint( uint( 1 ) ).toVar();
|
|
|
+ const seed = uint( uint( int( 0xdeadbeef ) ).add( len.shiftLeft( uint( 2 ) ).add( uint( 13 ) ) ) ).toVar();
|
|
|
+
|
|
|
+ return mx_bjfinal( seed.add( uint( x ) ), seed, seed );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int_1 = tslFn( ( [ x_immutable, y_immutable ] ) => {
|
|
|
+
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const len = uint( uint( 2 ) ).toVar();
|
|
|
+ const a = uint().toVar(), b = uint().toVar(), c = uint().toVar();
|
|
|
+ a.assign( b.assign( c.assign( uint( int( 0xdeadbeef ) ).add( len.shiftLeft( uint( 2 ) ).add( uint( 13 ) ) ) ) ) );
|
|
|
+ a.addAssign( uint( x ) );
|
|
|
+ b.addAssign( uint( y ) );
|
|
|
+
|
|
|
+ return mx_bjfinal( a, b, c );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int_2 = tslFn( ( [ x_immutable, y_immutable, z_immutable ] ) => {
|
|
|
+
|
|
|
+ const z = int( z_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const len = uint( uint( 3 ) ).toVar();
|
|
|
+ const a = uint().toVar(), b = uint().toVar(), c = uint().toVar();
|
|
|
+ a.assign( b.assign( c.assign( uint( int( 0xdeadbeef ) ).add( len.shiftLeft( uint( 2 ) ).add( uint( 13 ) ) ) ) ) );
|
|
|
+ a.addAssign( uint( x ) );
|
|
|
+ b.addAssign( uint( y ) );
|
|
|
+ c.addAssign( uint( z ) );
|
|
|
+
|
|
|
+ return mx_bjfinal( a, b, c );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int_3 = tslFn( ( [ x_immutable, y_immutable, z_immutable, xx_immutable ] ) => {
|
|
|
+
|
|
|
+ const xx = int( xx_immutable ).toVar();
|
|
|
+ const z = int( z_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const len = uint( uint( 4 ) ).toVar();
|
|
|
+ const a = uint().toVar(), b = uint().toVar(), c = uint().toVar();
|
|
|
+ a.assign( b.assign( c.assign( uint( int( 0xdeadbeef ) ).add( len.shiftLeft( uint( 2 ) ).add( uint( 13 ) ) ) ) ) );
|
|
|
+ a.addAssign( uint( x ) );
|
|
|
+ b.addAssign( uint( y ) );
|
|
|
+ c.addAssign( uint( z ) );
|
|
|
+ mx_bjmix( a, b, c );
|
|
|
+ a.addAssign( uint( xx ) );
|
|
|
+
|
|
|
+ return mx_bjfinal( a, b, c );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int_4 = tslFn( ( [ x_immutable, y_immutable, z_immutable, xx_immutable, yy_immutable ] ) => {
|
|
|
+
|
|
|
+ const yy = int( yy_immutable ).toVar();
|
|
|
+ const xx = int( xx_immutable ).toVar();
|
|
|
+ const z = int( z_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const len = uint( uint( 5 ) ).toVar();
|
|
|
+ const a = uint().toVar(), b = uint().toVar(), c = uint().toVar();
|
|
|
+ a.assign( b.assign( c.assign( uint( int( 0xdeadbeef ) ).add( len.shiftLeft( uint( 2 ) ).add( uint( 13 ) ) ) ) ) );
|
|
|
+ a.addAssign( uint( x ) );
|
|
|
+ b.addAssign( uint( y ) );
|
|
|
+ c.addAssign( uint( z ) );
|
|
|
+ mx_bjmix( a, b, c );
|
|
|
+ a.addAssign( uint( xx ) );
|
|
|
+ b.addAssign( uint( yy ) );
|
|
|
+
|
|
|
+ return mx_bjfinal( a, b, c );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_int = overloadingFn( [ mx_hash_int_0, mx_hash_int_1, mx_hash_int_2, mx_hash_int_3, mx_hash_int_4 ] );
|
|
|
+
|
|
|
+const mx_hash_vec3_0 = tslFn( ( [ x_immutable, y_immutable ] ) => {
|
|
|
+
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const h = uint( mx_hash_int( x, y ) ).toVar();
|
|
|
+ const result = uvec3().toVar();
|
|
|
+ result.x.assign( h.bitAnd( int( 0xFF ) ) );
|
|
|
+ result.y.assign( h.shiftRight( int( 8 ) ).bitAnd( int( 0xFF ) ) );
|
|
|
+ result.z.assign( h.shiftRight( int( 16 ) ).bitAnd( int( 0xFF ) ) );
|
|
|
+
|
|
|
+ return result;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_vec3_1 = tslFn( ( [ x_immutable, y_immutable, z_immutable ] ) => {
|
|
|
+
|
|
|
+ const z = int( z_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const h = uint( mx_hash_int( x, y, z ) ).toVar();
|
|
|
+ const result = uvec3().toVar();
|
|
|
+ result.x.assign( h.bitAnd( int( 0xFF ) ) );
|
|
|
+ result.y.assign( h.shiftRight( int( 8 ) ).bitAnd( int( 0xFF ) ) );
|
|
|
+ result.z.assign( h.shiftRight( int( 16 ) ).bitAnd( int( 0xFF ) ) );
|
|
|
+
|
|
|
