Merge pull request #13196 from node-3d/dev

Added GLBufferAttribute
Mr.doob 5 年之前
父節點
567b6facbe c73e993ea0
當前提交
ba9f8597d4
共有 13 個文件被更改，包括 565 次插入 和 1 次删除
分割檢視 顯示文件統計
  1. 117 0
      docs/api/en/core/GLBufferAttribute.html
  2. 117 0
      docs/api/zh/core/GLBufferAttribute.html
  3. 2 0
      docs/list.js
  4. 1 0
      examples/files.js
  5. 二進制
      examples/screenshots/webgl_buffergeometry_points_glbufferattribute.jpg
  6. 二進制
      examples/screenshots/webgl_buffergeometry_points_glbufferattribute.png
  7. 174 0
      examples/webgl_buffergeometry_points_glbufferattribute.html
  8. 1 0
      src/Three.js
  9. 24 1
      src/core/BufferGeometry.js
  10. 31 0
      src/core/GLBufferAttribute.d.ts
  11. 77 0
      src/core/GLBufferAttribute.js
  12. 19 0
      src/renderers/webgl/WebGLAttributes.js
  13. 2 0
      src/renderers/webgl/WebGLBindingStates.js

+ 117 - 0
docs/api/en/core/GLBufferAttribute.html
查看文件

@@ -0,0 +1,117 @@

+<!DOCTYPE html>

+<html lang="en">

+	<head>

+		<meta charset="utf-8" />

+		<base href="../../../" />

+		<script src="list.js"></script>

+		<script src="page.js"></script>

+		<link type="text/css" rel="stylesheet" href="page.css" />

+	</head>

+	<body>

+		<h1>[name]</h1>

+

+		<p class="desc">

+			This buffer attribute class does not construct a VBO. Instead, it uses

+			whatever VBO is passed in constructor and can later be altered via the

+			*buffer* property.<br /><br />

+			It is required to pass additional params alongside the VBO. Those are:

+			the GL context, the GL data type, the number of components per vertex,

+			the number of bytes per component, and the number of vertices.<br /><br />

+			The most common use case for this class is when some kind of GPGPU

+			calculation interferes or even produces the VBOs in question.

+		</p>

+

+		<h2>Constructor</h2>

+		<h3>[name]( [param:WebGLBuffer buffer], [param:GLenum type], [param:Integer itemSize], [param:Integer elementSize], [param:Integer count] )</h3>

+		<p>

+		*buffer* — Must be a <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGLBuffer" target="_blank">WebGLBuffer</a>.

+		<br />

+		*type* — One of <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGL_API/Constants#Data_types" target="_blank">WebGL Data Types</a>.

+		<br />

+		*itemSize* — The number of values of the array that should be associated with

+		a particular vertex. For instance, if this

+		attribute is storing a 3-component vector (such as a position, normal, or color), then itemSize should be 3.

+		<br />

+		*elementSize* — 1, 2 or 4. The corresponding size (in bytes) for the given "type" param.

+		<ul>

+			<li>gl.FLOAT: 4</li>

+			<li>gl.UNSIGNED_SHORT: 2</li>

+			<li>gl.SHORT: 2</li>

+			<li>gl.UNSIGNED_INT: 4</li>

+			<li>gl.INT: 4</li>

+			<li>gl.BYTE: 1</li>

+			<li>gl.UNSIGNED_BYTE: 1</li>

+		</ul>

+		*count* — The expected number of vertices in VBO.

+		</p>

+

+		<h2>Properties</h2>

+

+		<h3>[property:WebGLBuffer buffer]</h3>

+		<p>

+			The current <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGLBuffer" target="_blank">WebGLBuffer</a> instance.

+		</p>

+

+		<h3>[property:Integer count]</h3>

+		<p>

+			The expected number of vertices in VBO.

+		</p>

+

+		<h3>[property:Integer itemSize]</h3>

+		<p>

+			How many values make up each item (vertex).

+		</p>

+

+		<h3>[property:Integer elementSize]</h3>

+		<p>

+			Stores the corresponding size in bytes for the current *type* property value.

