@@ -0,0 +1,218 @@
|
|
|
+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js webgpu - postprocessing - dof</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
+ <link type="text/css" rel="stylesheet" href="main.css">
|
|
|
+ </head>
|
|
|
+ <body>
|
|
|
+ <script type="importmap">
|
|
|
+ {
|
|
|
+ "imports": {
|
|
|
+ "three": "../build/three.module.js",
|
|
|
+ "three/addons/": "./jsm/",
|
|
|
+ "three/nodes": "./jsm/nodes/Nodes.js"
|
|
|
+ }
|
|
|
+ }
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script type="module">
|
|
|
+
|
|
|
+ import * as THREE from 'three';
|
|
|
+
|
|
|
+ import WebGPURenderer from 'three/addons/renderers/webgpu/WebGPURenderer.js';
|
|
|
+ import PostProcessing from 'three/addons/renderers/common/PostProcessing.js';
|
|
|
+ import { MeshBasicNodeMaterial, cubeTexture } from 'three/nodes';
|
|
|
+ import { pass } from 'three/nodes';
|
|
|
+
|
|
|
+ import { GUI } from 'three/addons/libs/lil-gui.module.min.js';
|
|
|
+ import Stats from 'three/addons/libs/stats.module.js';
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ let camera, scene, renderer, mesh, stats;
|
|
|
+
|
|
|
+ let mouseX = 0, mouseY = 0;
|
|
|
+
|
|
|
+ let windowHalfX = window.innerWidth / 2;
|
|
|
+ let windowHalfY = window.innerHeight / 2;
|
|
|
+
|
|
|
+ let width = window.innerWidth;
|
|
|
+ let height = window.innerHeight;
|
|
|
+
|
|
|
+ let postProcessing;
|
|
|
+
|
|
|
+ const color = new THREE.Color();
|
|
|
+
|
|
|
+ init();
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ camera = new THREE.PerspectiveCamera( 70, width / height, 1, 3000 );
|
|
|
+ camera.position.z = 200;
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+
|
|
|
+ const path = 'textures/cube/SwedishRoyalCastle/';
|
|
|
+ const format = '.jpg';
|
|
|
+ const urls = [
|
|
|
+ path + 'px' + format, path + 'nx' + format,
|
|
|
+ path + 'py' + format, path + 'ny' + format,
|
|
|
+ path + 'pz' + format, path + 'nz' + format
|
|
|
+ ];
|
|
|
+
|
|
|
+ const textureCube = new THREE.CubeTextureLoader().load( urls );
|
|
|
+ const cubeTextureNode = cubeTexture( textureCube );
|
|
|
+
|
|
|
+ const geometry = new THREE.SphereGeometry( 60, 20, 10 );
|
|
|
+ const material = new MeshBasicNodeMaterial();
|
|
|
+ material.colorNode = cubeTextureNode;
|
|
|
+
|
|
|
+ const xgrid = 14, ygrid = 9, zgrid = 14;
|
|
|
+ const count = xgrid * ygrid * zgrid;
|
|
|
+
|
|
|
+ mesh = new THREE.InstancedMesh( geometry, material, count );
|
|
|
+ scene.add( mesh );
|
|
|
+
|
|
|
+ const matrix = new THREE.Matrix4();
|
|
|
+
|
|
|
+ let index = 0;
|
|
|
+
|
|
|
+ for ( let i = 0; i < xgrid; i ++ ) {
|
|
|
+
|
|
|
+ for ( let j = 0; j < ygrid; j ++ ) {
|
|
|
+
|
|
|
+ for ( let k = 0; k < zgrid; k ++ ) {
|
|
|
+
|
|
|
+ const x = 200 * ( i - xgrid / 2 );
|
|
|
+ const y = 200 * ( j - ygrid / 2 );
|
|
|
+ const z = 200 * ( k - zgrid / 2 );
|
|
|
+
|
|
|
+ mesh.setMatrixAt( index, matrix.identity().setPosition( x, y, z ) );
|
|
|
+ mesh.setColorAt( index, color );
|
|
|
+ index ++;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ // renderer
|
|
|
+
|
|
|
+ renderer = new WebGPURenderer( { antialias: true } );
|
|
|
+ renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ renderer.setAnimationLoop( animate );
|
|
|
+ document.body.appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ // post processing
|
|
|
+
|
|
|
+ postProcessing = new PostProcessing( renderer );
|
|
|
+
|
|
|
+ const scenePass = pass( scene, camera );
|
|
|
+
|
|
|
+ const scenePassColor = scenePass.getTextureNode();
|
|
|
+ const scenePassViewZ = scenePass.getViewZNode();
|
|
|
+
|
|
|
+ const dofPass = scenePassColor.dof( scenePassViewZ );
|
|
|
+
|
|
|
+ postProcessing.outputNode = dofPass;
|
|
|
+
|
|
|
+ // controls
|
|
|
+
|
|
|
+ renderer.domElement.style.touchAction = 'none';
|
|
|
+ renderer.domElement.addEventListener( 'pointermove', onPointerMove );
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', onWindowResize );
|
|
|
+
|
|
|
+ // stats
|
|
|
+
|
|
|
+ stats = new Stats();
|
|
|
+ document.body.appendChild( stats.dom );
|
|
|
+
|
|
|
+ // gui
|
|
|
+
|
|
|
+ const effectController = {
|
|
|
+
|
|
|
+ focus: 500.0,
|
|
|
+ aperture: 5,
|
|
|
+ maxblur: 0.01
|
|
|
+
|
|
|
+ };
|
|
|
+
|
|
|
+ function updateEffect( ) {
|
|
|
+
|
|
|
+ dofPass.focus.value = effectController.focus;
|
|
|
+ dofPass.aperture.value = effectController.aperture * 0.00001;
|
|
|
+ dofPass.maxblur.value = effectController.maxblur;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ const gui = new GUI();
|
|
|
+ gui.add( effectController, 'focus', 10.0, 3000.0, 10 ).onChange( updateEffect );
|
|
|
+ gui.add( effectController, 'aperture', 0, 10, 0.1 ).onChange( updateEffect );
|
|
|
+ gui.add( effectController, 'maxblur', 0.0, 0.01, 0.001 ).onChange( updateEffect );
|
|
|
+
|
|
|
+ updateEffect();
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onPointerMove( event ) {
|
|
|
+
|
|
|
+ if ( event.isPrimary === false ) return;
|
|
|
+
|
|
|
+ mouseX = event.clientX - windowHalfX;
|
|
|
+ mouseY = event.clientY - windowHalfY;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onWindowResize() {
|
|
|
+
|
|
|
+ windowHalfX = window.innerWidth / 2;
|
|
|
+ windowHalfY = window.innerHeight / 2;
|
|
|
+
|
|
|
+ width = window.innerWidth;
|
|
|
+ height = window.innerHeight;
|
|
|
+
|
|
|
+ camera.aspect = width / height;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ renderer.setSize( width, height );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function animate() {
|
|
|
+
|
|
|
+ render();
|
|
|
+ stats.update();
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function render() {
|
|
|
+
|
|
|
+ const time = Date.now() * 0.00005;
|
|
|
+
|
|
|
+ camera.position.x += ( mouseX - camera.position.x ) * 0.036;
|
|
|
+ camera.position.y += ( - ( mouseY ) - camera.position.y ) * 0.036;
|
|
|
+
|
|
|
+ camera.lookAt( scene.position );
|
|
|
+
|
|
|
+ for ( let i = 0; i < mesh.count; i ++ ) {
|
|
|
+
|
|
|
+ const h = ( 360 * ( i / mesh.count + time ) % 360 ) / 360;
|
|
|
+ color.setHSL( h, 1, 0.5 );
|
|
|
+ mesh.setColorAt( i, color );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ mesh.instanceColor.needsUpdate = true;
|
|
|
+
|
|
|
+ postProcessing.render();
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+ </body>
|
|
|
+</html>
|