+ return result;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_hash_vec3 = overloadingFn( [ mx_hash_vec3_0, mx_hash_vec3_1 ] );
|
|
|
+
|
|
|
+const mx_perlin_noise_float_0 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar();
|
|
|
+ const fx = float( mx_floorfrac( p.x, X ) ).toVar();
|
|
|
+ const fy = float( mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const u = float( mx_fade( fx ) ).toVar();
|
|
|
+ const v = float( mx_fade( fy ) ).toVar();
|
|
|
+ const result = float( mx_bilerp( mx_gradient_float( mx_hash_int( X, Y ), fx, fy ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y ), fx.sub( 1.0 ), fy ), mx_gradient_float( mx_hash_int( X, Y.add( int( 1 ) ) ), fx, fy.sub( 1.0 ) ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y.add( int( 1 ) ) ), fx.sub( 1.0 ), fy.sub( 1.0 ) ), u, v ) ).toVar();
|
|
|
+
|
|
|
+ return mx_gradient_scale2d( result );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_perlin_noise_float_1 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar(), Z = int().toVar();
|
|
|
+ const fx = float( mx_floorfrac( p.x, X ) ).toVar();
|
|
|
+ const fy = float( mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const fz = float( mx_floorfrac( p.z, Z ) ).toVar();
|
|
|
+ const u = float( mx_fade( fx ) ).toVar();
|
|
|
+ const v = float( mx_fade( fy ) ).toVar();
|
|
|
+ const w = float( mx_fade( fz ) ).toVar();
|
|
|
+ const result = float( mx_trilerp( mx_gradient_float( mx_hash_int( X, Y, Z ), fx, fy, fz ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y, Z ), fx.sub( 1.0 ), fy, fz ), mx_gradient_float( mx_hash_int( X, Y.add( int( 1 ) ), Z ), fx, fy.sub( 1.0 ), fz ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y.add( int( 1 ) ), Z ), fx.sub( 1.0 ), fy.sub( 1.0 ), fz ), mx_gradient_float( mx_hash_int( X, Y, Z.add( int( 1 ) ) ), fx, fy, fz.sub( 1.0 ) ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y, Z.add( int( 1 ) ) ), fx.sub( 1.0 ), fy, fz.sub( 1.0 ) ), mx_gradient_float( mx_hash_int( X, Y.add( int( 1 ) ), Z.add( int( 1 ) ) ), fx, fy.sub( 1.0 ), fz.sub( 1.0 ) ), mx_gradient_float( mx_hash_int( X.add( int( 1 ) ), Y.add( int( 1 ) ), Z.add( int( 1 ) ) ), fx.sub( 1.0 ), fy.sub( 1.0 ), fz.sub( 1.0 ) ), u, v, w ) ).toVar();
|
|
|
+
|
|
|
+ return mx_gradient_scale3d( result );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_perlin_noise_float = overloadingFn( [ mx_perlin_noise_float_0, mx_perlin_noise_float_1 ] );
|
|
|
+
|
|
|
+const mx_perlin_noise_vec3_0 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar();
|
|
|
+ const fx = float( mx_floorfrac( p.x, X ) ).toVar();
|
|
|
+ const fy = float( mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const u = float( mx_fade( fx ) ).toVar();
|
|
|
+ const v = float( mx_fade( fy ) ).toVar();
|
|
|
+ const result = vec3( mx_bilerp( mx_gradient_vec3( mx_hash_vec3( X, Y ), fx, fy ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y ), fx.sub( 1.0 ), fy ), mx_gradient_vec3( mx_hash_vec3( X, Y.add( int( 1 ) ) ), fx, fy.sub( 1.0 ) ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y.add( int( 1 ) ) ), fx.sub( 1.0 ), fy.sub( 1.0 ) ), u, v ) ).toVar();
|
|
|
+
|
|
|
+ return mx_gradient_scale2d( result );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_perlin_noise_vec3_1 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar(), Z = int().toVar();
|
|
|
+ const fx = float( mx_floorfrac( p.x, X ) ).toVar();
|
|
|
+ const fy = float( mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const fz = float( mx_floorfrac( p.z, Z ) ).toVar();
|
|
|
+ const u = float( mx_fade( fx ) ).toVar();
|
|
|
+ const v = float( mx_fade( fy ) ).toVar();
|
|
|
+ const w = float( mx_fade( fz ) ).toVar();
|
|
|