+		</p>

+		<p>

+			See above (constructor) for a list of known type sizes.

+		</p>

+

+		<h3>[property:GLenum type]</h3>

+		<p>

+			A <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGL_API/Constants#Data_types" target="_blank">WebGL Data Type</a>

+			describing the underlying VBO contents.

+		</p>

+		<p>

+			Set this property together with *elementSize*. The recommended way is

+			using the *setType* method.

+		</p>

+

+		<h3>[property:Boolean isGLBufferAttribute]</h3>

+		<p>

+			Read-only. Always *true*.

+		</p>

+

+		<h2>Methods</h2>

+

+		<h3>[method:null setBuffer]( buffer ) </h3>

+		<p>Sets the *buffer* property.</p>

+

+		<h3>[method:null setType]( type, elementSize ) </h3>

+		<p>Sets the both *type* and *elementSize* properties.</p>

+

+		<h3>[method:null setItemSize]( itemSize ) </h3>

+		<p>Sets the *itemSize* property.</p>

+

+		<h3>[method:null setCount]( count ) </h3>

+		<p>Sets the *count* property.</p>

+

+		<h3>[property:Integer version]</h3>

+		<p>

+		A version number, incremented every time the needsUpdate property is set to true.

+		</p>

+

+		<h3>[property:Boolean needsUpdate]</h3>

+		<p>

+		Default is *false*. Setting this to true increments [page:GLBufferAttribute.version version].

+		</p>

+

+		<h2>Source</h2>

+		<p>

+			[link:https://github.com/mrdoob/three.js/blob/master/src/[path].js src/[path].js]

+		</p>

+	</body>

+</html>

+ 117 - 0
docs/api/zh/core/GLBufferAttribute.html
查看文件

@@ -0,0 +1,117 @@

+<!DOCTYPE html>

+<html lang="en">

+	<head>

+		<meta charset="utf-8" />

+		<base href="../../../" />

+		<script src="list.js"></script>

+		<script src="page.js"></script>

+		<link type="text/css" rel="stylesheet" href="page.css" />

+	</head>

+	<body>

+		<h1>[name]</h1>

+

+		<p class="desc">

+			This buffer attribute class does not construct a VBO. Instead, it uses

+			whatever VBO is passed in constructor and can later be altered via the

+			*buffer* property.<br /><br />

+			It is required to pass additional params alongside the VBO. Those are:

+			the GL context, the GL data type, the number of components per vertex,

+			the number of bytes per component, and the number of vertices.<br /><br />

+			The most common use case for this class is when some kind of GPGPU

+			calculation interferes or even produces the VBOs in question.

+		</p>

+

+		<h2>Constructor</h2>

+		<h3>[name]( [param:WebGLBuffer buffer], [param:GLenum type], [param:Integer itemSize], [param:Integer elementSize], [param:Integer count] )</h3>

+		<p>

+		*buffer* — Must be a <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGLBuffer" target="_blank">WebGLBuffer</a>.

+		<br />

+		*type* — One of <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGL_API/Constants#Data_types" target="_blank">WebGL Data Types</a>.

+		<br />

+		*itemSize* — The number of values of the array that should be associated with

+		a particular vertex. For instance, if this

+		attribute is storing a 3-component vector (such as a position, normal, or color), then itemSize should be 3.

+		<br />

+		*elementSize* — 1, 2 or 4. The corresponding size (in bytes) for the given "type" param.

+		<ul>

+			<li>gl.FLOAT: 4</li>

+			<li>gl.UNSIGNED_SHORT: 2</li>

+			<li>gl.SHORT: 2</li>

+			<li>gl.UNSIGNED_INT: 4</li>

+			<li>gl.INT: 4</li>

+			<li>gl.BYTE: 1</li>

+			<li>gl.UNSIGNED_BYTE: 1</li>

+		</ul>

+		*count* — The expected number of vertices in VBO.

+		</p>

+

+		<h2>Properties</h2>

+

+		<h3>[property:WebGLBuffer buffer]</h3>

+		<p>

+			The current <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGLBuffer" target="_blank">WebGLBuffer</a> instance.

