@@ -0,0 +1,322 @@
|
|
|
+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js - platformer demo</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
+ <style>
|
|
|
+ body {
|
|
|
+ background-color: rgb(200,200,200);
|
|
|
+ margin: 0px;
|
|
|
+ overflow: hidden;
|
|
|
+ }
|
|
|
+
|
|
|
+ #info {
|
|
|
+ position: absolute;
|
|
|
+ top: 0px; width: 100%;
|
|
|
+ color: #ffffff;
|
|
|
+ padding: 5px;
|
|
|
+ font-family:Monospace;
|
|
|
+ font-size:13px;
|
|
|
+ font-weight: bold;
|
|
|
+ text-align:center;
|
|
|
+ }
|
|
|
+
|
|
|
+ a {
|
|
|
+ color: #ffffff;
|
|
|
+ }
|
|
|
+ </style>
|
|
|
+ </head>
|
|
|
+ <body>
|
|
|
+
|
|
|
+ <div id="container"></div>
|
|
|
+ <div id="info"><a href="http://threejs.org" target="_blank">three.js</a> - platformer demo. cubemap by <a href="http://www.zfight.com/" target="_blank">Jochum Skoglund</a>.<br />Use arrow keys to look around and WASD to move.</div>
|
|
|
+
|
|
|
+ <script src="../build/three.min.js"></script>
|
|
|
+
|
|
|
+ <script>
|
|
|
+
|
|
|
+ // player motion parameters
|
|
|
+
|
|
|
+ var motion = {
|
|
|
+ airborne : false,
|
|
|
+ position : new THREE.Vector3(), velocity : new THREE.Vector3(),
|
|
|
+ rotation : new THREE.Vector2(), spinning : new THREE.Vector2()
|
|
|
+ };
|
|
|
+
|
|
|
+ motion.position.y = -150;
|
|
|
+
|
|
|
+
|
|
|
+ // game systems code
|
|
|
+
|
|
|
+ var resetPlayer = function() {
|
|
|
+ if( motion.position.y < -123 ) {
|
|
|
+ motion.position.set( -2, 7.7, 25 );
|
|
|
+ motion.velocity.multiplyScalar( 0 );
|
|
|
+ }
|
|
|
+ };
|
|
|
+
|
|
|
+ var keyboardControls = (function() {
|
|
|
+
|
|
|
+ var keys = { SP : 32, W : 87, A : 65, S : 83, D : 68, UP : 38, LT : 37, DN : 40, RT : 39 };
|
|
|
+
|
|
|
+ var keysPressed = {};
|
|
|
+
|
|
|
+ (function( watchedKeyCodes ) {
|
|
|
+ var handler = function( down ) {
|
|
|
+ return function( e ) {
|
|
|
+ var index = watchedKeyCodes.indexOf( e.keyCode );
|
|
|
+ if( index >= 0 ) {
|
|
|
+ keysPressed[watchedKeyCodes[index]] = down; e.preventDefault();
|
|
|
+ }
|
|
|
+ };
|
|
|
+ }
|
|
|
+ window.addEventListener( "keydown", handler( true ), false );
|
|
|
+ window.addEventListener( "keyup", handler( false ), false );
|
|
|
+ })([
|
|
|
+ keys.SP, keys.W, keys.A, keys.S, keys.D, keys.UP, keys.LT, keys.DN, keys.RT
|
|
|
+ ]);
|
|
|
+
|
|
|
+ var forward = new THREE.Vector3();
|
|
|
+ var sideways = new THREE.Vector3();
|
|
|
+
|
|
|
+ return function() {
|
|
|
+ if( !motion.airborne ) {
|
|
|
+
|
|
|
+ // look around
|
|
|
+ var sx = keysPressed[keys.UP] ? 0.04 : ( keysPressed[keys.DN] ? -0.04 : 0 );
|
|
|
+ var sy = keysPressed[keys.LT] ? 0.04 : ( keysPressed[keys.RT] ? -0.04 : 0 );
|
|
|
+
|
|
|