+ const result = vec3( mx_trilerp( mx_gradient_vec3( mx_hash_vec3( X, Y, Z ), fx, fy, fz ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y, Z ), fx.sub( 1.0 ), fy, fz ), mx_gradient_vec3( mx_hash_vec3( X, Y.add( int( 1 ) ), Z ), fx, fy.sub( 1.0 ), fz ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y.add( int( 1 ) ), Z ), fx.sub( 1.0 ), fy.sub( 1.0 ), fz ), mx_gradient_vec3( mx_hash_vec3( X, Y, Z.add( int( 1 ) ) ), fx, fy, fz.sub( 1.0 ) ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y, Z.add( int( 1 ) ) ), fx.sub( 1.0 ), fy, fz.sub( 1.0 ) ), mx_gradient_vec3( mx_hash_vec3( X, Y.add( int( 1 ) ), Z.add( int( 1 ) ) ), fx, fy.sub( 1.0 ), fz.sub( 1.0 ) ), mx_gradient_vec3( mx_hash_vec3( X.add( int( 1 ) ), Y.add( int( 1 ) ), Z.add( int( 1 ) ) ), fx.sub( 1.0 ), fy.sub( 1.0 ), fz.sub( 1.0 ) ), u, v, w ) ).toVar();
|
|
|
+
|
|
|
+ return mx_gradient_scale3d( result );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_perlin_noise_vec3 = overloadingFn( [ mx_perlin_noise_vec3_0, mx_perlin_noise_vec3_1 ] );
|
|
|
+
|
|
|
+const mx_cell_noise_float_0 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = float( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p ) ).toVar();
|
|
|
+
|
|
|
+ return mx_bits_to_01( mx_hash_int( ix ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_float_1 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+
|
|
|
+ return mx_bits_to_01( mx_hash_int( ix, iy ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_float_2 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+ const iz = int( mx_floor( p.z ) ).toVar();
|
|
|
+
|
|
|
+ return mx_bits_to_01( mx_hash_int( ix, iy, iz ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_float_3 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec4( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+ const iz = int( mx_floor( p.z ) ).toVar();
|
|
|
+ const iw = int( mx_floor( p.w ) ).toVar();
|
|
|
+
|
|
|
+ return mx_bits_to_01( mx_hash_int( ix, iy, iz, iw ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_float = overloadingFn( [ mx_cell_noise_float_0, mx_cell_noise_float_1, mx_cell_noise_float_2, mx_cell_noise_float_3 ] );
|
|
|
+
|
|
|
+const mx_cell_noise_vec3_0 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = float( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p ) ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_bits_to_01( mx_hash_int( ix, int( 0 ) ) ), mx_bits_to_01( mx_hash_int( ix, int( 1 ) ) ), mx_bits_to_01( mx_hash_int( ix, int( 2 ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_vec3_1 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_bits_to_01( mx_hash_int( ix, iy, int( 0 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, int( 1 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, int( 2 ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_vec3_2 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+ const iz = int( mx_floor( p.z ) ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_bits_to_01( mx_hash_int( ix, iy, iz, int( 0 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, iz, int( 1 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, iz, int( 2 ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_vec3_3 = tslFn( ( [ p_immutable ] ) => {
|
|
|
+
|
|
|
+ const p = vec4( p_immutable ).toVar();
|
|
|
+ const ix = int( mx_floor( p.x ) ).toVar();
|
|
|
+ const iy = int( mx_floor( p.y ) ).toVar();
|
|
|
+ const iz = int( mx_floor( p.z ) ).toVar();
|
|
|
+ const iw = int( mx_floor( p.w ) ).toVar();
|
|
|
+
|
|
|
+ return vec3( mx_bits_to_01( mx_hash_int( ix, iy, iz, iw, int( 0 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, iz, iw, int( 1 ) ) ), mx_bits_to_01( mx_hash_int( ix, iy, iz, iw, int( 2 ) ) ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_cell_noise_vec3 = overloadingFn( [ mx_cell_noise_vec3_0, mx_cell_noise_vec3_1, mx_cell_noise_vec3_2, mx_cell_noise_vec3_3 ] );
|
|
|
+
|
|
|
+const mx_fractal_noise_float = tslFn( ( [ p_immutable, octaves_immutable, lacunarity_immutable, diminish_immutable ] ) => {
|
|
|
+
|
|
|
+ const diminish = float( diminish_immutable ).toVar();
|
|
|
+ const lacunarity = float( lacunarity_immutable ).toVar();
|
|
|
+ const octaves = int( octaves_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const result = float( 0.0 ).toVar();
|
|
|
+ const amplitude = float( 1.0 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: int( 0 ), end: octaves }, ( { i } ) => {