+		</p>

+

+		<h3>[property:Integer count]</h3>

+		<p>

+			The expected number of vertices in VBO.

+		</p>

+

+		<h3>[property:Integer itemSize]</h3>

+		<p>

+			How many values make up each item (vertex).

+		</p>

+

+		<h3>[property:Integer elementSize]</h3>

+		<p>

+			Stores the corresponding size in bytes for the current *type* property value.

+		</p>

+		<p>

+			See above (constructor) for a list of known type sizes.

+		</p>

+

+		<h3>[property:GLenum type]</h3>

+		<p>

+			A <a href="https://developer.mozilla.org/en-US/docs/Web/API/WebGL_API/Constants#Data_types" target="_blank">WebGL Data Type</a>

+			describing the underlying VBO contents.

+		</p>

+		<p>

+			Set this property together with *elementSize*. The recommended way is

+			using the *setType* method.

+		</p>

+

+		<h3>[property:Boolean isGLBufferAttribute]</h3>

+		<p>

+			Read-only. Always *true*.

+		</p>

+

+		<h2>Methods</h2>

+

+		<h3>[method:null setBuffer]( buffer ) </h3>

+		<p>Sets the *buffer* property.</p>

+

+		<h3>[method:null setType]( type, elementSize ) </h3>

+		<p>Sets the both *type* and *elementSize* properties.</p>

+

+		<h3>[method:null setItemSize]( itemSize ) </h3>

+		<p>Sets the *itemSize* property.</p>

+

+		<h3>[method:null setCount]( count ) </h3>

+		<p>Sets the *count* property.</p>

+

+		<h3>[property:Integer version]</h3>

+		<p>

+		A version number, incremented every time the needsUpdate property is set to true.

+		</p>

+

+		<h3>[property:Boolean needsUpdate]</h3>

+		<p>

+		Default is *false*. Setting this to true increments [page:GLBufferAttribute.version version].

+		</p>

+

+		<h2>Source</h2>

+		<p>

+			[link:https://github.com/mrdoob/three.js/blob/master/src/[path].js src/[path].js]

