+<!DOCTYPE HTML>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js - cube map WebGL</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <style type="text/css">
|
|
|
+ body {
|
|
|
+ background:#000;
|
|
|
+ color:#fff;
|
|
|
+ padding:0;
|
|
|
+ margin:0;
|
|
|
+ overflow:hidden;
|
|
|
+ font-family:georgia;
|
|
|
+ text-align:center;
|
|
|
+ }
|
|
|
+ a { color: #ff0080; text-decoration: none; }
|
|
|
+ a:hover { color: #0080ff; }
|
|
|
+
|
|
|
+ canvas { pointer-events:none; z-index:10; position:relative; }
|
|
|
+ #log { position:absolute; top:50px; text-align:left; display:block; z-index:100; pointer-events:none; }
|
|
|
+ #d { text-align:center; margin:1em auto -9.5em; z-index:1000; position:relative; display:block;
|
|
|
+ background:rgba(0,0,0,0.5); padding:0.5em; width:400px; border-radius:15px; -webkit-box-shadow: 0px 0px 10px rgba(0,0,0,0.5) }
|
|
|
+ </style>
|
|
|
+ </head>
|
|
|
+
|
|
|
+ <body>
|
|
|
+ <div id="d">
|
|
|
+ <p><a href="http://github.com/mrdoob/three.js">Three.js</a> cube map refraction demo
|
|
|
+
|
|
|
+ <p>Lucy model from <a href="http://graphics.stanford.edu/data/3Dscanrep/">Stanford 3d scanning repository</a>
|
|
|
+ <p>Texture by <a href="http://www.humus.name/index.php?page=Textures" target="_blank">Humus</a>
|
|
|
+ </div>
|
|
|
+
|
|
|
+ <pre id="log"></pre>
|
|
|
+
|
|
|
+ <script type="text/javascript" src="../build/Three.js"></script>
|
|
|
+
|
|
|
+ <script type="text/javascript" src="../src/extras/primitives/Sphere.js"></script>
|
|
|
+ <script type="text/javascript" src="../src/extras/primitives/Plane.js"></script>
|
|
|
+ <script type="text/javascript" src="../src/extras/io/Loader.js"></script>
|
|
|
+
|
|
|
+ <script type="text/javascript" src="js/Stats.js"></script>
|
|
|
+
|
|
|
+ <script type="text/javascript">
|
|
|
+
|
|
|
+ var FLOOR = -250;
|
|
|
+
|
|
|
+ var container, stats;
|
|
|
+
|
|
|
+ var camera, scene, webglRenderer;
|
|
|
+ var cameraCube, sceneCube;
|
|
|
+
|
|
|
+ var mesh, zmesh, lightMesh, geometry;
|
|
|
+
|
|
|
+ var directionalLight, pointLight;
|
|
|
+
|
|
|
+ var mouseX = 0;
|
|
|
+ var mouseY = 0;
|
|
|
+
|
|
|
+ var windowHalfX = window.innerWidth / 2;
|
|
|
+ var windowHalfY = window.innerHeight / 2;
|
|
|
+
|
|
|
+ document.addEventListener('mousemove', onDocumentMouseMove, false);
|
|
|
+
|
|
|
+ init();
|
|
|
+ setInterval( loop, 1000 / 60 );
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ container = document.createElement('div');
|
|
|
+ document.body.appendChild(container);
|
|
|
+
|
|
|
+ camera = new THREE.Camera( 50, window.innerWidth / window.innerHeight, 1, 100000 );
|
|
|
+ camera.position.z = 2000;
|
|
|
+
|
|
|
+ cameraCube = new THREE.Camera( 50, window.innerWidth / window.innerHeight, 1, 100000 );
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+ sceneCube = new THREE.Scene();
|
|
|
+
|
|
|
+ // LIGHTS
|
|
|
+
|
|
|