|
|
|
+
|
|
|
+ result.addAssign( amplitude.mul( mx_perlin_noise_float( p ) ) );
|
|
|
+ amplitude.mulAssign( diminish );
|
|
|
+ p.mulAssign( lacunarity );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return result;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_fractal_noise_vec3 = tslFn( ( [ p_immutable, octaves_immutable, lacunarity_immutable, diminish_immutable ] ) => {
|
|
|
+
|
|
|
+ const diminish = float( diminish_immutable ).toVar();
|
|
|
+ const lacunarity = float( lacunarity_immutable ).toVar();
|
|
|
+ const octaves = int( octaves_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const result = vec3( 0.0 ).toVar();
|
|
|
+ const amplitude = float( 1.0 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: int( 0 ), end: octaves }, ( { i } ) => {
|
|
|
+
|
|
|
+ result.addAssign( amplitude.mul( mx_perlin_noise_vec3( p ) ) );
|
|
|
+ amplitude.mulAssign( diminish );
|
|
|
+ p.mulAssign( lacunarity );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return result;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_fractal_noise_vec2 = tslFn( ( [ p_immutable, octaves_immutable, lacunarity_immutable, diminish_immutable ] ) => {
|
|
|
+
|
|
|
+ const diminish = float( diminish_immutable ).toVar();
|
|
|
+ const lacunarity = float( lacunarity_immutable ).toVar();
|
|
|
+ const octaves = int( octaves_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+
|
|
|
+ return vec2( mx_fractal_noise_float( p, octaves, lacunarity, diminish ), mx_fractal_noise_float( p.add( vec3( int( 19 ), int( 193 ), int( 17 ) ) ), octaves, lacunarity, diminish ) );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_fractal_noise_vec4 = tslFn( ( [ p_immutable, octaves_immutable, lacunarity_immutable, diminish_immutable ] ) => {
|
|
|
+
|
|
|
+ const diminish = float( diminish_immutable ).toVar();
|
|
|
+ const lacunarity = float( lacunarity_immutable ).toVar();
|
|
|
+ const octaves = int( octaves_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const c = vec3( mx_fractal_noise_vec3( p, octaves, lacunarity, diminish ) ).toVar();
|
|
|
+ const f = float( mx_fractal_noise_float( p.add( vec3( int( 19 ), int( 193 ), int( 17 ) ) ), octaves, lacunarity, diminish ) ).toVar();
|
|
|
+
|
|
|
+ return vec4( c, f );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_distance_0 = tslFn( ( [ p_immutable, x_immutable, y_immutable, xoff_immutable, yoff_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const yoff = int( yoff_immutable ).toVar();
|
|
|
+ const xoff = int( xoff_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const tmp = vec3( mx_cell_noise_vec3( vec2( x.add( xoff ), y.add( yoff ) ) ) ).toVar();
|
|
|
+ const off = vec2( tmp.x, tmp.y ).toVar();
|
|
|
+ off.subAssign( 0.5 );
|
|
|
+ off.mulAssign( jitter );
|
|
|
+ off.addAssign( 0.5 );
|
|
|
+ const cellpos = vec2( vec2( float( x ), float( y ) ).add( off ) ).toVar();
|
|
|
+ const diff = vec2( cellpos.sub( p ) ).toVar();
|
|
|
+
|
|
|
+ If( metric.equal( int( 2 ) ), () => {
|
|
|
+
|
|
|
+ return abs( diff.x ).add( abs( diff.y ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 3 ) ), () => {
|
|
|
+
|
|
|
+ return max( abs( diff.x ), abs( diff.y ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return dot( diff, diff );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_distance_1 = tslFn( ( [ p_immutable, x_immutable, y_immutable, z_immutable, xoff_immutable, yoff_immutable, zoff_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const zoff = int( zoff_immutable ).toVar();
|
|
|
+ const yoff = int( yoff_immutable ).toVar();
|
|
|
+ const xoff = int( xoff_immutable ).toVar();
|
|
|
+ const z = int( z_immutable ).toVar();
|
|
|
+ const y = int( y_immutable ).toVar();
|
|
|
+ const x = int( x_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const off = vec3( mx_cell_noise_vec3( vec3( x.add( xoff ), y.add( yoff ), z.add( zoff ) ) ) ).toVar();
|
|
|
+ off.subAssign( 0.5 );
|
|
|
+ off.mulAssign( jitter );
|
|
|
+ off.addAssign( 0.5 );
|
|
|
