@@ -1,341 +0,0 @@
|
|
|
-<!DOCTYPE html>
|
|
|
-<html lang="en">
|
|
|
- <head>
|
|
|
- <title>three.js - platformer demo</title>
|
|
|
- <meta charset="utf-8">
|
|
|
- <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
- <link type="text/css" rel="stylesheet" href="main.css">
|
|
|
- </head>
|
|
|
- <body>
|
|
|
-
|
|
|
- <div id="info"><a href="http://threejs.org" target="_blank" rel="noopener">three.js</a> - platformer demo. cubemap by <a href="http://www.zfight.com/" target="_blank" rel="noopener">Jochum Skoglund</a>.<br />Use arrow keys to look around, WASD to move and SPACE to jump.</div>
|
|
|
-
|
|
|
- <script type="module">
|
|
|
-
|
|
|
- import * as THREE from '../build/three.module.js';
|
|
|
-
|
|
|
- // player motion parameters
|
|
|
-
|
|
|
- var motion = {
|
|
|
- airborne: false,
|
|
|
- position: new THREE.Vector3(), velocity: new THREE.Vector3(),
|
|
|
- rotation: new THREE.Vector2(), spinning: new THREE.Vector2()
|
|
|
- };
|
|
|
-
|
|
|
- motion.position.y = - 150;
|
|
|
-
|
|
|
-
|
|
|
- // game systems code
|
|
|
-
|
|
|
- var resetPlayer = function () {
|
|
|
-
|
|
|
- if ( motion.position.y < - 123 ) {
|
|
|
-
|
|
|
- motion.position.set( - 2, 7.7, 25 );
|
|
|
- motion.velocity.multiplyScalar( 0 );
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- var keyboardControls = ( function () {
|
|
|
-
|
|
|
- var keys = { SP: 32, W: 87, A: 65, S: 83, D: 68, UP: 38, LT: 37, DN: 40, RT: 39 };
|
|
|
-
|
|
|
- var keysPressed = {};
|
|
|
-
|
|
|
- ( function ( watchedKeyCodes ) {
|
|
|
-
|
|
|
- var handler = function ( down ) {
|
|
|
-
|
|
|
- return function ( e ) {
|
|
|
-
|
|
|
- var index = watchedKeyCodes.indexOf( e.keyCode );
|
|
|
- if ( index >= 0 ) {
|
|
|
-
|
|
|
- keysPressed[ watchedKeyCodes[ index ] ] = down;
|
|
|
- e.preventDefault();
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- };
|
|
|
- window.addEventListener( "keydown", handler( true ), false );
|
|
|
- window.addEventListener( "keyup", handler( false ), false );
|
|
|
-
|
|
|
- } )( [
|
|
|
- keys.SP, keys.W, keys.A, keys.S, keys.D, keys.UP, keys.LT, keys.DN, keys.RT
|
|
|
- ] );
|
|
|
-
|
|
|
- var forward = new THREE.Vector3();
|
|
|
- var sideways = new THREE.Vector3();
|
|
|
-
|
|
|
- return function () {
|
|
|
-
|
|
|
- if ( ! motion.airborne ) {
|
|
|
-
|
|
|
- // look around
|
|
|
- var sx = keysPressed[ keys.UP ] ? 0.03 : ( keysPressed[ keys.DN ] ? - 0.03 : 0 );
|
|
|
- var sy = keysPressed[ keys.LT ] ? 0.03 : ( keysPressed[ keys.RT ] ? - 0.03 : 0 );
|
|
|
-
|
|
|
- if ( Math.abs( sx ) >= Math.abs( motion.spinning.x ) ) motion.spinning.x = sx;
|
|
|
- if ( Math.abs( sy ) >= Math.abs( motion.spinning.y ) ) motion.spinning.y = sy;
|
|
|
-
|
|
|
- // move around
|
|
|