+ if( Math.abs( sx ) >= Math.abs( motion.spinning.x ) ) motion.spinning.x = sx;
|
|
|
+ if( Math.abs( sy ) >= Math.abs( motion.spinning.y ) ) motion.spinning.y = sy;
|
|
|
+
|
|
|
+ // move around
|
|
|
+ forward.set( Math.sin( motion.rotation.y ), 0, Math.cos( motion.rotation.y ) );
|
|
|
+ sideways.set( forward.z, 0, -forward.x );
|
|
|
+
|
|
|
+ forward.multiplyScalar( keysPressed[keys.W] ? -0.1 : (keysPressed[keys.S] ? 0.1 : 0));
|
|
|
+ sideways.multiplyScalar( keysPressed[keys.A] ? -0.1 : (keysPressed[keys.D] ? 0.1 : 0));
|
|
|
+
|
|
|
+ var combined = forward.add( sideways );
|
|
|
+ if( Math.abs( combined.x ) >= Math.abs( motion.velocity.x ) ) motion.velocity.x = combined.x;
|
|
|
+ if( Math.abs( combined.y ) >= Math.abs( motion.velocity.y ) ) motion.velocity.y = combined.y;
|
|
|
+ if( Math.abs( combined.z ) >= Math.abs( motion.velocity.z ) ) motion.velocity.z = combined.z;
|
|
|
+ }
|
|
|
+ };
|
|
|
+ })();
|
|
|
+
|
|
|
+ var jumpPads = (function() {
|
|
|
+ var pads = [ new THREE.Vector3( -17.5, 8, -10 ), new THREE.Vector3( 17.5, 8, -10 ), new THREE.Vector3( 0, 8, 21 ) ];
|
|
|
+ var temp = new THREE.Vector3();
|
|
|
+
|
|
|
+ return function() {
|
|
|
+ if( !motion.airborne ) {
|
|
|
+ for( var j = 0, n = pads.length; j < n; j++ ) {
|
|
|
+ if ( pads[j].distanceToSquared( motion.position ) < 2.3 ) {
|
|
|
+
|
|
|
+ // calculate velocity towards another side of platform from jump pad position
|
|
|
+ temp.copy( pads[j] ); temp.y = 0; temp.setLength( -0.8 ); temp.y = 0.7;
|
|
|
+
|
|
|
+ motion.airborne = true; motion.velocity.copy( temp ); break;
|
|
|
+ }
|
|
|
+ }
|
|
|
+ }
|
|
|
+ };
|
|
|
+ })();
|
|
|
+
|
|
|
+ var applyPhysics = (function() {
|
|
|
+ var timeStep = 5;
|
|
|
+ var timeLeft = timeStep + 1;
|
|
|
+
|
|
|
+ var birdsEye = 100;
|
|
|
+ var kneeDeep = 0.4;
|
|
|
+
|
|
|
+ var raycaster = new THREE.Raycaster();
|
|
|
+ raycaster.ray.direction.set( 0, -1, 0 );
|
|
|
+
|
|
|
+ var angles = new THREE.Vector2();
|
|
|
+ var displacement = new THREE.Vector3();
|
|
|
+
|
|
|
+ return function( dt ) {
|
|
|
+ var platform = scene.getObjectByName( "platform", true );
|
|
|
+ if( platform ) {
|
|
|
+
|
|
|
+ timeLeft += dt;
|
|
|
+
|
|
|
+ // run several fixed-step iterations to approximate varying-step
|
|
|
+
|
|
|
+ dt = 5;
|
|
|
+ while( timeLeft >= dt ) {
|
|
|
+
|
|
|
+ var time = 0.3, damping = 0.93, gravity = 0.01, tau = 2 * Math.PI;
|
|
|
+
|
|
|
+ raycaster.ray.origin.copy( motion.position );
|
|
|
+ raycaster.ray.origin.y += birdsEye;
|
|
|
+
|
|
|
+ var hits = raycaster.intersectObject( platform );
|
|
|
+
|
|
|
+ motion.airborne = true;
|
|
|
+
|
|
|
+ // are we above, or at most knee deep in, the platform?