+ var ambient = new THREE.AmbientLight( 0xffffff );
|
|
|
+ scene.addLight( ambient );
|
|
|
+
|
|
|
+ pointLight = new THREE.PointLight( 0xffffff, 2 );
|
|
|
+ scene.addLight( pointLight );
|
|
|
+
|
|
|
+ // light representation
|
|
|
+ sphere = new Sphere( 100, 16, 8, 1 );
|
|
|
+ lightMesh = new THREE.Mesh( sphere, new THREE.MeshBasicMaterial( { color:0xffaa00 } ) );
|
|
|
+ lightMesh.position = pointLight.position;
|
|
|
+ lightMesh.scale.x = lightMesh.scale.y = lightMesh.scale.z = 0.05;
|
|
|
+ scene.addObject(lightMesh);
|
|
|
+
|
|
|
+ // material samples
|
|
|
+
|
|
|
+
|
|
|
+ var r = "textures/cube/Park3Med/";
|
|
|
+
|
|
|
+ var urls = [ r + "px.jpg", r + "nx.jpg",
|
|
|
+ r + "py.jpg", r + "ny.jpg",
|
|
|
+ r + "pz.jpg", r + "nz.jpg" ];
|
|
|
+
|
|
|
+ var images = loadImageArray( urls );
|
|
|
+ var cubeMaterial3 = new THREE.MeshBasicMaterial( { color: 0xccddff, env_map: new THREE.TextureCube( images, THREE.RefractionMap ), refraction_ratio: 0.98, reflectivity:0.9 } );
|
|
|
+ var cubeMaterial2 = new THREE.MeshBasicMaterial( { color: 0xccfffd, env_map: new THREE.TextureCube( images, THREE.RefractionMap ), refraction_ratio: 0.985 } );
|
|
|
+ var cubeMaterial1 = new THREE.MeshBasicMaterial( { color: 0xffffff, env_map: new THREE.TextureCube( images, THREE.RefractionMap ), refraction_ratio: 0.98 } )
|
|
|
+
|
|
|
+ createCube( 10000, images );
|
|
|
+
|
|
|
+ webglRenderer = new THREE.WebGLRenderer( scene );
|
|
|
+ webglRenderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ webglRenderer.autoClear = false;
|
|
|
+ container.appendChild( webglRenderer.domElement );
|
|
|
+
|
|
|
+ stats = new Stats();
|
|
|
+ stats.domElement.style.position = 'absolute';
|
|
|
+ stats.domElement.style.top = '0px';
|
|
|
+ stats.domElement.style.zIndex = 100;
|
|
|
+ container.appendChild( stats.domElement );
|
|
|
+
|
|
|
+ var loader = new THREE.Loader();
|
|
|
+ loader.loadBinary( 'obj/lucy/Lucy100k_bin.js', function( geometry ) { createScene( geometry, cubeMaterial1, cubeMaterial2, cubeMaterial3 ) }, "obj/lucy" );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function addMesh( geometry, scale, x, y, z, rx, ry, rz, material ) {
|
|
|
+
|
|
|
+ mesh = new THREE.Mesh( geometry, material );
|
|
|
+ mesh.scale.x = mesh.scale.y = mesh.scale.z = scale;
|
|
|
+ mesh.position.x = x;
|
|
|
+ mesh.position.y = y;
|
|
|
+ mesh.position.z = z;
|
|
|
+ mesh.rotation.x = rx;
|
|
|
+ mesh.rotation.y = ry;
|
|
|
+ mesh.rotation.z = rz;
|
|
|
+ scene.addObject(mesh);
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function addCubeMesh( geometry, scale, x, y, z, rx, ry, rz, material ) {
|
|
|
+
|
|
|
+ mesh = new THREE.Mesh( geometry, material );
|
|
|
+ mesh.position.x = x;
|
|
|
+ mesh.position.y = y;
|
|
|
+ mesh.position.z = z;
|
|
|
+ mesh.rotation.x = rx;
|
|
|
+ mesh.rotation.y = ry;
|
|
|
+ mesh.rotation.z = rz;
|
|
|
+ mesh.scale.x = mesh.scale.y = mesh.scale.z = scale;