- forward.set( Math.sin( motion.rotation.y ), 0, Math.cos( motion.rotation.y ) );
|
|
|
- sideways.set( forward.z, 0, - forward.x );
|
|
|
-
|
|
|
- forward.multiplyScalar( keysPressed[ keys.W ] ? - 0.1 : ( keysPressed[ keys.S ] ? 0.1 : 0 ) );
|
|
|
- sideways.multiplyScalar( keysPressed[ keys.A ] ? - 0.1 : ( keysPressed[ keys.D ] ? 0.1 : 0 ) );
|
|
|
-
|
|
|
- var combined = forward.add( sideways );
|
|
|
- if ( Math.abs( combined.x ) >= Math.abs( motion.velocity.x ) ) motion.velocity.x = combined.x;
|
|
|
- if ( Math.abs( combined.y ) >= Math.abs( motion.velocity.y ) ) motion.velocity.y = combined.y;
|
|
|
- if ( Math.abs( combined.z ) >= Math.abs( motion.velocity.z ) ) motion.velocity.z = combined.z;
|
|
|
-
|
|
|
- //jump
|
|
|
- var vy = keysPressed[ keys.SP ] ? 0.7 : 0;
|
|
|
- motion.velocity.y += vy;
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- } )();
|
|
|
-
|
|
|
- var jumpPads = ( function () {
|
|
|
-
|
|
|
- var pads = [ new THREE.Vector3( - 17.5, 8, - 10 ), new THREE.Vector3( 17.5, 8, - 10 ), new THREE.Vector3( 0, 8, 21 ) ];
|
|
|
- var temp = new THREE.Vector3();
|
|
|
-
|
|
|
- return function () {
|
|
|
-
|
|
|
- if ( ! motion.airborne ) {
|
|
|
-
|
|
|
- for ( var j = 0, n = pads.length; j < n; j ++ ) {
|
|
|
-
|
|
|
- if ( pads[ j ].distanceToSquared( motion.position ) < 2.3 ) {
|
|
|
-
|
|
|
- // calculate velocity towards another side of platform from jump pad position
|
|
|
- temp.copy( pads[ j ] );
|
|
|
- temp.y = 0;
|
|
|
- temp.setLength( - 0.8 );
|
|
|
- temp.y = 0.7;
|
|
|
-
|
|
|
- motion.airborne = true;
|
|
|
- motion.velocity.copy( temp );
|
|
|
- break;
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- } )();
|
|
|
-
|
|
|
- var applyPhysics = ( function () {
|
|
|
-
|
|
|
- var timeStep = 5;
|
|
|
- var timeLeft = timeStep + 1;
|
|
|
-
|
|
|
- var birdsEye = 100;
|
|
|
- var kneeDeep = 0.4;
|
|
|
-
|
|
|
- var raycaster = new THREE.Raycaster();
|
|
|
- raycaster.ray.direction.set( 0, - 1, 0 );
|
|
|
-
|
|
|
- var angles = new THREE.Vector2();
|
|
|
- var displacement = new THREE.Vector3();
|
|
|
-
|
|
|
- return function ( dt ) {
|
|
|
-
|
|
|
- var platform = scene.getObjectByName( "platform", true );
|
|
|
- if ( platform ) {
|
|
|
-
|
|
|
- timeLeft += dt;
|
|
|
-
|
|
|
- // run several fixed-step iterations to approximate varying-step
|
|
|
-
|
|
|
- dt = 5;
|
|
|
- while ( timeLeft >= dt ) {
|
|
|
-
|
|
|
- var time = 0.3, damping = 0.93, gravity = 0.01, tau = 2 * Math.PI;
|
|
|
-
|
|
|
- raycaster.ray.origin.copy( motion.position );
|
|
|
- raycaster.ray.origin.y += birdsEye;
|
|
|
-
|
|
|
- var hits = raycaster.intersectObject( platform );
|
|
|
-
|
|
|
- motion.airborne = true;
|
|
|
-
|
|
|
- // are we above, or at most knee deep in, the platform?