+ const cellpos = vec3( vec3( float( x ), float( y ), float( z ) ).add( off ) ).toVar();
|
|
|
+ const diff = vec3( cellpos.sub( p ) ).toVar();
|
|
|
+
|
|
|
+ If( metric.equal( int( 2 ) ), () => {
|
|
|
+
|
|
|
+ return abs( diff.x ).add( abs( diff.y ).add( abs( diff.z ) ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 3 ) ), () => {
|
|
|
+
|
|
|
+ return max( max( abs( diff.x ), abs( diff.y ) ), abs( diff.z ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return dot( diff, diff );
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_distance = overloadingFn( [ mx_worley_distance_0, mx_worley_distance_1 ] );
|
|
|
+
|
|
|
+const mx_worley_noise_float_0 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar();
|
|
|
+ const localpos = vec2( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const sqdist = float( 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, X, Y, jitter, metric ) ).toVar();
|
|
|
+ sqdist.assign( min( sqdist, dist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_vec2_0 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar();
|
|
|
+ const localpos = vec2( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const sqdist = vec2( 1e6, 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, X, Y, jitter, metric ) ).toVar();
|
|
|
+
|
|
|
+ If( dist.lessThan( sqdist.x ), () => {
|
|
|
+
|
|
|
+ sqdist.y.assign( sqdist.x );
|
|
|
+ sqdist.x.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.y ), () => {
|
|
|
+
|
|
|
+ sqdist.y.assign( dist );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_vec3_0 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec2( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar();
|
|
|
+ const localpos = vec2( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ) ).toVar();
|
|
|
+ const sqdist = vec3( 1e6, 1e6, 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, X, Y, jitter, metric ) ).toVar();
|
|
|
+
|
|
|
+ If( dist.lessThan( sqdist.x ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( sqdist.y );
|
|
|
+ sqdist.y.assign( sqdist.x );
|
|
|
+ sqdist.x.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.y ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( sqdist.y );
|
|
|
+ sqdist.y.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.z ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( dist );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_float_1 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar(), Z = int().toVar();
|
|
|
+ const localpos = vec3( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ), mx_floorfrac( p.z, Z ) ).toVar();
|
|
|
+ const sqdist = float( 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'z', condition: '<=' }, ( { z } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, z, X, Y, Z, jitter, metric ) ).toVar();
|
|
|
+ sqdist.assign( min( sqdist, dist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_float = overloadingFn( [ mx_worley_noise_float_0, mx_worley_noise_float_1 ] );
|
|
|
+
|
|
|
+const mx_worley_noise_vec2_1 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar(), Z = int().toVar();
|
|
|
+ const localpos = vec3( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ), mx_floorfrac( p.z, Z ) ).toVar();
|
|
|
+ const sqdist = vec2( 1e6, 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'z', condition: '<=' }, ( { z } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, z, X, Y, Z, jitter, metric ) ).toVar();
|
|
|
+
|
|
|
+ If( dist.lessThan( sqdist.x ), () => {
|
|
|
+
|
|
|
+ sqdist.y.assign( sqdist.x );
|
|
|
+ sqdist.x.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.y ), () => {
|
|
|
+
|
|
|
+ sqdist.y.assign( dist );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_vec2 = overloadingFn( [ mx_worley_noise_vec2_0, mx_worley_noise_vec2_1 ] );
|
|
|
+
|
|
|
+const mx_worley_noise_vec3_1 = tslFn( ( [ p_immutable, jitter_immutable, metric_immutable ] ) => {
|
|
|
+
|
|
|
+ const metric = int( metric_immutable ).toVar();
|
|
|
+ const jitter = float( jitter_immutable ).toVar();
|
|
|
+ const p = vec3( p_immutable ).toVar();