|
|
|
+ sceneCube.addObject(mesh);
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function createCube( size, images ) {
|
|
|
+
|
|
|
+ var hsize = size/2, plane = new Plane( size, size ), pi2 = Math.PI/2, pi = Math.PI;
|
|
|
+
|
|
|
+ addCubeMesh( plane, 1, 0, 0, -hsize, 0, 0, 0, new THREE.MeshBasicMaterial( { map: new THREE.Texture( images[5] ) } ) );
|
|
|
+ addCubeMesh( plane, 1, -hsize, 0, 0, 0, pi2, 0, new THREE.MeshBasicMaterial( { map: new THREE.Texture( images[0] ) } ) );
|
|
|
+ addCubeMesh( plane, 1, hsize, 0, 0, 0, -pi2, 0, new THREE.MeshBasicMaterial( { map: new THREE.Texture( images[1] ) } ) );
|
|
|
+ addCubeMesh( plane, 1, 0, hsize, 0, pi2, 0, pi, new THREE.MeshBasicMaterial( { map: new THREE.Texture( images[2] ) } ) );
|
|
|
+ addCubeMesh( plane, 1, 0, -hsize, 0, -pi2, 0, pi, new THREE.MeshBasicMaterial( { map: new THREE.Texture( images[3] ) } ) );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function createScene( geometry, m1, m2, m3 ) {
|
|
|
+
|
|
|
+ var s = 1.5, z = -1000;
|
|
|
+
|
|
|
+ addMesh( geometry, s, 0, 0, z, 0,0,0, m1 );
|
|
|
+ addMesh( geometry, s, -900, 0, z, 0,0,0, m2 );
|
|
|
+ addMesh( geometry, s, 900, 0, z, 0,0,0, m3 );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function loadImageArray( urls ) {
|
|
|
+
|
|
|
+ var i, images = [];
|
|
|
+
|
|
|
+ images.loadCount = 0;
|
|
|
+
|
|
|
+ for ( i = 0; i < urls.length; ++i ) {
|
|
|
+
|
|
|
+ images[i] = new Image();
|
|
|
+ images[i].loaded = 0;
|
|
|
+ images[i].onload = function() { images.loadCount += 1; this.loaded = 1;/*log( images.loadCount );*/ }
|
|
|
+ images[i].src = urls[i];
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ return images;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onDocumentMouseMove(event) {
|
|
|
+
|
|
|
+ mouseX = ( event.clientX - windowHalfX ) * 4;
|
|
|
+ mouseY = ( event.clientY - windowHalfY ) * 4;
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ var r = 0;
|
|
|
+
|
|
|
+ function loop() {
|
|
|
+
|
|
|
+ camera.position.x += ( mouseX - camera.position.x ) * .05;
|
|
|
+ camera.position.y += ( - mouseY - camera.position.y ) * .05;
|
|
|
+
|
|
|
+ cameraCube.target.position.x = - camera.position.x;
|
|
|
+ cameraCube.target.position.y = - camera.position.y;
|
|
|
+ cameraCube.target.position.z = - camera.position.z;
|
|
|
+
|
|
|
+
|
|
|
+ lightMesh.position.x = 1500 * Math.cos( r );
|
|
|
+ lightMesh.position.z = 1500 * Math.sin( r );
|
|
|
+
|
|
|
+ r += 0.01;
|
|
|
+
|
|
|
+ webglRenderer.clear();
|
|
|
+ webglRenderer.render( sceneCube, cameraCube );
|
|
|
+ webglRenderer.render( scene, camera );
|
|
|
+
|
|
|
+ stats.update();
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function log(text) {
|
|
|
+
|
|
|
+ var e = document.getElementById("log");
|
|
|
+ e.innerHTML = text + "<br/>" + e.innerHTML;
|
|
|
+
|
|
|
+ }
|
|
|
+ </script>
|
|
|
+
|
|
|
+ </body>
|
|
|
+</html>
|