+		</p>

+	</body>

+</html>

+ 2 - 0
docs/list.js
查看文件

@@ -89,6 +89,7 @@ var list = {

 				"EventDispatcher": "api/en/core/EventDispatcher",

 				"Face3": "api/en/core/Face3",

 				"Geometry": "api/en/core/Geometry",

+				"GLBufferAttribute": "api/en/core/GLBufferAttribute",

 				"InstancedBufferAttribute": "api/en/core/InstancedBufferAttribute",

 				"InstancedBufferGeometry": "api/en/core/InstancedBufferGeometry",

 				"InstancedInterleavedBuffer": "api/en/core/InstancedInterleavedBuffer",

@@ -570,6 +571,7 @@ var list = {

 				"EventDispatcher": "api/zh/core/EventDispatcher",

 				"Face3": "api/zh/core/Face3",

 				"Geometry": "api/zh/core/Geometry",

+				"GLBufferAttribute": "api/zh/core/GLBufferAttribute",

 				"InstancedBufferAttribute": "api/zh/core/InstancedBufferAttribute",

 				"InstancedBufferGeometry": "api/zh/core/InstancedBufferGeometry",

 				"InstancedInterleavedBuffer": "api/zh/core/InstancedInterleavedBuffer",

+ 1 - 0
examples/files.js
查看文件

@@ -287,6 +287,7 @@ var files = {

 		"webgl_buffergeometry_lines_indexed",

 		"webgl_buffergeometry_morphtargets",

 		"webgl_buffergeometry_points",

+		"webgl_buffergeometry_points_glbufferattribute",

 		"webgl_buffergeometry_points_interleaved",

 		"webgl_buffergeometry_rawshader",

 		"webgl_buffergeometry_selective_draw",

二進制
examples/screenshots/webgl_buffergeometry_points_glbufferattribute.jpg
查看文件


二進制
examples/screenshots/webgl_buffergeometry_points_glbufferattribute.png
查看文件


+ 174 - 0
examples/webgl_buffergeometry_points_glbufferattribute.html
查看文件

@@ -0,0 +1,174 @@

+<!DOCTYPE html>

+<html lang="en">

+	<head>

+		<title>three.js webgl - buffergeometry - custom VBOs</title>

+		<meta charset="utf-8">

+		<meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">

+		<link type="text/css" rel="stylesheet" href="main.css">

+	</head>

+	<body>

+

+		<div id="container"></div>

+		<div id="info"><a href="https://threejs.org" target="_blank" rel="noopener">three.js</a> webgl - buffergeometry - custom VBOs</div>

+

+		<script type="module">

+

+			import * as THREE from '../build/three.module.js';

+

+			import Stats from './jsm/libs/stats.module.js';

+
+			var container, stats;

+

+			var camera, scene, renderer;

+

+			var points;

+

+			var particles = 300000;

+

+			init();

+			animate();

+

+			function init() {

+

+				container = document.getElementById( 'container' );

+

+				//

+

+				renderer = new THREE.WebGLRenderer( { antialias: false } );

+				renderer.setPixelRatio( window.devicePixelRatio );

+				renderer.setSize( window.innerWidth, window.innerHeight );

+

+				container.appendChild( renderer.domElement );

+

+				//

+

+				camera = new THREE.PerspectiveCamera( 27, window.innerWidth / window.innerHeight, 5, 3500 );

+				camera.position.z = 2750;

+

+				scene = new THREE.Scene();

+				scene.background = new THREE.Color( 0x050505 );

+				scene.fog = new THREE.Fog( 0x050505, 2000, 3500 );

+

+				//

+

+				var geometry = new THREE.BufferGeometry();

+

+				var positions = [];

+				var positions2 = [];

+				var colors = [];

+

+				var color = new THREE.Color();

+

+				var n = 1000, n2 = n / 2; // particles spread in the cube

+

+				for ( var i = 0; i < particles; i ++ ) {

+

+					// positions

+

+					var x = Math.random() * n - n2;

+					var y = Math.random() * n - n2;

+					var z = Math.random() * n - n2;

+

+					positions.push( x, y, z );

+					positions2.push( z * 0.3, x * 0.3, y * 0.3 );

+

+					// colors

+

+					var vx = ( x / n ) + 0.5;

+					var vy = ( y / n ) + 0.5;

+					var vz = ( z / n ) + 0.5;

+

+					color.setRGB( vx, vy, vz );

+

+					colors.push( color.r, color.g, color.b );

+

+				}

+

+				var gl = renderer.getContext();

+

+				var pos = gl.createBuffer();

+				gl.bindBuffer( gl.ARRAY_BUFFER, pos );

+				gl.bufferData( gl.ARRAY_BUFFER, new Float32Array( positions ), gl.STATIC_DRAW );

+

+				var pos2 = gl.createBuffer();

+				gl.bindBuffer( gl.ARRAY_BUFFER, pos2 );

+				gl.bufferData( gl.ARRAY_BUFFER, new Float32Array( positions2 ), gl.STATIC_DRAW );

+

+				var rgb = gl.createBuffer();

+				gl.bindBuffer( gl.ARRAY_BUFFER, rgb );

+				gl.bufferData( gl.ARRAY_BUFFER, new Float32Array( colors ), gl.STATIC_DRAW );

+

+				var posAttr = new THREE.GLBufferAttribute( pos, gl.FLOAT, 3, 4, particles );

+				geometry.setAttribute( 'position', posAttr );

+

+				setInterval( function () {

+

+					posAttr.buffer = ( posAttr.buffer === pos ) ? pos2 : pos;

+					posAttr.needsUpdate = true;

+

+				}, 2000 );

+

+				geometry.setAttribute( 'color', new THREE.GLBufferAttribute( rgb, gl.FLOAT, 3, 4, particles ) );

+

+				//

+

+				var material = new THREE.PointsMaterial( { size: 15, vertexColors: THREE.VertexColors } );