|
|
|
-
|
|
|
- if ( ( hits.length > 0 ) && ( hits[ 0 ].face.normal.y > 0 ) ) {
|
|
|
-
|
|
|
- var actualHeight = hits[ 0 ].distance - birdsEye;
|
|
|
-
|
|
|
- // collision: stick to the surface if landing on it
|
|
|
-
|
|
|
- if ( ( motion.velocity.y <= 0 ) && ( Math.abs( actualHeight ) < kneeDeep ) ) {
|
|
|
-
|
|
|
- motion.position.y -= actualHeight;
|
|
|
- motion.velocity.y = 0;
|
|
|
- motion.airborne = false;
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- if ( motion.airborne ) motion.velocity.y -= gravity;
|
|
|
-
|
|
|
- angles.copy( motion.spinning ).multiplyScalar( time );
|
|
|
- if ( ! motion.airborne ) motion.spinning.multiplyScalar( damping );
|
|
|
-
|
|
|
- displacement.copy( motion.velocity ).multiplyScalar( time );
|
|
|
- if ( ! motion.airborne ) motion.velocity.multiplyScalar( damping );
|
|
|
-
|
|
|
- motion.rotation.add( angles );
|
|
|
- motion.position.add( displacement );
|
|
|
-
|
|
|
- // limit the tilt at ±0.4 radians
|
|
|
-
|
|
|
- motion.rotation.x = Math.max( - 0.4, Math.min( + 0.4, motion.rotation.x ) );
|
|
|
-
|
|
|
- // wrap horizontal rotation to 0...2π
|
|
|
-
|
|
|
- motion.rotation.y += tau;
|
|
|
- motion.rotation.y %= tau;
|
|
|
-
|
|
|
- timeLeft -= dt;
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- } )();
|
|
|
-
|
|
|
- var updateCamera = ( function () {
|
|
|
-
|
|
|
- var euler = new THREE.Euler( 0, 0, 0, 'YXZ' );
|
|
|
-
|
|
|
- return function () {
|
|
|
-
|
|
|
- euler.x = motion.rotation.x;
|
|
|
- euler.y = motion.rotation.y;
|
|
|
- camera.quaternion.setFromEuler( euler );
|
|
|
-
|
|
|
- camera.position.copy( motion.position );
|
|
|
-
|
|
|
- camera.position.y += 3.0;
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- } )();
|
|
|
-
|
|
|
-
|
|
|
- // init 3D stuff
|
|
|
-
|
|
|
- function makePlatform( url ) {
|
|
|
-
|
|
|
- var placeholder = new THREE.Object3D();
|
|
|
-
|
|
|
- var loader = new THREE.ObjectLoader();
|
|
|
- loader.load( url, function ( platform ) {
|
|
|
-
|
|
|
- placeholder.add( platform );
|
|
|
-
|
|
|
- } );
|
|
|
-
|
|
|
- return placeholder;
|
|
|
-
|
|
|
- }
|
|
|
-
|
|
|
- var renderer = new THREE.WebGLRenderer( { antialias: true } );
|
|
|
- renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
- document.body.appendChild( renderer.domElement );
|
|
|
-
|
|
|
- var camera = new THREE.PerspectiveCamera( 60, 1, 0.1, 9000 );
|
|
|
-
|
|
|
- var scene = new THREE.Scene();
|
|
|
-
|
|
|
- var envMap = new THREE.CubeTextureLoader().load( [
|
|
|
- 'textures/cube/skybox/px.jpg', // right
|
|
|
- 'textures/cube/skybox/nx.jpg', // left
|
|
|
- 'textures/cube/skybox/py.jpg', // top
|
|
|
- 'textures/cube/skybox/ny.jpg', // bottom
|
|
|
- 'textures/cube/skybox/pz.jpg', // back
|
|
|
- 'textures/cube/skybox/nz.jpg' // front
|
|
|
- ] );
|
|
|
- envMap.format = THREE.RGBFormat;
|
|
|
-
|
|
|
- scene.background = envMap;
|
|
|
-
|
|
|
- scene.add( makePlatform(
|
|
|
- 'models/json/platform/platform.json'
|
|
|
- ) );
|
|
|
-
|
|
|
- // start the game
|
|
|
-
|
|
|
- var start = function ( gameLoop, gameViewportSize ) {
|
|
|
-
|
|
|
- var resize = function () {
|
|
|
-
|
|
|
- var viewport = gameViewportSize();
|
|
|
- renderer.setSize( viewport.width, viewport.height );
|
|
|
- camera.aspect = viewport.width / viewport.height;
|
|
|
- camera.updateProjectionMatrix();
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- window.addEventListener( 'resize', resize, false );
|
|
|
- resize();
|
|
|
-
|
|
|
- var lastTimeStamp;
|
|
|
- var render = function ( timeStamp ) {
|
|
|
-
|
|
|
- var timeElapsed = lastTimeStamp ? timeStamp - lastTimeStamp : 0;
|
|
|
- lastTimeStamp = timeStamp;
|
|
|
-
|
|
|
- // call our game loop with the time elapsed since last rendering, in ms
|
|
|
- gameLoop( timeElapsed );
|
|
|
-
|
|
|
- renderer.render( scene, camera );
|
|
|
- requestAnimationFrame( render );
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- requestAnimationFrame( render );
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
-
|
|
|
- var gameLoop = function ( dt ) {
|
|
|
-
|
|
|
- resetPlayer();
|
|
|
- keyboardControls();
|
|
|
- jumpPads();
|
|
|
- applyPhysics( dt );
|
|
|
- updateCamera();
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- var gameViewportSize = function () {
|
|
|
-
|
|
|
- return {
|
|
|
-
|
|
|
- width: window.innerWidth, height: window.innerHeight
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- };
|
|
|
-
|
|
|
- start( gameLoop, gameViewportSize );
|
|
|
- </script>
|
|
|
- </body>
|
|
|
-</html>
|
Michael Herzog
