+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js - WebGPU - Backdrop Water</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
+ <link type="text/css" rel="stylesheet" href="main.css">
|
|
|
+ </head>
|
|
|
+ <body>
|
|
|
+
|
|
|
+ <div id="info">
|
|
|
+ <a href="https://threejs.org" target="_blank" rel="noopener">three.js</a> WebGPU - Backdrop Water
|
|
|
+ </div>
|
|
|
+
|
|
|
+ <script type="importmap">
|
|
|
+ {
|
|
|
+ "imports": {
|
|
|
+ "three": "../build/three.module.js",
|
|
|
+ "three/addons/": "./jsm/",
|
|
|
+ "three/nodes": "./jsm/nodes/Nodes.js"
|
|
|
+ }
|
|
|
+ }
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script type="module">
|
|
|
+
|
|
|
+ import * as THREE from 'three';
|
|
|
+ import { color, depth, depthTexture, normalWorld, triplanarTexture, texture, viewportSharedTexture, mx_worley_noise_float, positionWorld, timerLocal, MeshStandardNodeMaterial, MeshBasicNodeMaterial } from 'three/nodes';
|
|
|
+
|
|
|
+ import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js';
|
|
|
+
|
|
|
+ import WebGPU from 'three/addons/capabilities/WebGPU.js';
|
|
|
+ import WebGL from 'three/addons/capabilities/WebGL.js';
|
|
|
+
|
|
|
+ import WebGPURenderer from 'three/addons/renderers/webgpu/WebGPURenderer.js';
|
|
|
+
|
|
|
+ import { OrbitControls } from 'three/addons/controls/OrbitControls.js';
|
|
|
+
|
|
|
+ import { GUI } from 'three/addons/libs/lil-gui.module.min.js';
|
|
|
+
|
|
|
+ let camera, scene, renderer;
|
|
|
+ let mixer, objects, clock;
|
|
|
+ let model, floor, floorPosition;
|
|
|
+
|
|
|
+ init();
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ if ( WebGPU.isAvailable() === false && WebGL.isWebGL2Available() === false ) {
|
|
|
+
|
|
|
+ document.body.appendChild( WebGPU.getErrorMessage() );
|
|
|
+
|
|
|
+ throw new Error( 'No WebGPU or WebGL2 support' );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ camera = new THREE.PerspectiveCamera( 50, window.innerWidth / window.innerHeight, 0.25, 30 );
|
|
|
+ camera.position.set( 3, 3, 4 );
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+ scene.fog = new THREE.Fog( 0x74ccf4, 7, 25 );
|
|
|
+ scene.backgroundNode = normalWorld.y.mix( color( 0x74ccf4 ), color( 0x0066ff ) );
|
|
|
+ camera.lookAt( 0, 1, 0 );
|
|
|
+
|
|
|
+ const sunLight = new THREE.DirectionalLight( 0xFFE499, 5 );
|
|
|
+ sunLight.castShadow = true;
|
|
|
+ sunLight.shadow.camera.near = .1;
|
|
|
+ sunLight.shadow.camera.far = 3;
|
|
|
+ sunLight.shadow.camera.right = 2;
|
|
|
+ sunLight.shadow.camera.left = - 2;
|
|
|
+ sunLight.shadow.camera.top = 2;
|
|
|
+ sunLight.shadow.camera.bottom = - 2;
|
|
|
+ sunLight.shadow.mapSize.width = 2048;
|
|
|
+ sunLight.shadow.mapSize.height = 2048;
|
|
|
+ sunLight.shadow.bias = - 0.001;
|
|
|
+ sunLight.position.set( 1, 3, 1 );
|
|
|
+
|
|
|
+ const waterAmbientLight = new THREE.HemisphereLight( 0x333366, 0x74ccf4, 5 );
|
|
|
+ const skyAmbientLight = new THREE.HemisphereLight( 0x74ccf4, 0, 1 );
|
|
|
+
|
|
|
+ scene.add( sunLight );
|
|
|
+ scene.add( skyAmbientLight );
|
|
|
+ scene.add( waterAmbientLight );
|
|
|
+
|
|
|
+ clock = new THREE.Clock();
|
|
|
+
|
|
|
+ // animated model
|
|
|
+
|
|
|
+ const loader = new GLTFLoader();
|
|
|
+ loader.load( 'models/gltf/Michelle.glb', function ( gltf ) {
|
|
|
+
|
|
|
+ model = gltf.scene;
|
|
|
+ model.children[ 0 ].children[ 0 ].castShadow = true;
|
|
|
+
|
|
|
+ mixer = new THREE.AnimationMixer( model );
|
|
|
+
|
|
|
+ const action = mixer.clipAction( gltf.animations[ 0 ] );
|
|
|
+ action.play();
|
|
|
+
|
|
|
+ scene.add( model );
|
|
|
+
|
|
|
+ } );
|
|
|
+
|
|
|
+ // objects
|
|
|
+
|
|
|
+ const textureLoader = new THREE.TextureLoader();
|
|
|
+ const brick_diffuse = textureLoader.load( './textures/brick_diffuse.jpg' );
|
|
|
+ brick_diffuse.wrapS = THREE.RepeatWrapping;
|
|
|
+ brick_diffuse.wrapT = THREE.RepeatWrapping;
|
|
|
+ brick_diffuse.colorSpace = THREE.NoColorSpace;
|
|
|
+
|
|
|
+ const brick = triplanarTexture( texture( brick_diffuse ) );
|
|
|
+
|
|
|
+ const geometry = new THREE.TorusKnotGeometry( .6, 0.3, 128, 64 );
|
|
|
+ const material = new MeshStandardNodeMaterial();
|
|
|
+ material.colorNode = brick;
|
|
|
+
|
|
|
+ const count = 100;
|
|
|
+ const scale = 3.5;
|
|