|
|
|
+
|
|
|
+ if( ( hits.length > 0 ) && ( hits[0].face.normal.y > 0 ) ) {
|
|
|
+ var actualHeight = hits[0].distance - birdsEye;
|
|
|
+
|
|
|
+ // collision: stick to the surface if landing on it
|
|
|
+
|
|
|
+ if( ( motion.velocity.y <= 0 ) && ( Math.abs( actualHeight ) < kneeDeep ) ) {
|
|
|
+ motion.position.y -= actualHeight;
|
|
|
+ motion.velocity.y = 0;
|
|
|
+ motion.airborne = false;
|
|
|
+ }
|
|
|
+ }
|
|
|
+
|
|
|
+ if( motion.airborne ) motion.velocity.y -= gravity;
|
|
|
+
|
|
|
+ angles.copy( motion.spinning ).multiplyScalar( time );
|
|
|
+ if( !motion.airborne ) motion.spinning.multiplyScalar( damping );
|
|
|
+
|
|
|
+ displacement.copy( motion.velocity ).multiplyScalar( time );
|
|
|
+ if( !motion.airborne ) motion.velocity.multiplyScalar( damping );
|
|
|
+
|
|
|
+ motion.rotation.add( angles );
|
|
|
+ motion.position.add( displacement );
|
|
|
+
|
|
|
+ // limit the tilt at ±0.4 radians
|
|
|
+
|
|
|
+ motion.rotation.x = Math.max( -0.4, Math.min ( +0.4, motion.rotation.x ) );
|
|
|
+
|
|
|
+ // wrap horizontal rotation to 0...2π
|
|
|
+
|
|
|
+ motion.rotation.y += tau; motion.rotation.y %= tau;
|
|
|
+
|
|
|
+ timeLeft -= dt;
|
|
|
+ }
|
|
|
+ }
|
|
|
+ };
|
|
|
+ })();
|
|
|
+
|
|
|
+ var updateCamera = (function() {
|
|
|
+ var euler = new THREE.Euler( 0, 0, 0, 'YXZ' );
|
|
|
+
|
|
|
+ return function() {
|
|
|
+ euler.x = motion.rotation.x;
|
|
|
+ euler.y = motion.rotation.y;
|
|
|
+ camera.quaternion.setFromEuler( euler );
|
|
|
+
|
|
|
+ camera.position.copy( motion.position );
|
|
|
+
|
|
|
+ camera.position.y += 3.0;
|
|
|
+ };
|
|
|
+ })();
|
|
|
+
|
|
|
+
|
|
|
+ // init 3D stuff
|
|
|
+
|
|
|
+ function makeSkybox( urls, size ) {
|
|
|
+ var skyboxCubemap = THREE.ImageUtils.loadTextureCube( urls );
|
|
|
+ skyboxCubemap.format = THREE.RGBFormat;
|
|
|
+
|
|
|
+ var skyboxShader = THREE.ShaderLib['cube'];
|
|
|
+ skyboxShader.uniforms['tCube'].value = skyboxCubemap;
|
|
|
+
|
|
|
+ return new THREE.Mesh(
|
|
|
+ new THREE.BoxGeometry( size, size, size ),
|
|
|
+ new THREE.ShaderMaterial({
|
|
|
+ fragmentShader : skyboxShader.fragmentShader, vertexShader : skyboxShader.vertexShader,
|
|
|
+ uniforms : skyboxShader.uniforms, depthWrite : false, side : THREE.BackSide
|
|
|
+ })
|
|
|
+ );
|
|
|
+ };
|
|
|
+
|
|
|
+ function makePlatform( jsonUrl, textureUrl, textureQuality ) {
|
|
|
+ var placeholder = new THREE.Object3D();
|
|
|
+
|
|
|
+ var texture = THREE.ImageUtils.loadTexture( textureUrl );
|
|
|
+ texture.anisotropy = textureQuality;
|
|
|
+
|
|
|
+ var loader = new THREE.JSONLoader();
