+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js webvr - 360 6DOF panorama</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, initial-scale=1.0, user-scalable=no">
|
|
|
+ <link type="text/css" rel="stylesheet" href="main.css">
|
|
|
+ <!-- WebXR Device API (For Chrome M76+), expires 12/04/2019 -->
|
|
|
+ <meta http-equiv="origin-trial" content="Aq9LklhCLNUveuCr7QTpGpqwCPG817cYHdVyQuJPOZYk47iRB390lUKa5edVmgS1pZSl8HPspElEC/91Fz55dwIAAABTeyJvcmlnaW4iOiJodHRwczovL3RocmVlanMub3JnOjQ0MyIsImZlYXR1cmUiOiJXZWJYUkRldmljZU03NiIsImV4cGlyeSI6MTU3NTQxNzU5OX0=">
|
|
|
+ </head>
|
|
|
+ <body>
|
|
|
+ <div id="container"></div>
|
|
|
+
|
|
|
+ <div id="info">
|
|
|
+ <a href="http://threejs.org" target="_blank" rel="noopener">three.js</a> webvr - 360 6DOF panorama<br />
|
|
|
+ Written by <a href="https://orfleisher.com" target="_blank" rel="noopener">@juniorxsound</a>. Panorama from <a href="http://www.meryproject.com/" target="_blank" rel="noopener">reference panoramas</a>.
|
|
|
+ </div>
|
|
|
+
|
|
|
+ <script type="x-shader/x-vertex" id="vertexshader">
|
|
|
+ varying vec2 vUv;
|
|
|
+
|
|
|
+ uniform sampler2D depth_map;
|
|
|
+ uniform float displacement;
|
|
|
+
|
|
|
+ void main() {
|
|
|
+
|
|
|
+ vUv = uv;
|
|
|
+
|
|
|
+ float depth = texture2D(depth_map, uv).r;
|
|
|
+ float disp = displacement * depth;
|
|
|
+ vec3 offset = position + (-normal) * disp;
|
|
|
+
|
|
|
+ gl_Position = projectionMatrix *
|
|
|
+ modelViewMatrix *
|
|
|
+ vec4(offset, 1.0);
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script type="x-shader/x-fragment" id="fragmentshader">
|
|
|
+
|
|
|
+ varying vec2 vUv;
|
|
|
+
|
|
|
+ uniform sampler2D texture;
|
|
|
+
|
|
|
+ void main() {
|
|
|
+
|
|
|
+ gl_FragColor = texture2D(texture, vUv);
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script src="js/vr/HelioWebXRPolyfill.js"></script>
|
|
|
+
|
|
|
+ <script type="module">
|
|
|
+
|
|
|
+ import * as THREE from '../build/three.module.js';
|
|
|
+ import { WEBVR } from './jsm/vr/WebVR.js';
|
|
|
+
|
|
|
+ var camera, scene, renderer, sphere, clock;
|
|
|
+
|
|
|
+ init();
|
|
|
+ animate();
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ var container = document.getElementById( 'container' );
|
|
|
+
|
|
|
+ clock = new THREE.Clock();
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+ scene.background = new THREE.Color( 0x101010 );
|
|
|
+
|
|
|
+ camera = new THREE.PerspectiveCamera( 75, window.innerWidth / window.innerHeight, 1, 2000 );
|
|
|
+ var cameraRig = new THREE.Object3D();
|
|
|
+ cameraRig.position.y = -1.6;
|
|
|
+ cameraRig.add( camera );
|
|
|
+ scene.add( cameraRig );
|
|
|
+
|
|
|
+ // Create the panoramic sphere with the custom shader material
|
|
|
+ var panoSphereGeo = new THREE.SphereBufferGeometry( 6, 256, 256 );
|
|
|
+ var panoSphereMat = new THREE.ShaderMaterial({
|
|
|
+ uniforms: {
|
|
|
+ texture: { value : null },
|
|
|
+ depth_map: { value: null },
|
|
|
+ displacement: { value: 4 }
|
|
|
+ },
|
|
|
+ vertexShader: document.getElementById( 'vertexshader' ).textContent,
|
|
|
+ fragmentShader: document.getElementById( 'fragmentshader' ).textContent,
|
|
|
+ side: THREE.BackSide
|
|
|
+ });
|
|
|
+ sphere = new THREE.Mesh( panoSphereGeo, panoSphereMat );
|
|
|
+ scene.add( sphere );
|
|
|
+
|
|
|
+ // Load and assign the texture and depth map
|
|
|
+ var loader = new THREE.TextureLoader();
|
|
|
+ loader.load('./textures/kandao3.jpg', function ( texture ) {
|
|
|
+ texture.minFilter = THREE.NearestFilter
|
|
|
+ texture.magFilter = THREE.LinearFilter
|
|
|
+ texture.format = THREE.RGBFormat
|
|
|
+ texture.generateMipmaps = false
|
|
|
+ sphere.material.uniforms.texture.value = texture;
|
|
|
+ });
|
|
|
+
|
|
|
+ loader.load('./textures/kandao3_depthmap.jpg', function ( depth ) {
|
|
|
+ depth.minFilter = THREE.NearestFilter
|
|
|
+ depth.magFilter = THREE.LinearFilter
|
|
|
+ depth.format = THREE.RGBFormat
|
|
|
+ depth.generateMipmaps = false
|
|
|
+ sphere.material.uniforms.depth_map.value = depth;
|
|
|
+ });
|
|
|
+
|
|
|
+ renderer = new THREE.WebGLRenderer();
|
|
|
+ renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ renderer.vr.enabled = true;
|
|
|
+ container.appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ document.body.appendChild( WEBVR.createButton( renderer ) );
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', onWindowResize, false );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onWindowResize() {
|
|
|
+
|
|
|
+ camera.aspect = window.innerWidth / window.innerHeight;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function animate() {
|
|
|
+
|
|
|
+ renderer.setAnimationLoop( render );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function render() {
|
|
|
+
|
|
|
+ // If we are not presenting move the camera a little so the effect is visible
|
|
|
+ if (!renderer.vr.isPresenting()) {
|
|
|
+
|
|
|
+ var time = clock.getElapsedTime();
|
|
|
+
|
|
|
+ sphere.rotation.y += 0.001;
|
|
|
+ sphere.position.x = Math.sin(time) * 0.2;
|
|
|
+ sphere.position.z = Math.cos(time) * 0.2;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ renderer.render( scene, camera );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+ </body>
|
|
|
+</html>
|