|
|
|
+ const X = int().toVar(), Y = int().toVar(), Z = int().toVar();
|
|
|
+ const localpos = vec3( mx_floorfrac( p.x, X ), mx_floorfrac( p.y, Y ), mx_floorfrac( p.z, Z ) ).toVar();
|
|
|
+ const sqdist = vec3( 1e6, 1e6, 1e6 ).toVar();
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'x', condition: '<=' }, ( { x } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'y', condition: '<=' }, ( { y } ) => {
|
|
|
+
|
|
|
+ loop( { start: - 1, end: int( 1 ), name: 'z', condition: '<=' }, ( { z } ) => {
|
|
|
+
|
|
|
+ const dist = float( mx_worley_distance( localpos, x, y, z, X, Y, Z, jitter, metric ) ).toVar();
|
|
|
+
|
|
|
+ If( dist.lessThan( sqdist.x ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( sqdist.y );
|
|
|
+ sqdist.y.assign( sqdist.x );
|
|
|
+ sqdist.x.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.y ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( sqdist.y );
|
|
|
+ sqdist.y.assign( dist );
|
|
|
+
|
|
|
+ } ).elseif( dist.lessThan( sqdist.z ), () => {
|
|
|
+
|
|
|
+ sqdist.z.assign( dist );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ If( metric.equal( int( 0 ) ), () => {
|
|
|
+
|
|
|
+ sqdist.assign( sqrt( sqdist ) );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ return sqdist;
|
|
|
+
|
|
|
+} );
|
|
|
+
|
|
|
+const mx_worley_noise_vec3 = overloadingFn( [ mx_worley_noise_vec3_0, mx_worley_noise_vec3_1 ] );
|
|
|
+
|
|
|
+// layouts
|
|
|
+
|
|
|
+mx_select.setLayout( {
|
|
|
+ name: 'mx_select',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'b', type: 'bool' },
|
|
|
+ { name: 't', type: 'float' },
|
|
|
+ { name: 'f', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_negate_if.setLayout( {
|
|
|
+ name: 'mx_negate_if',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'val', type: 'float' },
|
|
|
+ { name: 'b', type: 'bool' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_floor.setLayout( {
|
|
|
+ name: 'mx_floor',
|
|
|
+ type: 'int',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_bilerp_0.setLayout( {
|
|
|
+ name: 'mx_bilerp_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v0', type: 'float' },
|
|
|
+ { name: 'v1', type: 'float' },
|
|
|
+ { name: 'v2', type: 'float' },
|
|
|
+ { name: 'v3', type: 'float' },
|
|
|
+ { name: 's', type: 'float' },
|
|
|
+ { name: 't', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_bilerp_1.setLayout( {
|
|
|
+ name: 'mx_bilerp_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v0', type: 'vec3' },
|
|
|
+ { name: 'v1', type: 'vec3' },
|
|
|
+ { name: 'v2', type: 'vec3' },
|
|
|
+ { name: 'v3', type: 'vec3' },
|
|
|
+ { name: 's', type: 'float' },
|
|
|
+ { name: 't', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_trilerp_0.setLayout( {
|
|
|
+ name: 'mx_trilerp_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v0', type: 'float' },
|
|
|
+ { name: 'v1', type: 'float' },
|
|
|
+ { name: 'v2', type: 'float' },
|
|
|
+ { name: 'v3', type: 'float' },
|
|
|
+ { name: 'v4', type: 'float' },
|
|
|
+ { name: 'v5', type: 'float' },
|
|
|
+ { name: 'v6', type: 'float' },
|
|
|
+ { name: 'v7', type: 'float' },
|
|
|
+ { name: 's', type: 'float' },
|
|
|
+ { name: 't', type: 'float' },
|
|
|
+ { name: 'r', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_trilerp_1.setLayout( {
|
|
|
+ name: 'mx_trilerp_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v0', type: 'vec3' },
|
|
|
+ { name: 'v1', type: 'vec3' },
|
|
|
+ { name: 'v2', type: 'vec3' },
|
|
|
+ { name: 'v3', type: 'vec3' },
|
|
|
+ { name: 'v4', type: 'vec3' },
|
|
|
+ { name: 'v5', type: 'vec3' },
|
|
|
+ { name: 'v6', type: 'vec3' },
|
|
|
+ { name: 'v7', type: 'vec3' },
|
|
|
+ { name: 's', type: 'float' },
|
|
|
+ { name: 't', type: 'float' },
|
|
|
+ { name: 'r', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_float_0.setLayout( {
|
|
|
+ name: 'mx_gradient_float_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'hash', type: 'uint' },
|
|
|
+ { name: 'x', type: 'float' },
|
|
|
+ { name: 'y', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_float_1.setLayout( {