+

+				points = new THREE.Points( geometry, material );

+

+				// Choose one:

+				// geometry.boundingSphere = ( new THREE.Sphere() ).set( new THREE.Vector3(), Infinity );

+				points.frustumCulled = false;

+

+				scene.add( points );

+

+				//

+

+				stats = new Stats();

+				container.appendChild( stats.dom );

+

+				//

+

+				window.addEventListener( 'resize', onWindowResize, false );

+

+			}

+

+			function onWindowResize() {

+

+				camera.aspect = window.innerWidth / window.innerHeight;

+				camera.updateProjectionMatrix();

+

+				renderer.setSize( window.innerWidth, window.innerHeight );

+

+			}

+

+			//

+

+			function animate() {

+

+				requestAnimationFrame( animate );

+

+				render();

+				stats.update();

+

+			}

+

+			var drawCount = 10000;

+			function render() {

+

+				drawCount = ( Math.max( 5000, drawCount ) + Math.floor( 500 * Math.random() ) ) % particles;

+				points.geometry.setDrawRange( 0, drawCount );

+

+				var time = Date.now() * 0.001;

+

+				points.rotation.x = time * 0.1;

+				points.rotation.y = time * 0.2;

+

+				renderer.render( scene, camera );

+

+			}

+

+		</script>

+

+	</body>

+</html>

+ 1 - 0
src/Three.js
查看文件

@@ -98,6 +98,7 @@ export { InterleavedBufferAttribute } from './core/InterleavedBufferAttribute.js

 export { InstancedInterleavedBuffer } from './core/InstancedInterleavedBuffer.js';

 export { InterleavedBuffer } from './core/InterleavedBuffer.js';

 export { InstancedBufferAttribute } from './core/InstancedBufferAttribute.js';

+export { GLBufferAttribute } from './core/GLBufferAttribute.js';

 export * from './core/BufferAttribute.js';

 export { Face3 } from './core/Face3.js';

 export { Object3D } from './core/Object3D.js';

+ 24 - 1
src/core/BufferGeometry.js
查看文件

@@ -554,6 +554,19 @@ BufferGeometry.prototype = Object.assign( Object.create( EventDispatcher.prototy

 		const position = this.attributes.position;

 		const morphAttributesPosition = this.morphAttributes.position;


+		if ( position && position.isGLBufferAttribute ) {

+

+			console.error( 'THREE.BufferGeometry.computeBoundingBox(): GLBufferAttribute requires a manual bounding box. Alternatively set "mesh.frustumCulled" to "false".', this );

+

+			this.boundingBox.set(

+				new Vector3( - Infinity, - Infinity, - Infinity ),

+				new Vector3( + Infinity, + Infinity, + Infinity )

+			);

+

+			return;

+

+		}

+

 		if ( position !== undefined ) {


 			this.boundingBox.setFromBufferAttribute( position );

@@ -594,7 +607,7 @@ BufferGeometry.prototype = Object.assign( Object.create( EventDispatcher.prototy


 		if ( isNaN( this.boundingBox.min.x ) || isNaN( this.boundingBox.min.y ) || isNaN( this.boundingBox.min.z ) ) {


-			console.error( 'THREE.BufferGeometry.computeBoundingBox: Computed min/max have NaN values. The "position" attribute is likely to have NaN values.', this );

+			console.error( 'THREE.BufferGeometry.computeBoundingBox(): Computed min/max have NaN values. The "position" attribute is likely to have NaN values.', this );


 		}


@@ -611,6 +624,16 @@ BufferGeometry.prototype = Object.assign( Object.create( EventDispatcher.prototy

 		const position = this.attributes.position;

 		const morphAttributesPosition = this.morphAttributes.position;


+		if ( position && position.isGLBufferAttribute ) {

+

+			console.error( 'THREE.BufferGeometry.computeBoundingSphere(): GLBufferAttribute requires a manual bounding sphere. Alternatively set "mesh.frustumCulled" to "false".', this );

+

+			this.boundingSphere.set( new Vector3(), Infinity );

+

+			return;