|
+ const column = 10;
|
|
|
+
|
|
|
+ objects = new THREE.Group();
|
|
|
+
|
|
|
+ for ( let i = 0; i < count; i ++ ) {
|
|
|
+
|
|
|
+ const x = i % column;
|
|
|
+ const y = i / column;
|
|
|
+
|
|
|
+ const mesh = new THREE.Mesh( geometry, material );
|
|
|
+ mesh.position.set( x * scale, 0, y * scale );
|
|
|
+ mesh.rotation.set( Math.random(), Math.random(), Math.random() );
|
|
|
+ objects.add( mesh );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ objects.position.set(
|
|
|
+ ( ( column - 1 ) * scale ) * - .5,
|
|
|
+ - .3,
|
|
|
+ ( ( count / column ) * scale ) * - .5
|
|
|
+ );
|
|
|
+
|
|
|
+ scene.add( objects );
|
|
|
+
|
|
|
+ // water
|
|
|
+
|
|
|
+ const depthEffect = depthTexture().distance( depth ).remapClamp( 0, .05 );
|
|
|
+
|
|
|
+ const timer = timerLocal( .8 );
|
|
|
+ const floorUV = positionWorld.xzy;
|
|
|
+
|
|
|
+ const waterLayer0 = mx_worley_noise_float( floorUV.mul( 4 ).add( timer ) );
|
|
|
+ const waterLayer1 = mx_worley_noise_float( floorUV.mul( 2 ).add( timer ) );
|
|
|
+ const waterLayer2 = mx_worley_noise_float( floorUV.mul( 3 ).add( timer ) );
|
|
|
+
|
|
|
+ const waterIntensity = waterLayer0.mul( waterLayer1 ).mul( waterLayer2 ).mul( 5 );
|
|
|
+ const waterColor = waterIntensity.mix( color( 0x0f5e9c ), color( 0x74ccf4 ) );
|
|
|
+ const viewportTexture = viewportSharedTexture();
|
|
|
+
|
|
|
+ const waterMaterial = new MeshBasicNodeMaterial();
|
|
|
+ waterMaterial.colorNode = waterColor;
|
|
|
+ waterMaterial.backdropNode = depthEffect.mul( 3 ).min( 1.4 ).mix( viewportTexture, viewportTexture.mul( color( 0x74ccf4 ) ) );
|
|
|
+ waterMaterial.backdropAlphaNode = depthEffect.oneMinus();
|
|
|
+ waterMaterial.transparent = true;
|
|
|
+
|
|
|
+ const water = new THREE.Mesh( new THREE.BoxGeometry( 100, .001, 100 ), waterMaterial );
|
|
|
+ water.position.set( 0, .8, 0 );
|
|
|
+ scene.add( water );
|
|
|
+
|
|
|
+ // floor
|
|
|
+
|
|
|
+ floor = new THREE.Mesh( new THREE.BoxGeometry( 1.7, 10, 1.7 ), new MeshStandardNodeMaterial( { colorNode: brick } ) );
|
|
|
+ floor.position.set( 0, - 5, 0 );
|
|
|
+ scene.add( floor );
|
|
|
+
|
|
|
+ // caustics
|
|
|
+
|
|
|
+ const waterPosY = positionWorld.y.sub( water.position.y );
|
|
|
+
|
|
|
+ let transition = waterPosY.add( .1 ).saturate().oneMinus();
|
|
|
+ transition = waterPosY.lessThan( 0 ).cond( transition, normalWorld.y.mix( transition, 0 ) ).toVar();
|
|
|
+
|
|
|
+ material.colorNode = transition.mix( material.colorNode, material.colorNode.add( waterLayer0 ) );
|
|
|
+ floor.material.colorNode = material.colorNode;
|
|
|
+
|
|
|
+ // renderer
|
|
|
+
|
|
|
+ renderer = new WebGPURenderer( /*{ antialias: true }*/ );
|
|
|
+ renderer.stencil = false;
|
|
|
+ renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ renderer.setAnimationLoop( animate );
|
|
|
+ document.body.appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ const controls = new OrbitControls( camera, renderer.domElement );
|
|
|
+ controls.minDistance = 1;
|
|
|
+ controls.maxDistance = 10;
|
|
|
+ controls.maxPolarAngle = Math.PI * 0.9;
|
|
|
+ controls.target.set( 0, 1, 0 );
|
|
|
+ controls.update();
|
|
|
+
|
|
|
+ // gui
|
|
|
+
|
|
|
+ const gui = new GUI();
|
|
|
+
|
|
|
+ floorPosition = new THREE.Vector3( 0, 1, 0 );
|
|
|
+
|
|
|
+ gui.add( floorPosition, 'y', 0, 2, .001 ).name( 'position' );
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', onWindowResize );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onWindowResize() {
|
|
|
+
|
|
|
+ camera.aspect = window.innerWidth / window.innerHeight;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function animate() {
|
|
|
+
|
|
|
+ const delta = clock.getDelta();
|
|
|
+
|
|
|
+ floor.position.y = floorPosition.y - 5;
|
|
|
+
|
|
|
+ if ( model ) {
|
|
|
+
|
|
|
+ mixer.update( delta );
|
|
|
+
|
|
|
+ model.position.y = floorPosition.y;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ for ( const object of objects.children ) {
|
|
|
+
|
|
|
+ object.position.y = Math.sin( clock.elapsedTime + object.id ) * .3;
|
|
|
+ object.rotation.y += delta * .3;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ renderer.render( scene, camera );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+ </body>
|
|
|
+</html>
|