|
|
|
+ name: 'mx_gradient_float_1',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'hash', type: 'uint' },
|
|
|
+ { name: 'x', type: 'float' },
|
|
|
+ { name: 'y', type: 'float' },
|
|
|
+ { name: 'z', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_vec3_0.setLayout( {
|
|
|
+ name: 'mx_gradient_vec3_0',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'hash', type: 'uvec3' },
|
|
|
+ { name: 'x', type: 'float' },
|
|
|
+ { name: 'y', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_vec3_1.setLayout( {
|
|
|
+ name: 'mx_gradient_vec3_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'hash', type: 'uvec3' },
|
|
|
+ { name: 'x', type: 'float' },
|
|
|
+ { name: 'y', type: 'float' },
|
|
|
+ { name: 'z', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_scale2d_0.setLayout( {
|
|
|
+ name: 'mx_gradient_scale2d_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_scale3d_0.setLayout( {
|
|
|
+ name: 'mx_gradient_scale3d_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_scale2d_1.setLayout( {
|
|
|
+ name: 'mx_gradient_scale2d_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_gradient_scale3d_1.setLayout( {
|
|
|
+ name: 'mx_gradient_scale3d_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'v', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_rotl32.setLayout( {
|
|
|
+ name: 'mx_rotl32',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'uint' },
|
|
|
+ { name: 'k', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_bjfinal.setLayout( {
|
|
|
+ name: 'mx_bjfinal',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'a', type: 'uint' },
|
|
|
+ { name: 'b', type: 'uint' },
|
|
|
+ { name: 'c', type: 'uint' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_bits_to_01.setLayout( {
|
|
|
+ name: 'mx_bits_to_01',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'bits', type: 'uint' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_fade.setLayout( {
|
|
|
+ name: 'mx_fade',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 't', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_int_0.setLayout( {
|
|
|
+ name: 'mx_hash_int_0',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_int_1.setLayout( {
|
|
|
+ name: 'mx_hash_int_1',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_int_2.setLayout( {
|
|
|
+ name: 'mx_hash_int_2',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'z', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_int_3.setLayout( {
|
|
|
+ name: 'mx_hash_int_3',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'z', type: 'int' },
|
|
|
+ { name: 'xx', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_int_4.setLayout( {
|
|
|
+ name: 'mx_hash_int_4',
|
|
|
+ type: 'uint',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'z', type: 'int' },
|
|
|
+ { name: 'xx', type: 'int' },
|
|
|
+ { name: 'yy', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_vec3_0.setLayout( {
|
|
|
+ name: 'mx_hash_vec3_0',
|
|
|
+ type: 'uvec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_hash_vec3_1.setLayout( {
|
|
|
+ name: 'mx_hash_vec3_1',
|
|
|
+ type: 'uvec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'z', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_perlin_noise_float_0.setLayout( {
|
|
|
+ name: 'mx_perlin_noise_float_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_perlin_noise_float_1.setLayout( {
|
|
|
+ name: 'mx_perlin_noise_float_1',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_perlin_noise_vec3_0.setLayout( {
|
|
|
+ name: 'mx_perlin_noise_vec3_0',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_perlin_noise_vec3_1.setLayout( {
|
|
|
+ name: 'mx_perlin_noise_vec3_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_float_0.setLayout( {
|
|
|
+ name: 'mx_cell_noise_float_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_float_1.setLayout( {
|
|
|
+ name: 'mx_cell_noise_float_1',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_float_2.setLayout( {
|
|
|