|
|
|
+ loader.load( jsonUrl, function( geometry ) {
|
|
|
+
|
|
|
+ geometry.computeFaceNormals();
|
|
|
+
|
|
|
+ var platform = new THREE.Mesh( geometry, new THREE.MeshBasicMaterial({ map : texture }) );
|
|
|
+
|
|
|
+ platform.name = "platform";
|
|
|
+
|
|
|
+ placeholder.add( platform );
|
|
|
+ });
|
|
|
+
|
|
|
+ return placeholder;
|
|
|
+ };
|
|
|
+
|
|
|
+ var renderer = new THREE.WebGLRenderer({ antialias : true });
|
|
|
+
|
|
|
+ var camera = new THREE.PerspectiveCamera( 90, 1, 0.1, 9000 );
|
|
|
+
|
|
|
+ var scene = new THREE.Scene();
|
|
|
+
|
|
|
+ scene.add( camera );
|
|
|
+
|
|
|
+ scene.add( makeSkybox( [
|
|
|
+ 'textures/cube/skybox/px.jpg', // right
|
|
|
+ 'textures/cube/skybox/nx.jpg', // left
|
|
|
+ 'textures/cube/skybox/py.jpg', // top
|
|
|
+ 'textures/cube/skybox/ny.jpg', // bottom
|
|
|
+ 'textures/cube/skybox/pz.jpg', // back
|
|
|
+ 'textures/cube/skybox/nz.jpg' // front
|
|
|
+ ], 8000 ));
|
|
|
+
|
|
|
+ scene.add( makePlatform(
|
|
|
+ 'models/platform/platform.json',
|
|
|
+ 'models/platform/platform.jpg',
|
|
|
+ renderer.getMaxAnisotropy()
|
|
|
+ ));
|
|
|
+
|
|
|
+
|
|
|
+ // start the game
|
|
|
+
|
|
|
+ var start = function( gameLoop, gameViewportSize ) {
|
|
|
+ var resize = function() {
|
|
|
+ var viewport = gameViewportSize();
|
|
|
+ renderer.setSize( viewport.width, viewport.height );
|
|
|
+ camera.aspect = viewport.width / viewport.height;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+ };
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', resize, false );
|
|
|
+ resize();
|
|
|
+
|
|
|
+ var lastTimeStamp;
|
|
|
+ var render = function( timeStamp ) {
|
|
|
+ var timeElapsed = lastTimeStamp ? timeStamp - lastTimeStamp : 0; lastTimeStamp = timeStamp;
|
|
|
+
|
|
|
+ // call our game loop with the time elapsed since last rendering, in ms
|
|
|
+ gameLoop( timeElapsed );
|
|
|
+
|
|
|
+ renderer.render( scene, camera );
|
|
|
+ requestAnimationFrame( render );
|
|
|
+ };
|
|
|
+
|
|
|
+ requestAnimationFrame( render );
|
|
|
+ };
|
|
|
+
|
|
|
+
|
|
|
+ var gameLoop = function( dt ) {
|
|
|
+ resetPlayer();
|
|
|
+ keyboardControls();
|
|
|
+ jumpPads();
|
|
|
+ applyPhysics( dt );
|
|
|
+ updateCamera();
|
|
|
+ };
|
|
|
+
|
|
|
+ var gameViewportSize = function() { return {
|
|
|
+ width: window.innerWidth, height: window.innerHeight
|
|
|
+ }};
|
|
|
+
|
|
|
+ document.getElementById( 'container' ).appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ start( gameLoop, gameViewportSize );
|
|
|
+ </script>
|
|
|
+ </body>
|
|
|
+</html>
|
makc