+

+		}

+

 		if ( position ) {


 			// first, find the center of the bounding sphere

+ 31 - 0
src/core/GLBufferAttribute.d.ts
查看文件

@@ -0,0 +1,31 @@

+/**

+ * @see <a href="https://github.com/mrdoob/three.js/blob/master/src/core/GLBufferAttribute.js">src/core/GLBufferAttribute.js</a>

+ */

+

+export class GLBufferAttribute {

+

+	constructor(

+		buffer: WebGLBuffer,

+		type: number,

+		itemSize: number,

+		elementSize: 1 | 2 | 4,

+		count: number

+	);

+

+	buffer: WebGLBuffer;

+	type: number;

+	itemSize: number;

+	elementSize: 1 | 2 | 4;

+	count: number;

+	version: number;

+

+	readonly isGLBufferAttribute: true;

+

+	set needsUpdate( value: boolean );

+

+	setBuffer( buffer: WebGLBuffer ): this;

+	setType( type: number, elementSize: 1 | 2 | 4 ): this;

+	setItemSize( itemSize: number ): this;

+	setCount( count: number ): this;

+

+}

+ 77 - 0
src/core/GLBufferAttribute.js
查看文件

@@ -0,0 +1,77 @@

+/**

+ * @author raub / https://github.com/raub

+ */

+

+/**

+ * Element size is one of:

+ * gl.FLOAT: 4

+ * gl.UNSIGNED_SHORT: 2

+ * gl.SHORT: 2

+ * gl.UNSIGNED_INT: 4

+ * gl.INT: 4

+ * gl.BYTE: 1

+ * gl.UNSIGNED_BYTE: 1

+ */

+function GLBufferAttribute( buffer, type, itemSize, elementSize, count ) {

+

+	this.buffer = buffer;

+	this.type = type;

+	this.itemSize = itemSize;

+	this.elementSize = elementSize;

+	this.count = count;

+

+	this.version = 0;

+

+}

+

+Object.defineProperty( GLBufferAttribute.prototype, 'needsUpdate', {

+

+	set: function ( value ) {

+

+		if ( value === true ) this.version ++;

+

+	}

+

+} );

+

+Object.assign( GLBufferAttribute.prototype, {

+

+	isGLBufferAttribute: true,

+

+	setBuffer: function ( buffer ) {

+

+		this.buffer = buffer;

+

+		return this;

+

+	},

+

+	setType: function ( type, elementSize ) {

+

+		this.type = type;

+		this.elementSize = elementSize;

+

+		return this;

+

+	},

+

+	setItemSize: function ( itemSize ) {

+

+		this.itemSize = itemSize;

+

+		return this;

+

+	},

+

+	setCount: function ( count ) {

+

+		this.count = count;

+

+		return this;

+

+	},

+

+} );

+

+

+export { GLBufferAttribute };

+ 19 - 0
src/renderers/webgl/WebGLAttributes.js
查看文件

@@ -122,6 +122,25 @@ function WebGLAttributes( gl, capabilities ) {


 	function update( attribute, bufferType ) {


+		if ( attribute.isGLBufferAttribute ) {

+

+			var cached = buffers.get( attribute );

+

+			if ( ! cached || cached.version < attribute.version ) {

+

+				buffers.set( attribute, {

+					buffer: attribute.buffer,

+					type: attribute.type,

+					bytesPerElement: attribute.elementSize,

+					version: attribute.version

+				} );

+

+			}

+

+			return;

+

+		}

+

 		if ( attribute.isInterleavedBufferAttribute ) attribute = attribute.data;


 		const data = buffers.get( attribute );

+ 2 - 0
src/renderers/webgl/WebGLBindingStates.js
查看文件

@@ -176,6 +176,8 @@

 			const cachedAttribute = cachedAttributes[ key ];

 			const geometryAttribute = geometryAttributes[ key ];


+			if ( geometryAttribute.isGLBufferAttribute ) return true;

+

 			if ( cachedAttribute === undefined ) return true;


 			if ( cachedAttribute.attribute !== geometryAttribute ) return true;