+ name: 'mx_cell_noise_float_2',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_float_3.setLayout( {
|
|
|
+ name: 'mx_cell_noise_float_3',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec4' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_vec3_0.setLayout( {
|
|
|
+ name: 'mx_cell_noise_vec3_0',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_vec3_1.setLayout( {
|
|
|
+ name: 'mx_cell_noise_vec3_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_vec3_2.setLayout( {
|
|
|
+ name: 'mx_cell_noise_vec3_2',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_cell_noise_vec3_3.setLayout( {
|
|
|
+ name: 'mx_cell_noise_vec3_3',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec4' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_fractal_noise_float.setLayout( {
|
|
|
+ name: 'mx_fractal_noise_float',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'octaves', type: 'int' },
|
|
|
+ { name: 'lacunarity', type: 'float' },
|
|
|
+ { name: 'diminish', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_fractal_noise_vec3.setLayout( {
|
|
|
+ name: 'mx_fractal_noise_vec3',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'octaves', type: 'int' },
|
|
|
+ { name: 'lacunarity', type: 'float' },
|
|
|
+ { name: 'diminish', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_fractal_noise_vec2.setLayout( {
|
|
|
+ name: 'mx_fractal_noise_vec2',
|
|
|
+ type: 'vec2',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'octaves', type: 'int' },
|
|
|
+ { name: 'lacunarity', type: 'float' },
|
|
|
+ { name: 'diminish', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_fractal_noise_vec4.setLayout( {
|
|
|
+ name: 'mx_fractal_noise_vec4',
|
|
|
+ type: 'vec4',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'octaves', type: 'int' },
|
|
|
+ { name: 'lacunarity', type: 'float' },
|
|
|
+ { name: 'diminish', type: 'float' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_distance_0.setLayout( {
|
|
|
+ name: 'mx_worley_distance_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' },
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'xoff', type: 'int' },
|
|
|
+ { name: 'yoff', type: 'int' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_distance_1.setLayout( {
|
|
|
+ name: 'mx_worley_distance_1',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'x', type: 'int' },
|
|
|
+ { name: 'y', type: 'int' },
|
|
|
+ { name: 'z', type: 'int' },
|
|
|
+ { name: 'xoff', type: 'int' },
|
|
|
+ { name: 'yoff', type: 'int' },
|
|
|
+ { name: 'zoff', type: 'int' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_float_0.setLayout( {
|
|
|
+ name: 'mx_worley_noise_float_0',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_vec2_0.setLayout( {
|
|
|
+ name: 'mx_worley_noise_vec2_0',
|
|
|
+ type: 'vec2',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_vec3_0.setLayout( {
|
|
|
+ name: 'mx_worley_noise_vec3_0',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec2' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_float_1.setLayout( {
|
|
|
+ name: 'mx_worley_noise_float_1',
|
|
|
+ type: 'float',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_vec2_1.setLayout( {
|
|
|
+ name: 'mx_worley_noise_vec2_1',
|
|
|
+ type: 'vec2',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+mx_worley_noise_vec3_1.setLayout( {
|
|
|
+ name: 'mx_worley_noise_vec3_1',
|
|
|
+ type: 'vec3',
|
|
|
+ inputs: [
|
|
|
+ { name: 'p', type: 'vec3' },
|
|
|
+ { name: 'jitter', type: 'float' },
|
|
|
+ { name: 'metric', type: 'int' }
|
|
|
+ ]
|
|
|
+} );
|
|
|
+
|
|
|
+export { mx_select, mx_negate_if, mx_floor, mx_floorfrac, mx_bilerp, mx_trilerp, mx_gradient_float, mx_gradient_vec3, mx_gradient_scale2d, mx_gradient_scale3d, mx_rotl32, mx_bjmix, mx_bjfinal, mx_bits_to_01, mx_fade, mx_hash_int, mx_hash_vec3, mx_perlin_noise_float, mx_perlin_noise_vec3, mx_cell_noise_float, mx_cell_noise_vec3, mx_fractal_noise_float, mx_fractal_noise_vec3, mx_fractal_noise_vec2, mx_fractal_noise_vec4, mx_worley_distance, mx_worley_noise_float, mx_worley_noise_vec2, mx_worley_noise_vec3 };
|
sunag
